High-Quality DN40 Flow Sensor Water Meter for Heating Systems
1-9 Piece
$35510-99 Piece
$320100 Piece
$220Product information
High-quality High-Quality DN40 Flow Sensor Water Meter for Heating Systems supplied by Hangzhou Pangu Automation System Co., Ltd. Bulk wholesale pricing ranges from $220 to $355 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Accuracy:
+1.0%or+0.2%
RATED POWER:
-20°C~60°C
SIGNAL ACCURACY:
0.5%
Package Gross Weight:
10.500kg
RANGE RATIO:
10:1
EXCITING CURRENT:
180mA
EXCITING FREQUENCY:
25Hz
CABLE LENGTH:
30m
Specifications
Accuracy:
+1.0%or+0.2%
RATED POWER:
-20°C~60°C
SIGNAL ACCURACY:
0.5%
Package Gross Weight:
10.500kg
RANGE RATIO:
10:1
EXCITING CURRENT:
180mA
EXCITING FREQUENCY:
25Hz
CABLE LENGTH:
30m
HS Code:
3301969
Package Size:
484.00cm * 342.00cm * 292.00cm
FLOW OUTPUT:
4~20mA, Freg, Pulse
Production Capacity:
50000
WORKINGVOLTAGEWORKINGVOLTAGE:
AC220V/DC24V
Certification:
CE, ISO
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Measurement Object:
Closed Pipeline
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Specification:
DN20-DN300
Size:
DN20-DN300
Measuring Principle:
Electrical Principles
Type:
Electromagnetic Flow Meter
Trade Term:
FOB, CFR, CIF, EXW
COMMUNICATION PROTOCOL:
Hart, Modbus, Bluetooth
INSTALLATION POSITiON:
Incorporate;separate wallhanging
Application:
Industrial Production
Payment Term:
LC, T/T, PayPal, D/P, Western Union, Small-amount payment
DISPLAY:
LCD,128x64
OPERATE:
Mechanical keying
Trademark:
PANGU
Application Scenario/Field:
Printing and dyeing, canning, the chemical industr
Port Of Loading:
Shanghai Port, Ningbo Port
Transport Package:
Standard Package
Payment Methods:
Support payments in USD
Sensor:
Tube/Flange
Main Application:
Water, Wastewater, Printing and dyeing, canning, the chemical industr
Origin:
Zhejiang
COIL PARAMETER:
inductance≤200mH,resistance40~90Q
Measuring Media:
water,wastewater
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2001-02-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
47
Preferred Payment Term:
LC, T/T, PayPal, D/P, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CFR, CIF, EXW
Port Of Loading:
Shanghai Port, Ningbo Port
Certificates:
ISO45001:2018, ISO9001:2015
Product descriptions from the supplier
The electromagnetic flowmeter is a velocity-type flowmeter with high precision and high reliability, which is widely used in industries such as petroleum, chemical engineering, iron and steel, food, electric power, papermaking, water treatment, water supply, heating, and environmental protection.
The electromagnetic flowmeter consists of two parts: the sensor and the converter. The sensor is composed of parts such as the measuring tube, electrodes, exciting coils, iron core, and housing. After amplifying, processing, and calculating the flow signal, the converter can display the instantaneous flow and cumulative flow, and output signals such as pulses and analog currents, which are used for the measurement and control of fluid flow. The PMF series of electromagnetic flowmeters uses intelligent converters, which not only have functions such as measurement and display, but also support functions such as remote data transmission, wireless remote control, and alarms.
The electromagnetic flowmeter consists of two parts: the sensor and the converter. The sensor is composed of parts such as the measuring tube, electrodes, exciting coils, iron core, and housing. After amplifying, processing, and calculating the flow signal, the converter can display the instantaneous flow and cumulative flow, and output signals such as pulses and analog currents, which are used for the measurement and control of fluid flow. The PMF series of electromagnetic flowmeters uses intelligent converters, which not only have functions such as measurement and display, but also support functions such as remote data transmission, wireless remote control, and alarms.
Pangu Automation of China is a national hightech enterprises,found in 2001, it has been focusing on the paperless recorder, flow totalizer, electromagnetic flowmeter, electromagnetic heat meters, controllers, vacuum gauges, differential scanning calorimetry design, manufacturing, as the main work of national standard paper recorder, the industry leader.Pangu has a composition by industry leader in professional, efficient R & D, manufacturing team, is one of the current domestic paperless recorderindustry's most influential companies.
The company has dozens of products related patents. Products have been widely used in petroleum, chemical, electric power, metallurgy, building materials, thermal power, food, pharmaceutical, environmental protection and municipal industry. English version of paperless recorder also exported to India,Pakistan, Malaysia, Turkey, Thailand, South Korea, Taiwan and other countries and regions.
Pangu has been committed to provide the best products to customers,let the Pangu manufacturing products become synonymous with excellent quality.
Q1: Could I visit your factory?
Sincerely invite you to visit our factory,Our factory and office are all in Hangzhou,Zhejiang.
Q2: Do you provide samples?
Yes,we have materials in stock to help you to get the samples as soon as we can.
Q3: How about the quality of the managements?
We have a complete quality control system , all of our products will be fully pre-inspection by QC departments before shipping to you . We have the certification of ISO,CE we could send the certification test of our company to you.
Q4: What is your payment method?
30% prepayment, 70% before shipment.
Q5: What is the warranty for your product?
Warranty: 18 months, Lifetime maintenance.
Q6: How soon can you arrange the production?
Once getting your product confirmation and receiving your payment, we will arrange the production immediately. For some products we have it in stock.
Q7: Could you provide me the shortest lead time?
For somre standard products we have it in stock . Pls tell me your detailed requirements, we will send to you as early as we can.
