High Efficiency Round Metal Bar Peeling Machine
Piece
Negotiable
Product information
High-quality High Efficiency Round Metal Bar Peeling Machine supplied by RealWell Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
1000PCS/Year
HS Code:
84581900
Certification:
CE, ISO9001
Trade Term:
FOB, CFR, CIF
Payment Term:
LC, T/T
Port Of Loading:
Qingdao,China
Trademark:
RW
Transport Package:
Seaworthy Package
Specifications
Production Capacity:
1000PCS/Year
HS Code:
84581900
Certification:
CE, ISO9001
Trade Term:
FOB, CFR, CIF
Payment Term:
LC, T/T
Port Of Loading:
Qingdao,China
Trademark:
RW
Transport Package:
Seaworthy Package
Automatic Grade:
Semi-Automatic
Origin:
Shandong, China
Type:
Special Casting
Model NO.:
WXC130CA
Specification:
weight: 11.5T
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Year Established:
2020-06-24
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CFR, CIF
Port Of Loading:
Qingdao,China
Certificates:
Brand
Product descriptions from the supplier
General Introduction
The WXC series peeling machine Dedicated high-performance lathes designed for both initial shaping and final polishing of round bars, pipes, and wire rods. Efficiently eliminates surface decarburization, fissures, and other surface imperfections with speed and exact accuracy.
he models in the parameter table can be made into common types (Type B, Type C), small (CA) type and numerical control (S) typ
Strengths & Merits
1. It can process extra long rods, pipes and wires, including coil to coil, and coil to bars.
2. High efficiency: multiple blades simultaneously operate: its work efficiency is several times higher than conventional lathe.
3. High precision: diameter tolerance of finished products ≤h9, surface roughness ≤6.3 μm
4. Non-pollution: disposals can be recycled.
Parameter Table
.
Clients Visit to Our Factory
WELCOME YOUR INQUIRY FOR ANY ITEM YOU ARE INTERESTED!
The WXC series peeling machine Dedicated high-performance lathes designed for both initial shaping and final polishing of round bars, pipes, and wire rods. Efficiently eliminates surface decarburization, fissures, and other surface imperfections with speed and exact accuracy.
he models in the parameter table can be made into common types (Type B, Type C), small (CA) type and numerical control (S) typ
Strengths & Merits
1. It can process extra long rods, pipes and wires, including coil to coil, and coil to bars.
2. High efficiency: multiple blades simultaneously operate: its work efficiency is several times higher than conventional lathe.
3. High precision: diameter tolerance of finished products ≤h9, surface roughness ≤6.3 μm
4. Non-pollution: disposals can be recycled.
Parameter Table
| Model | WXC130CA | |
| Workpiece Required | Cutting range(mm) | Φ35~ Φ135X3000~unlimited |
| Tensile strength σb(Mpa) | ≤1100 | |
| Surface hardness | ≤HB320 | |
| Bend(mm/m) | ≤1.50 | |
| Diameter tolerance | As per GB 702-88 group two | |
| Roundness | ≤diameter tolerance 50% | |
| Surface roughness(Ra) | ≤25~50mm | |
| Finished Products | Diameter range(mm) | Φ30~Φ130 |
| Radius cutting depth(mm) | 0. 5~2.5 | |
| Diameter tolerance | ≤IT9(standard diameter tolerance) | |
| Surface roughness (Ra) | ≤3.2μm | |
| Roundness (mm) | ≤0.03 | |
| Feeding speed (infinitely adjust speed m/min) | 1.0~5.0(Slow down for materials with ceaseless chips, high strength and high hardness.) | |
| Cutter head rotating speed (infinitely variable speed) (r/min) | 160~900 (2 level speed gearbox) | |
| Main motor power (kW) | 90(4 electrodes) | |
| Feeding motor power (kW) | 5.5 (4 electrodes) | |
| Clamping vehicle motor (kW) | 4 (servo) | |
| Dimensions (m) (reference) | Host machine 4X3.7X2.4 | |
| Weight (t) (reference) | Host machine 11.5 | |
| Total capacity (kW) | 120 | |
| Source of compressed air (prepared by user) | 0.4~0.8MPa, 2m3/min, with second grade oil and water separator | |
Composition Introduction
The equipment is composed of two general members: "host machine and transportation devices".
