High Performance Integrated Gluing and Framing Machine

High Performance Integrated Gluing and Framing Machine - Image 1
High Performance Integrated Gluing and Framing Machine - Image 2
High Performance Integrated Gluing and Framing Machine - Image 3
High Performance Integrated Gluing and Framing Machine - Image 4
High Performance Integrated Gluing and Framing Machine - Image 5
High Performance Integrated Gluing and Framing Machine - Image 6
High Performance Integrated Gluing and Framing Machine - Image 1
High Performance Integrated Gluing and Framing Machine - Image 2
High Performance Integrated Gluing and Framing Machine - Image 3
High Performance Integrated Gluing and Framing Machine - Image 4
High Performance Integrated Gluing and Framing Machine - Image 5
High Performance Integrated Gluing and Framing Machine - Image 6

1 PC

$15,000

1 PC

$10,000

Product information

High-quality High Performance Integrated Gluing and Framing Machine supplied by YiLi Pv Tech Factory Ltd. Bulk wholesale pricing ranges from $10,000 to $15,000 per PC with a minimum order of 1 PC. Inquiry for latest prices.

Warranty:

12 Months

After Sales Service:

24 Hours Online Support

Temperature:

25±5℃

Voltage:

3ψ5W, 380V, 50/60Hz

Specification:

5600*3200*2500mm

Trade Term:

FOB, CIF, CFR, EXW

Origin:

Jiangsu, China

Payment Term:

LC, D/P, PayPal, Western Union, Small-amount payment

Specifications

Warranty:

12 Months

After Sales Service:

24 Hours Online Support

Temperature:

25±5℃

Voltage:

3ψ5W, 380V, 50/60Hz

Specification:

5600*3200*2500mm

Trade Term:

FOB, CIF, CFR, EXW

Origin:

Jiangsu, China

Payment Term:

LC, D/P, PayPal, Western Union, Small-amount payment

Port Of Loading:

Shanghai Port

Transport Package:

Wooden Box

Trademark:

Yilipv

Solar Panel Short Side Size Error:

±0.5 mm

Solar Panel Long Side Size Error:

±0.5 mm

Solar Panel Diagonal Size Error:

≤1 mm

Humidity:

≤80%

Business Details

Country:

China

Business Types:

Not specified

Main Markets:

Not specified

Main Products:

Not specified

Year Established:

2014-04-22

Annual Revenue Amount:

Not specified

Numbers Of Employees:

56

Preferred Payment Term:

LC, D/P, PayPal, Western Union, Small-amount payment

Preferred Trade Term:

FOB, CIF, CFR, EXW

Port Of Loading:

Shanghai Port

Product descriptions from the supplier

SONA2024 2.2.1
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
Trinity fully automatic framing YLP-F2500
Function:
1.Automatic glue application, automatically grabs the frame and places it on the framing machine. When assembling the frame, the surrounding area will be evenly filled with glue.
2.The framing machine adopts a high-position frame to transmit laminated panel and place frames at the same time, saving time.
3.The equipment meets special requirements such as no C-face frame, film-less frame, guide rail frame, steel frame, etc., and has strong applicability.
4.The size of the machine is small and takes up little space.
5.The equipment operation surface is simple, convenient and reliable.
6.The flatness of the working surface of the equipment meets the glue overflow requirements, and one-click adjustment is available for different frames, which is convenient and simple.
Product advantages:
1.Servo drive
2.Lower component damage rate.
3.The robot grabs 4 frames at a time, with high efficiency.
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
Item
Parameters
Warranty
12 Months
Glass size
W990~1400mm ,L1640~2500mm
Air pressure
0.6~0.8Mpa
Voltage
AC 380V 3-phase 5-wire 50Hz
Power
12KW
Transfer speed
0~30M/Min
Working environment
25±5℃
Humidity
≤80%
Beat
≤24 Sec
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
High Performance Integrated Gluing and Framing Machine
Q1:What is your delivery date?
A: Production is usually completed within 30 days after receiving your advancepayment, and specific adjustments need to be made based on our inventory andproduction plan.

Q2:Payment method?
A: We accept wire transfers.

Q3: How many days do installation and training take to complete?
A: Depending on the size of the production line, it takes 7-30 days.

Q4: How long is the warranty period for the machine?
A: Our equipment usually comes with a one-year warranty period, calculated fromthe completion of installation.

Q5: How many workers do we need to operate these machines?
A: Depending on the size of the production line, there are 3-5 people.

Q6: Do you provide raw materials?
A. We do not direcly provide raw materials, we can help customers purchasehigh-quality and cost-effeclive raw materials.
