High Precision Metal Slitting Machine Direct
1 Piece
$300,0001 Piece
$100,000Product information
High-quality High Precision Metal Slitting Machine Direct supplied by JIANGSU NEW VICTOR INDUSTRIAL CO., LTD.. Bulk wholesale pricing ranges from $100,000 to $300,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Decoiler Main Shaft And 4 PCS Leaves:
#55 Steel, Both Are Forged Cast Steel
Warranty:
12 Months
Specification:
3.0*1650Smm
HS Code:
3215966637
Production Capacity::
60m/Min
Decoiler Main Shaft And Seamless Drum:
All Forged Cast Steel Include Wedge
Raw Material Choosing:
Bao Steel Plate
Classification:
Cloth Cutting Machine
Specifications
Decoiler Main Shaft And 4 PCS Leaves:
#55 Steel, Both Are Forged Cast Steel
Warranty:
12 Months
Specification:
3.0*1650Smm
HS Code:
3215966637
Production Capacity::
60m/Min
Decoiler Main Shaft And Seamless Drum:
All Forged Cast Steel Include Wedge
Raw Material Choosing:
Bao Steel Plate
Classification:
Cloth Cutting Machine
Structure:
Cutting Part
After Sales Service:
Door-to-Doorinstallation
Coil Car Surranding Safety Protection:
Equipment Is Equipped with a Fall Protection Cover
Work Method:
Extrusion Slitting
Trade Term:
FOB, CIF
Slitter Shaft:
Forged 42CrMo, Slit Bearing Only NSK Brand
Slitter Rail Cover, Transimision:
Has Rail Cover to Protect Rail Scratch
Decoiler Auto Greasing System:
Has Separate Auto Pump Greasing for Decoiler
Slitter Strips Support Rack:
Has Strips Support Rack, Help Feeding Strip
Type:
High-Speed Slitting Machine
Origin:
Jiangsu, China
Payment Terms::
L/C, T/T, D/P, Western Union, Paypal, Money Gram
Payment Term:
LC, T/T
Application:
Machinery&Hardware
Trademark:
New Victor
Decoiler Main Shaft Copper Paste:
Paste Copper Plate on The Sliding Wedge Area
Model NO.:
QSS QSL
One Key Auto Feeding Coil To Decoiler Sh:
Sensor in Decoiler Arm
Port::
Shanghai, China
Applicable Process:
Slitting
Suitable Substrates:
Steel
Slitter Side Houser:
T600 Cast Steel Body, Good for High Duty Running
Decoiler Structure And Gear Box:
Use Heavy Frame, and Gear Box Type Transmission
First Loop Bridge:
Use Lift Type Table, The Table Cover with Bakelite
Slitter Lift Device:
Use Specical Gear Bar
Transport Package:
Wood
Packaging:
Wood
Packaging Material:
Wood
Decoiler Drum Wedge Support:
for 1250/1300 Line, We Have 5 Set of Support Wedge
Port Of Loading:
shanghai port
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2000-01-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF
Port Of Loading:
shanghai port
Certificates:
CE CERTIFICATE, ISO CERTIFICATE, SGS CERTIFICATE
Product descriptions from the supplier
Product Description
High Precision Metal Slitting Machine Direct
Product Description
QSS-3.0×1650SMM SLITTING LINE (DOUBLE SLITTER)
QSS-3.0-1350MM SLITTING LINE (WITH BELT BRIDLE)
THICK PLATE SLITTING MACHINE
Features
| our | others | |
| Raw material choosing | Bao steel plate | small steel factory defective steel plate |
| Coil car surranding safety protection | equipment with protection cover to anti-fall | have big pit, operator fall if carelessness or wrong walking |
| One key auto feeding coil to decoiler shaft | sensor in decoiler arm | no sensor in decoiler |
| Decoiler structure and gear box | use heavy frame, and gear box type transmission | use chain type transmission and light frame |
| Decoiler auto greasing system | has separate auto pump greasing for decoiler | not have |
| Decoiler main shaft and 4 PCS leaves | 35CrMo 4 PCS leaves: #55 steel, both are forged cast steel | 40Cr, 4 PCS leaves: #45 steel, both are normal casting material, no forged |
| Decoiler main shaft copper paste | paste copper plate on the sliding wedge area to acheive longer life and less wear | don't paste any copper on the sliding wedge area |
| Decoiler main shaft and seamless drum | all forged cast steel include wedge, fix copper plate on moving area, drum are seamless to protect thin material no mark | weld wedge, no copper in touch area, drum are big gap easy to bring mark for thin material |
| Decoiler drum wedge support | for 1250/1300 line, we have 5 set of support wedge, For 1500/1600 line we have 6 sets of support wedge | for 1250/1300 line, have 3 set of support wedge, For 1500/1600 line we have 4 sets of support wedge |