1. Main machine: comprises the lathe bed, spindle, oil-air cooling mechanism, front clamping and back extraction components, front guide and central-back guide, and other similar elements.
2. Transportation devices: Transportation devices comprises loader and unloader.
Oil-air lubrication system: Tailored to ensure consistent lubrication and heat dissipation during spindle high-speed spinning, this system includes a pump, an oil-air manifold, and a gas processing unit.
Cutting fluid recirculation system: This system includes a coolant recovery pump, piping, and nozzles. A high-pressure pump sends cooled cutting fluid from a reservoir via pipes to a nozzle positioned close to the cutting tool. The fluid is directed straight at the cutting edge and swarf, effectively removing most of the generated heat. The heated fluid, along with the swarf, exits through a discharge port beneath the tool and returns via the piping to the reservoir where it cools before reuse.
Chip-conveyor: This is a high-grade, third-party manufactured component. Fragments move via the lower opening on the cutter head, fall onto the conveyor’s chain links, and are transported by mechanical drive, remaining ready for pickup.
Hydraulic system: Comprised of an electric pump, control valve, hydraulic fluid reservoir, piping, and additional components, this system operates the front (rear) clamping units by driving bar clamping and release actions via hydraulic cylinders.
The electrical system of the machine comprises power supply and control components, consisting of one power distribution cabinet and one control panel. This setup manages the electrical operation of the primary drive, front and rear clamping feeding units, cooling mechanism, hydraulic circuit, chip conveyance, and material transport systems.
MODELS FOR YOUR SELECTION
.
| Model | Input Dia | Length | Feeding Speed | Cutting Depth | Surface Roughness | Dia.Tolerance | Spindle Motor | Total Capacity |
| WXC20 | ф5-ф20mm | ≥1400mm | 1-25m/min | 0.5-2mm | Ra≤3.2 | IT9 | 22KW | 30KW |
| WXC40 | ф5.5-ф40mm | ≥1400mm | 1-15m/min | 0.5-2mm | Ra≤3.2 | IT9 | 45KW | 63KW |
| WXC60 | ф13-ф75mm | ≥2000mm | 1-15m/min | 0.5-2mm | Ra≤3.2 | IT9 | 45KW | 63KW |
| WXC80 | ф16-ф85mm | ≥2200mm | 1-12m/min | 0.5-3mm | Ra≤3.2 | IT9 | 55KW/75KW | 75KW/90KW |
| WXC100 | ф25-ф110mm | ≥2800mm | 0.5-10m/min | 1-4mm | Ra≤3.2 | IT9 | 75KW | 95KW |
| WXC130 | ф35-ф135mm | ≥3000mm | 0.3-6m/min | 1-5mm | Ra≤3.2 | IT9 | 90KW | 120KW |
| WXC160 | ф45-ф170mm | ≥3500mm | 0.3-5m/min | 1-5mm | Ra≤3.2 | IT9 | 110KW | 140KW |
| WXC200 | ф70-ф210mm | ≥4000mm | 0.3-4m/min | 1-5mm | Ra≤3.2 | IT9 | 132KW | 165KW |
| WXC250 | ф95-ф260mm | ≥4000mm | 0.2-2.5m/min | 1-5mm | Ra≤3.2 | IT9 | 160KW | 210KW |
| WXC350 | ф150-ф360mm | ≥4500mm | 0.1-2m/min | 1-10mm | Ra≤3.2 | IT9 | 200KW | 265KW |
| WXC400 | ф205-ф410mm | ≥4800mm | 0.1-2m/min | 1-10mm | Ra≤3.2 | IT9 | 250KW | 345KW |
| WXC500 | ф315-ф510mm | ≥5000mm | 0.1-1.5m/min | 1-10mm | Ra≤3.2 | IT9 | 315KW | 415KW |
