High Performance DN15-DN20 Volumetric Rotary Piston Type Plastic Body Water Meter
100 Piece
$14Product information
High-quality High Performance DN15-DN20 Volumetric Rotary Piston Type Plastic Body Water Meter supplied by Hebei Shanghong Meters Technology Co., Ltd.. Bulk wholesale pricing is $14 per Piece with a minimum order of 100 Piece. Inquiry for latest prices.
Production Capacity:
10000
Nominal Diameter:
15-40
Thread End Type:
Bsp
Level Measurement:
C
Origin:
China
Application:
Civil
Medium Temperature:
Cold Water
Model NO.:
DN15-DN20
Specifications
Production Capacity:
10000
Nominal Diameter:
15-40
Thread End Type:
Bsp
Level Measurement:
C
Origin:
China
Application:
Civil
Medium Temperature:
Cold Water
Model NO.:
DN15-DN20
Counter Instructions:
Digital
Register:
Dry Dial
Work Environment:
Dry Water Meter
Trade Term:
FOB, CFR, CIF, CIP
Medium Pressure:
General Water Meter
Feature:
High Performance
Installation:
Horizontal Installation
Certificate:
ISO4064
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Material:
Plastic,Brass
Trademark:
S. H. Meters
Port Of Loading:
TIANJIN
Stucture:
Traditional
Install:
Vertical
Principle:
Volumetric Meter
Transport Package:
Wooden and Carton Packaging
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2013-09-03
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
FOB, CFR, CIF, CIP
Port Of Loading:
TIANJIN
Product descriptions from the supplier
High Performance DN15-DN20 Volumetric Rotary Piston Type Plastic Body Water Meter
Mechanism use of high-quality rmaterial to ensure a stable characteristic.
| Description | Unit | Hydraulic Data And Dimensions | |||||
| Nominal Size | mm(inch) | DN15(1/2) | DN20(3/4) | DN(1) | DN32(1-1/4) | DN40(1-1/2) | |
| Q4 Error Limit ±2% | m³/h | 3.125 | 5 | 7.875 | 12.5 | 20 | |
| Q3 Error Limit ±2% | m³/h | 2.5 | 4 | 6.3 | 10 | 16 | |
| Q2 Error Limit ±2% | l/h | 25 | 40 | 63 | 100 | 160 | |
| Q1 Error Limit ±5% | l/h | 15.6 | 25 | 39.4 | 62.5 | 100 | |
| Min.Reading | l | 0.05 | 0.05 | 0.05 | 0.5 | 0.5 | |
| Max.Reading | m³ | 9999.9999 | 9999.9999 | 9999.9999 | 99999.999 | 99999.999 | |
| MAP | MPa | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | |
| Press Loss ΔP AT | MPa | ≤0.063 | ≤0.063 | ≤0.063 | ≤0.063 | ≤0.063 | |
| L | mm | 115 | 165 | 199 | 260 | 300 | |
| B | mm | 43 | 43 | 53 | 60 | 77 | |
| weight | Without Connections | Kg | 1.14 | 1.56 | 2.48 | 3.47 | 5.65 |
| With Connections | Kg | 0.97 | 1.3 | 2.05 | 2.75 | 4.7 | |
You need a good solution for water metering---Catering all your needs.
As the China's professional manufacturer and distributor since 2013, we have developed a comprehensive water meter range and a complete solution for the Commercial ,agriculture, Industrial and Domestic market on Mechanical type water meter and smart water meters. Moving with the changes in technology and precision metering has been the mission of the company since its genesis and we are adding metering that can support water sustainability using. Since 2017, we start the export smart water meters to the whole world, and hope more and more countries and region people can save the water with us together with the smart technology and system. Nowadays, S.H.Meters have already become one the main important exporter for water flow meters in China.
We will provide your product to your hand in timely manner and keep you informed of process with your order throughout the whole sales. From the strictly QC inspection, strictly cost control and five star quality services,we believe that you will own a more solution on water metering.
