High Performance 12V 40A New Auto Starter Automotive 4pin Relay
100-999 Pieces
$3.581000-9999 Pieces
$1.6810000 Pieces
$1.08Product information
High-quality High Performance 12V 40A New Auto Starter Automotive 4pin Relay supplied by Zhejiang Goodvic Electronic Co., Ltd.. Bulk wholesale pricing ranges from $1.08 to $3.58 per Pieces with a minimum order of 100 Pieces. Inquiry for latest prices.
Ambient Temperature:
-40°C~+85°C
Package Gross Weight:
1.000kg
Insulation Resistance:
100MΩ
Input Parameter:
12VDC
Production Capacity:
15000000/Year
Contact Point Type:
1A (Spstno)
Package Size:
20.00cm * 20.00cm * 20.00cm
Max Switching Voltage:
27VDC
Specifications
Ambient Temperature:
-40°C~+85°C
Package Gross Weight:
1.000kg
Insulation Resistance:
100MΩ
Input Parameter:
12VDC
Production Capacity:
15000000/Year
Contact Point Type:
1A (Spstno)
Package Size:
20.00cm * 20.00cm * 20.00cm
Max Switching Voltage:
27VDC
Max Rated Switching Current:
40A
HS Code:
853641000
Contact Point Material:
AgSnO2
Origin:
China, Zhejiang
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Transport Package:
Customizable
EMC:
EMI
Certification:
ENEC, CB, SEV
Trade Term:
FOB, CIF, CFR, EXW
Pin Number:
Four
Model NO.:
GW821
Trademark:
Goodvic/customizable
Application:
Imitated European Cars
Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Port Of Loading:
Ningbo Port
Type:
Please Contact Us
Specification:
Please refer to details page
Payment Methods:
Support payments in USD
Withstand Voltage Of Insulation Level:
withstand Voltage between Coil
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2010-03-25
Annual Revenue Amount:
Not specified
Numbers Of Employees:
89
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Ningbo Port
Certificates:
ISO14001, ISO9001, ROHS Certification Certificate, TUV Certification Certificate, VDE Certification Certificate
Product descriptions from the supplier
*Main feature:
40A contact switching capability
A group of normally open, a group of conversion two contact forms
Various installation forms
| Contact Specification | |
| Contact Form | 1A, 1C |
| Contact Material | AgSno2 |
| Max Operating Current | 40A |
| Max Operating Voltage | 27VDC |
| Rated Load | 1A:40A 13.5VDC 20A 27VDC |
| Insulation Resistance | 100MΩ |
| Dielectric Strength | 500VAC/M |
| Ambient Temperature | -40°C~+85°C |
| Operate/Release Time | ≤10ms |
| Release Time | ≤5ms |
| Mechanical Life | 1 X106 |
| Electrical Life | 1 X105 |
| Terminal Type | Quick ConnectTerminal |
| Coil Parameters | |||||||||
| Rated Voltage |
Operate Voltage |
Release Voltage |
Coil Resistance |
Parallel Resistance |
Equivalent Resistance |
Relay Power Consumption |
Max Allowable Coil Voltage |
||
| 20 °C | 85 °C | ||||||||
| Standard | 12 | ≤8.4 | ≥1.2 | 80 | - | - | 1.8 | 20.2 | 15.7 |
| 12 | ≤8.4 | ≥1.2 | 80 | 680 | 71.6 | 2.0 | 20.2 | 15.7 | |
| 24 | ≤16.8 | ≥2.4 | 320 | - | - | 1.8 | 40.5 | 31.5 | |
| 24 | ≤16.8 | ≥2.4 | 320 | 2700 | 286 | 2.0 | 40.5 | 31.5 | |
| Low power | 12 | ≤8.4 | ≥1.2 | 90 | - | - | 1.6 | 20.2 | 15.7 |
| 12 | ≤8.4 | ≥1.2 | 90 | 680 | 79.5 | 1.8 | 20.2 | 15.7 | |
| 24 | ≤16.8 | ≥2.4 | 360 | - | - | 1.6 | 40.5 | 31.5 | |
| 24 | ≤16.8 | ≥2.4 | 360 | 2700 | 317.6 | 1.8 | 40.5 | 31.5 | |
Remark: (1)In case of no tolerance shown in outline dimension: outline dimension≤1mm, tolerance should be ±0.2mm;Outline dimension>1mm and ≤5mm, tolerance should be ±0.3mm; outline dimension>5mm,tolerance should be ±0.4mm.
ZHEJIANG GOODVIC ELECTRONIC CO, LTD is one of the leading industry professionals when it comes to automobile, magnetic latching relays and manganin shunts in Wenzhou China. We pride ourselves on research, development, handle production and sales on our own.
At Goodwin, we have passed ISO9001:2008 quality management system and ISO14001:2004 environmental management system certifications. These are among-st the national level of safety production standardization certifications. We have the international and national patent for our single phase and three phase latching relay, which we have researched and developed.The products have gone through the VDE and CQC security certification one at a time, and conforms to IEC62055-31, UC3, RoHS standards.
Goodwin's new plant is 10000 square meters in size, a staff of nearly 300, and this includes a strong professional R & D team with 10 dedicated people. The primary management and technical personnel all have between 5 and 10 years' experience of magnetic latching relay and Manganin shunt experience in the industry.We can produce more than 20 series, supported by three automated production lines and more than ten semi-automated or non-standard production lines, and have the capacity to produce 15 million pieces/year. The relay has a capacity of 12 million pieces/year, with a guaranteed high delivery security.
1. Q: How about the payment terms?
Normally 30% deposit in advance. It can be discussed when we have friendly relationship.
2. How about Delivery time?
We can produce 50,000 pcs per month, large capacity. Normally, 15 days.
3. Q:Can I get a sample?
For sure, we are willing to supply samples free for quality checking.
4. Q : What's the price?
Reasonable price, competitive price, and acceptable prices, which are all based on good quality.
Any requirements or question,welcome to"Send" us an e-mail Now!!!TRated