| First loop bridge | use lift type table, the table cover with bakelite plate and Dynamically balanced rubber wheel, if strips head fall down, just lift the table, all strips are coming up, no need risk of labors come down to the pit | use cylinder type, the table cover with steel roller and no Dynamically balanced, if strips head fall down, need operator going down to the pit to take out manualy, very risky of this jobwork |
| Slitter shaft | Forged 42CrMo, slit bearing only NSK brand | 40Cr or 42CrMo, slit bearing use Chinese brand mostly |
| Slitter side houser | T600 cast steel body, Very good for high duty running and high thickness material | normal steel(Q235) welding. strength not stable and durable for high speed running (More than 100m/min) |
| Slitter strips support rack | has strips support rack, help feeding strip to slitter head | does not, need manually feeding strip to slitter head |
| Slitter rail cover, transimision | has rail cover to protect rail scratch or damage Shaft housing out by motor, no need worry about oil leakage if by hydro cylinder | use manual or hydro cylinder type, hdyro cylinder worry about cylinder bar damage or scratch, also leakage will stop the line running |
| Slitter shaft housing | use full body casting T600 material, it is more stable and stronger in high speed to ache ive less burr and less shaft run-out | use weld type, the frame strength much more weaker than casting type. in high speed running, big vibration , big burr, and high run-out |
| Slitter lift device | use specical gear bar and copper gear | use steel bar and steel gear, strength is much lower than copper gear, heavy duty machine must use copper |
| Scrap winder | baller type and suspension type, Baller type easy winding even edge broken down, it can works well without stop line. Suspension type save space, also far away from operator working area, safe for their working | use chain type, week body and need operator remove edge coil out by hands, scrape are sharp, easy to get hurt |
| Tensioner | use heavy frame with first support lift, press arm lift, another two are separate shaft, four roller together easy for feeding, for wider line(width above 1600mm) we use 3 sets of hydro cylinder to give heavier strength and average pressure | use weak frame, feeding take long time due to less roller sets, operator have to stand in the loop bridge to feeding multi-strips by hands, dangers and risky |
| Recoiler | use 6 grade gear box ratio, have bigger start power and good protect the gearbox working life, gears through Gear grinding, gear hobbing, nitriding, working smooth and low noise | use 3 or 4 grade gear, need very higher motor drive, also has weak power, gear only through grinding, no other good heat treatment, big working noise |
| Recoiler main shaft and 4 PCS leaves | cast 35CrMo, 4 PCS leaves: #55 cast steel, both are forged cast steel | 40Cr, 4 PCS leaves: #45 steel, both material not cast material |
| Recoiler main shaft copper paste | paste copper plate on the sliding wedge area to acheive longer life and less wear | don't paste any copper on the sliding wedge area |
| Recoiler separate rack/arm | use frame type separate device, has heavier strength and more stable for high speed running separating | use cheap arm type, body are small square pipe weld frame, easy to deviation |
| Recoiler support arm | use full close swing type, has stronger frame, stable working and anti-vibration in high speed running | use light frame, some are lift type, some are close type, but only one side weld, strength not for durable working |
| Electric system | 1, One key for auto feeding coil to decoiler main shaft from coil saddle with laser sensor detecting support 2, use real-time monitoring control system, boss can see working condition from his laptop, set special screen for monitoring only 3, Full cabinet wire out from one interface 4, full line has 3 or 4 sets of camera to provide details to monitoring system 5, parts protection level is IP 54 | 1, manual hold the remote controller to feeding to decoiler main shaft 2, not has 3, lots of wire out from cabinet,if some one problem,they have to take long time to find out that broken wire 4, no camera support 5, parts protection level is IP 52 |
Company Profile
Jiangsu New VictorIndustrial Co., Ltd. is a machinery equipment manufacturing enterprise integrating product research and development, manufacturing, and domestic and international independent marketing. Stock abbreviation: Xinzeqi, stock code: 873713.
