Hardfacing Material Tungsten Carbide Composite Welding Rods
kg
Negotiable
Product information
High-quality Hardfacing Material Tungsten Carbide Composite Welding Rods supplied by Zhuzhou Better Tungsten Carbide Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Specification:
1.6~3.2mm 3~5mm 4.8~6.4mm 6.4~8mm 8~9.5mmm.
Production Capacity:
50000
Trade Term:
CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW
Origin:
China
Port Of Loading:
Guangzhou, shenzhen, shanghai
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Application:
Mining ,Oil Drilling
Name:
Tungsten Carbide Composite Rods
Specifications
Specification:
1.6~3.2mm 3~5mm 4.8~6.4mm 6.4~8mm 8~9.5mmm.
Production Capacity:
50000
Trade Term:
CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW
Origin:
China
Port Of Loading:
Guangzhou, shenzhen, shanghai
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Application:
Mining ,Oil Drilling
Name:
Tungsten Carbide Composite Rods
Usage:
Wear Resistance and Hardfacing and Welding
Colar:
Yellow
Trademark:
ubt
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2011-09-07
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW
Port Of Loading:
Guangzhou, shenzhen, shanghai
Certificates:
ISO 9001: 2015 Certificate, ISO 9001:2015
Product descriptions from the supplier
Our tungsten carbide composition welding rods are very high in quality and best in price.
Description:
1. The tungsten carbide composite rod is made of cemented carbide tips and Ni/Ag(Cu)alloy. The carbide tips are always tungsten carbide crushed grits, carbide wear inserts, like the carbide star shape inserts, carbide pyramid shape inserts, shark shape inserts, and so on. Sometimes, the carbide tips can be tungsten carbide powder. The economic choice is tungsten carbide crushed grits. If you want higher durability than carbide grits, carbide inserts are better. However, the cemented carbide/crushed carbide with a sharp edge has excellent wear resistance and cutting ability too.
2. The hardness is 89-91 HRA, the binder metal is Ni and copper alloy, strength can up to 690MPa, hardness HB≥160.
3. To brief, most of the Composite rod made using crushed sintered Tungsten Carbide grains bonded with a bronze nickel matrix,(Cu 50 Zn 40 Ni 10) with a low melting point ( 870°C ).
There are different types of tungsten carbide composition welding rods in our factory:
1. Copper welding material + tungsten carbide grits.
2. Nickle welding material + tungsten carbide grits.
With each different material, there are two different percentages of tungsten carbide grits too:
1. 70% tungsten carbide grits.
2. 30% tungsten carbide grits. Blanch welding material.
The grain sizes of the carbide grits:
1. 1/8-1/16 in. ( 3.2-1.6 mm )
2. 3/16-1/8 in. (4.8-3.2 mm)
3. 1/4-3/16 in. (6.3-4.8 mm)
4. 3/8-5/16 in. (9.5-7.9 mm)
5. 5/16-1/4 in. (7.9 -6.3 mm)
6. 3/8-1/4 in. (9.5-6.3 mm)
7. 1/2-5/16 in. (12.7-7.9 mm)
Carbidide welding rods come in different lengths and widths.
The grades of the composite rods
There are main grades that depend on the different proportions of the tungsten carbide grits
| Grade | Chemical compositions(%) | Physical performance | Applications | ||
| WC | Cu+Zn+Sn | Co | |||
| BT-Cu-30 | 64-67 | 30±2 | 3.8-4.2 | Hardness: >160 HB TRS: >690MPa | Down hole tools Plungers Shafts Agricultural/mining equipment Vlaves Turbine Blades Tool joints Extruder barrels and screws |
| BT-Cu-40 | 53-56 | 40±2 | 4.6-4.8 | ||
| BT-Cu-45 | 48-52 | 45±2 | 4.2-4.5 | ||
| BT-Cu-50 | 44-48 | 50±2 | 3.8-4.2 | ||
| Item | Carbide grits size | Apperance | Available width (mm) | Available length (mm) | |
| (mm) | (inch) | ||||
| 1 | 1.6-3.2 | 1/8-1/16 | Bare or with fluxed-coating | (20-22 ) (18-20 ) (10-12) | 280- 450 |
| 2 | 3.2-4.8 | 3/16-1/8 | |||
| 3 | 4.8-6.4 | 1/4-3/16 | |||
| 4 | 6.4-8.0 | 5/16-1/4 | |||
| 5 | 8.0-9.5 | 3/8-5/16 | |||
| 6 | 9.5-11.0 | 7/16-3/8 | |||
| 7 | 11.0-12.7 | 1/2-7/16 | |||
Sizes, unit weight, and grit sizes can be OEM.
Composite rod welding has been acknowledged throughout the oil drilling, mining, and construction industry worldwide for its extra hardness and high wear-resistant properties. The use is even spreading to more industries and is getting greater use. Composite rod welding has wear and cutting properties coupled by high-end weld ability and low fuming, allowing the material to be usedin stabilizers, reamers, drill pipe joints, construction drilling, hydraulic-cutter, pipe cutter blades, core bit, scraper, twist drill, milling and grinding shoes, etc.
Our packing of tungsten carbide composition welding rods
1. First in PP bags
2. Then, PP bags are put into paper boxes.
3. 2 Paper boxes into paper cartons.
4. Paper cartons onto a wooden case.
We are your good partner, trust us!
