High Precision Laboratory Grade Offset Printing Ink Sampling Machine
1 Piece
$5,0001 Piece
$100Product information
High-quality High Precision Laboratory Grade Offset Printing Ink Sampling Machine supplied by UBY Industrial Co., Ltd.. Bulk wholesale pricing ranges from $100 to $5,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Weight:
0-100Kg
Accuracy Grade:
0.5
Production Capacity:
1000/Year
Maxcapacity:
<1000KN
Power Source:
AC220V
Origin:
China
Display:
Digital
Loading Method:
Dynamic Load
Specifications
Weight:
0-100Kg
Accuracy Grade:
0.5
Production Capacity:
1000/Year
Maxcapacity:
<1000KN
Power Source:
AC220V
Origin:
China
Display:
Digital
Loading Method:
Dynamic Load
Load Way:
Electronic Load
Trade Term:
FOB, EXW, CFR, CIF, DDP, FCA
Type:
Ink Printing Proofer
Control:
Manual Control
Transport Package:
Professional Export Packaging
Port Of Loading:
Shenzhen, Shanghai, Guangzhou
Payment Term:
T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Model NO.:
UP-6005
Trademark:
own
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-08-21
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
FOB, EXW, CFR, CIF, DDP, FCA
Port Of Loading:
Shenzhen, Shanghai, Guangzhou
Certificates:
Appearance patent certificate, CE, ISO24001, ISO45001, ISO9001, SGS
Product descriptions from the supplier
High Precision Laboratory Grade Offset Printing Ink Sampling Machine
Use and Specification:
Applicable objects: monochrome proofing (such as color matching, testing, etc.)
Input power: 220V, 50/60HZ
Power: 400W
Ink way: drip ink
Thickness of proofing material: 0.01-2mm (bendable material)
Proofing material size: 170x220mm
Printing area: 117x138mm
Plate area: 150x170mm
Plate thickness: USA Dupont 1.7mm thick flexible plate back glue 0.3mm
Pressure of plate roller and anilox roller: adjustable by 2mm, with scale to show pressure
Plate roller and embossing pressure: adjustable by 2mm, with scale to show the pressure
Printing speed adjustable: 0-120 m/min
Specification of ceramic roller:USA φ70x210mm
Lines number of ceramic roller: standard one 600LPI (70-1200 lines can be customized) BCM:1.6-5.3
Applicable ink: flexographic waterborne, UV ink, lithography, relief ordinary or UV ink
Suitable proofing materials: paper, plastic film, non - woven fabric, napkin, gold and silver paper jam, etc
External dimensions (length x width x height) : 450x800x240mm
Net weight: 110KG
UV curing device selection
The instrument can be coated, solid color, dot pattern proofing
Specification :
| 1.BCM:2.0 2.Ink hole carving Angle:60° 3.ink cavity shape:Regular hexagon openings 4.Anilox roller wire Angle:45° 5.Number of anilox roller lines:600LPI 6.anilox roller concentric to beat:within 0.01mm |
Unique features of the instrument:
1. After the ceramic roller rotates the ink evenly, the printing material and plate cylinder start up and rotate for one week to complete the proofing work. The ceramic roller and the printing material cylinder synchronize with the printing plate cylinder to ensure the quality of proofing.
2. The four structures of scraper, ceramic roller, plate roller and printing material roller can adjust the pressure separately and adjust flexibly.
3. Net roller, scraper disassembly and installation is simple and convenient
4. Large cylinder structure is adopted to install printing materials, easy to install printing plate and clean printing plate.
Our service:
During the whole business process, we offer Consultative Selling service.
1)Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm.
Then quote the most suitable price according to customer requirements.
2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.
3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show the production process.
After finishing production, offer photos to the customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products is confirmed shipping time and inform the customer.
4)Installation and after-sale service:
Defines installing those products in the field and providing after-sales support.
FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional Manufacturers like Environmental Chambers, Leather shoe testing equipment, Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 months warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What about the delivery term?
For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
If there is no stock, normally, the delivery time is 15-20 working days after payment received;
If you are in urgent need, we will make a special arrangement for you.
3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on site.
