Graphite Mold for Diamond Core Bit Reamer Sintering Graphite Mould
5 Piece
$1005 Piece
$1Product information
High-quality Graphite Mold for Diamond Core Bit Reamer Sintering Graphite Mould supplied by Jiangxi Ningheda New Material Co., Ltd.. Bulk wholesale pricing ranges from $1 to $100 per Piece with a minimum order of 5 Piece. Inquiry for latest prices.
Production Capacity:
100000
HS Code:
380190900
Crystal Morphology:
Artifical Graphite
Origin:
China
Trade Term:
FOB, CIF, CFR, EXW
Composition:
Graphite
Type:
Graphite Mold
Product Name:
Graphite Mold for Diamond Core Bit and Reamer Sint
Specifications
Production Capacity:
100000
HS Code:
380190900
Crystal Morphology:
Artifical Graphite
Origin:
China
Trade Term:
FOB, CIF, CFR, EXW
Composition:
Graphite
Type:
Graphite Mold
Product Name:
Graphite Mold for Diamond Core Bit and Reamer Sint
Name:
Graphite Sintered Mold
Grade:
HP
Carbon Content:
High-Carbon
Payment Term:
LC, T/T, PayPal, Western Union
Model NO.:
MSL80
Specification:
MSL80
Forming Way:
Molded Graphite
Trademark:
Ningheda
Transport Package:
Pallet
Port Of Loading:
Tianjin Port, Qingdao Port, Shanghai Port
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-07-20
Annual Revenue Amount:
Not specified
Numbers Of Employees:
126
Preferred Payment Term:
LC, T/T, PayPal, Western Union
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Tianjin Port, Qingdao Port, Shanghai Port
Certificates:
ISO14001, ISO45001:2018, ISO9001:2015
Product descriptions from the supplier
Good Thermal Shock Resistance Custom Graphite Mold for Diamond Core Bit Sintering
Characteristics of our graphite mold:
1. Graphite molds are one of the most heat-resistant materials at present.
2. With good thermal shock resistance, no cracks will occur when the temperature is hot and cold.
3. Excellent thermal conductivity and conductive properties.
4. Good lubrication and abrasion resistance.
5. Chemical stability, acid and alkali resistance and corrosion resistance, not easy to react with most metals.
6. Factory supply customized graphite sintering mold Easy to process, good mechanical processing performance, can machining. complex shape and high precision mold.
The graphite mold has been widely used in following aspects:
1.Continuous casting mold
2. Pressure foundry mold
3.Glass molding with die
4.Sintering mold
5.Centrifugal casting mold
6.Smelt gold, silver, jewelry......
| Grade | NX603 | NX604 | NX605 |
| Grain Size (≤μm) | 25 | 25 | 25 |
| Bulk Density (≥g/cm3) | 1.78 | 1.85 | 1.90 |
| Compressive Strength (≥MPa) | 70 | 80 | 90 |
| Flexural Strength(≥MPa) | 35 | 38 | 42 |
| Porosity(≤%) | 17 | 14 | 11 |
| Specific Resistance(≤μΩm) | 12 | 11 | 10 |
| Ash Content(≤ppm) | 600 | 500 | 300 |
| Shore Hardness | 50 | 55 | 60 |
- The ash content can be purified to 30ppm according to the requirement.
- The above index data is the standard value, not the guaranteed value.
Established in 2017, located in Fengxin Industrial Area, Yichun City, Jiangxi Province, China, Jiangxi Ningheda New Material Co., Ltd. is the subsidiary company of Jiangxi Ningxin New Material Co., Ltd.
Jiangxi Ningxin New Material Co., Ltd. is an enterprise which specializes in R&D, production and sale of special graphite. The total investment is RMB 520 million. It covers an area of more than 152000 square meters and produces 10000 tons of special graphite annually, which makes Ningxin to be the leading enterprise in the domestic industry.
On November 8th, 2016, Ningxin was listed of Chinese new third board. The stock abbreviation is Ningxin New Material, and stock code is 839719.
Jiangxi Ningheda New Material Co., Ltd. is mainly engaged in graphite product processing, graphite product matching service, providing graphite materials, graphite electrode and graphite products for the lithium industry, rare earth industry, machinery industry, aerospace, semiconductor and solar photovoltaic industry, together with the corresponding products technical service and technical application of update program.
With excellent production technology, good customer service, high market share, and relying on the advantage of new material, capital and management of parent company (Jiangxi Ningxin New Material Co., Ltd.), Jiangxi Ningheda New Material Co., Ltd. develops quickly. We devote to the extension of the special graphite industry chain, and make contributions for building the future whole graphite industry strategy.
Advantages of Ningheda graphite raw material
1. The processing materials are ultrafine granule structure, high purity and graphite with high graphitization degree.
2. High hardness, good anti-oxidation performance and high machining accuracy
3. Good conductivity, high resistivity, sufficient mechanical strength
4. Small porosity and dense structure.
5. Excellent thermal shock resistance, conductive and thermal conductivity.
6. High temperature resistance, corrosion resistance, acid and alkali resistance, good wear resistance.
7. Surface can be treated with anti-oxidation.
Q1. Are you a factory or trading company?
A: We are an ISO9001-Qualified processing manufacturer with70000 square meter factory area.
Q2. Can you introduce your main products?
A: Sure.
Jiangxi Ningheda New Material Co., Ltd. mainly produces graphite products, we can offer customized shape according to customers' specific demand. Our Graphite Products, including molded graphite products, isostatic graphite products, extruded graphite products, vibration moulding graphite products. We can produce a lot of graphite products, like graphite mold, graphite casting die, graphite heating element, graphite crucible, graphite sealing ring, graphite tube, graphite rod, graphite edm, graphite block etc.
Q3.What is your MOQ?
A: 1 piece (graphite block, graphite rod, graphite box, graphite mold, graphite material, graphite seal ring, graphite crucible, graphite products, graphite sintering mold, graphite heater etc.).
Q4. Can you offer free samples?
A: Yes, usually we can offer free sample for you to check the quality, but do not afford express charge.
However, if the sample is expensive, like large size, we has to charge basic cost of the sample.And Samples delivery time will be about 3-10 days.
Q5. When can I get the price?
A: We will reply you within 24 hours after getting your detailed requirements, like size, quantity etc. If it is an urgent order, you can call us directly.
Q6. Do you accept OEM or ODM orders?
A: Yes, of course, most of our products are customized.
Q7. How about your delivery time?
A: Usually 7 to 25 days after payment.
Q8. Do you test your goods before delivery?
A: Yes, we have strict inspection system.
Q9. How do you keep long-term business relationship?
A: 1. Good quality and competitive price to ensure mutual benefit;
2. Quick reply and sincere service.
Notice: When you contact us, please show us the accurate drawing and your selected graphite material information, then we can offer you accurate price.
Packaging: export standard wooden case.
Delivery Detail: 15~30 working days after confirming order.
Sea Port: Shanghai or other port of China Mainland.