Over the years, the company has adhered to a strategy of leading technology, continuously researching and developing and improving products according to market demand. The company focuses on its core business, deeply cultivates the segmented market of company products, continuously improves product and service quality, and builds the company's brand. The company has established a research and development center, formed a professional technical research and development team, and purchased advanced metal processing equipment. The company has passed ISO9001 quality system certification, integration of two management systems certification, and CE certification for product export. The company owns more than 70 independent research and development product patents and adds new patents every year.
The company has been awarded honors such as "National Special New Small Giant Enterprise", "Jiangsu Province High-tech Enterprise", "Jiangsu Province Special New Small Giant Enterprise", "Jiangsu Private Technology Enterprise", "Jiangsu Enterprise Technology Center", "China Textile Industry Association Special New Small Giant Enterprise", "Suzhou Gazelle Plan Candidate Enterprise", "Zhangjiagang Harmonious Labor Relations Enterprise", "Zhangjiagang Civilized Unit", etc. In addition to selling products in the domestic market, the company also exports to Eastern Europe, Africa, the Middle East, Southeast Asia, South America, and other countries.
Metal processing machinery equipment, mainly: VZH16-273 series high-frequency precision welded pipe unit, VTL-10 -25 copper-clad aluminum/steel bimetallic processing equipment can produce copper-clad aluminum, copper-clad steel, and other composite metal wires, which can be applied in the fields of high-frequency signal lines, composite wires, etc. The company's environmentally friendly and efficient copper-clad aluminum composite production line was awarded the National Torch Plan Project and Jiangsu Province High-tech Product in 2007.
After Sales Service
Pre-sale service
1. We can provide machine running videos for reference
2. We will recommend the most suitable equipment according to the needs of customers
3. We can provide the layout of the factory
4. We welcome customers to visit our factory, we can show you the running machine in China.
After-sales service
1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly
2.When you finish the Preparation conditions, Our fast and professional aftersales service engineer team will go to your factory
to install the machine, give you the operating manual, And train your employee until they can operate the machine well.
3.We provide one year warranty and life-long technical support.
4.Well-trained & experienced staff are to answer all your inquiries in English and Chinese
5 .24 hours for engineer response.
6.Your business relationship with us will be confidential to any third party.
7. We offer one year's supply of spare parts free of charge
Quality Control
We have the single quality department, that make sure the material of the raw materials is good, and ensure the machine running smoothly.
FAQ
Are you a trading company or a manufactory?
We are a manufactory with 30 years experience, we supply the factory price with good quality, welcome to visit !
Do you have reference project?
We have reference project in most countries, If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory. And you are always welcome to come to visit our company, and see the machine running in our factory, we can pick you up from the station near our city. Contact our foreign sale team you can get video of our reference running machine.
Do you provide turnkey project?
Turnkey project available We can help you to start a new company in steel tube making.
Do you have agent and after-service stations?
So far we have agent in the middle east, Ethiopia, Singapore, South America. welcome to join us!
When can I get my machine after I paid?
Normally production time is around 60~90days, the exactly depend on what kind of machine you order. The shipping time is based on your destination port.
When can i get engineers from you?
When you finish the Preparation conditions(water resource, electricity, air supply, production materials)contact with our sales people we will dispatch engineer to install the machine for you ,and train your employees to use the machine well. Normally when your preparation is done, you can contact with our sales people and cooperate us to get the visa for the engineer and our engineer will be there within 15 days.
How long time for installation?
According your machines order, we will send one or two engineers to your plant, it will take about 10 days to 25 days.
How about the spare parts?
We will send one year enough easy broken spare parts together with the machines, shipping together.
Do you have any certificate?
We have CE, ISO, SGS certification
Do you provide customized service?
We can design the machines according your requirements.
What's your guarantee or the warranty of the quality if we buy your machines?
We offer you high quality machines with 1 year guarantee and supply life-long technical support.
