High Efficiency Micro Powder Grinding Mill Machine

High efficiency micro powder grinding machine

Engineered over decades of production expertise and integrating cutting-edge Swedish milling technology, this micro powder grinder represents a breakthrough in ultra-fine particle processing, developed through over twenty iterations of testing and refinement. Operating under identical parameters, it delivers triple the output and a fineness level 300 mesh finer than both Raymond and medium-speed mills, surpassing the finest achievable results of wet stirred mills—long considered the benchmark for modern, high-performance, energy-efficient grinding solutions.

A micro powder grinder is designed to create ultrafine and extremely fine powders from non-flammable, non-explosive, and fragile substances including calcite, chalk, limestone, dolomite, kaolin, bentonite, talc, mica, magnesite, illite, pyrophyllite, vermiculite, sepiolite, attapulgite, rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite, rock phosphate, potassium ore, pumice, and others, all with a Mohs hardness of six or lower.

Advantages and Benefits of micro powder grinding machine

A micro powder grinding mill delivers double the output compared to jet mills, mixing grinders, and ball mills when operating under identical final particle size and motor power, while reducing energy use by 30%.

Long service life of spare parts
The ring and roller are crafted from a specialized alloy featuring high efficiency. With identical grinding media and finish for a specific dimension, spare component durability reaches approximately one year—2 to 3 times greater than that of impact or turbo mills. Additionally, operational lifespan extends between 2 and 5 years when processing calcite carbonate.

High safety and reliability
Since the grinding chamber lacks rolling bearings or screws, issues arising from bolt fragmentation or quick deterioration of bearing and seal parts do not occur.

High fineness and flexible adjustment
The grinding output's particle size can be set within the range of 325 to 2,500 mesh (47–5 microns), achieving a D97 value of no more than 5μm.

Environment-friendly
The application of pulse bag filter and muffler greatly alleviates dust pollution and noise.

Advanced intelligent speed control device
It is featured by convenient adjustment and more uniform particle size.

Working Principle of micro powder grinding machine

Each dial and the main support shaft are powered by an electric motor from the primary unit via a gearbox, and the rollers that move within the ring are activated by the dial through a plunger mechanism. Once processed by the hammer mill, large particles are reduced in size and transported to a storage hopper via a conveyor, then evenly distributed to the center of the first dial using an electromagnetic vibrating feeder and feed conduit. The material is then pushed outward toward the dial’s edge by centrifugal force, drops into the ring, and is further pulverized by the rollers, eventually forming a fine powder after passing through three grinding stages. A high-pressure centrifugal fan draws in ambient air and forces the ground material into a classifier. Inside the powder concentrator, the rotating turbine separates oversized particles, returning them to the mill for additional grinding, while finer particles mix with the air and enter a cyclone, exiting through a discharge chute situated at the base. The air, now containing minimal fine particles, is cleaned using an impulse filter and then expelled through a blower and silencer.




Technical Data of micro powder grinding machine
