High Quality Multifunctional Vertical Horizontal Drilling and Milling Machine
Set
Negotiable
Product information
High-quality High Quality Multifunctional Vertical Horizontal Drilling and Milling Machine supplied by Tangshan Qiangfeng Machinery Manufacturing Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
1000
Specification:
4800x2110x2100
Automatic Grade:
Automatic
Certification:
CE
Controlling Mode:
CNC
CNC Or Not:
CNC
Origin:
China
Trade Term:
FOB, CIF
Specifications
Production Capacity:
1000
Specification:
4800x2110x2100
Automatic Grade:
Automatic
Certification:
CE
Controlling Mode:
CNC
CNC Or Not:
CNC
Origin:
China
Trade Term:
FOB, CIF
Structure:
Flat
Object:
Hardware
Precision:
High Precision
Precisions:
High Precision Universal Milling Machine
Milling Cutter Structure:
Indexable Type
Payment Term:
LC, T/T
Product Name:
Metal Milling Machine
Transport Package:
Plywood Case
Trademark:
Qiangfeng
Machine Type:
Universal
Milling Cutter Type:
Vertical Milling Cutter
Keyword:
Vertical Turret Milling Machine
Model NO.:
X6140
Port Of Loading:
tianjin
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2021-04-12
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF
Port Of Loading:
tianjin
Product descriptions from the supplier
High Precision Second-Hand Milling Machine
This machine is widely used in electrical equipment, Instrument apparatus industry, Cars, Motorcycle parts, Fastener bearing, Photographic equipment, movie mechanical, hardware various clocks and watches The glasses, Stationery,electric machinery, Valves,Gas pipe fittings and other high precision machining and manufacturing of complex parts, Is a hardware machinery processing industry the most ideal efficient equipment. Is a hardware machinery processing industry the most ideal efficient equipment.
Milling machine application:
The milling machine is a kind of universal light duty metal cutting machine,Has two functions of vertical and horizontal milling,
Milling medium, small parts of the plane, inclined plane, groove and spline etc.. Widely used in mechanical processing, mold,
equipment, instrumentation and other industries.
|
Specifications
|
Units
|
4HW
|
5HW
|
|
Table size
|
mm
|
1270x254
|
1370x305
|
|
Table travel
|
mm
|
780/420/400
|
810/420/400
|
|
T slot(number-width-pitch)
|
mm
|
3-16-65
|
3-16-65
|
|
Spindle taper
|
|
(V) R8/ISO40
(H) ISO40 |
(V) R8/ISO40
(H) ISO40 |
|
Spindle speed range
|
rpm
|
(V) 50HZ:65-4500 60HZ:80-5440 (16 steps)
(H) 45-1350(12steps) |
|
|
|
|
Optional(variable)65-4000
|
|
|
Spindle travel
|
mm
|
127
|
127
|
|
Spindle feed range
|
mm
|
0.04,0.08,0.15
(3 steps) |
0.04,0.08,0.15
(3 steps) |
|
Distance between spindle axis and table surface
|
mm
|
0-400
|
0-400
|
|
Main motor power
|
kw
|
2.2(V)3(H)
|
2.2(V)3(H)
|
|
Head rotation (left - right )
|
°
|
±90°
|
±90°
|
|
Head rotation (front - rear)
|
°
|
±45°
|
±45°
|
|
Weight
|
kg
|
1750
|
1850
|
|
Overall dimension
|
mm
|
1550x1650x2250
|
1550x1650x2250
|
|
Single milers package
|
mm
|
1566x1650x2080
|
1566x1650x2080
|
|
Two milers package
|
mm
|
1720x1800x2175
|
1720x1800x2175
|
|
Weight
|
kg
|
1600
|
1650
|
Tangshan Qiangfeng Machinery Manufacturing Co., Ltd. has carved a niche by specializing in high-quality used machine tools and construction machinery, combining professional expertise with a customer-first philosophy to serve diverse industrial needs.
The company's primary focus lies in two key product categories, each tailored to address specific industry requirements:
Used Machine Tools: This includes a wide range of pre-owned CNC lathes, milling machines, grinders, and drilling equipment sourced from reputable manufacturers such as Haas, FANUC, and SCM. These machines undergo rigorous inspections and refurbishment processes to ensure they operate at 90%+ of their original performance levels. Target clients include automotive part manufacturers, metal processing workshops, and precision engineering firms seeking to expand production capacity without incurring the high costs of new machinery.
Used Construction Machinery: The portfolio here features second-hand excavators, loaders, bulldozers, and concrete pumps from leading brands like SA NY. These units are particularly popular among construction contractors, infrastructure developers, and rural construction teams. Each piece of equipment is evaluated for structural integrity, engine performance, and safety compliance before being listed for sale.
In addition to sales, the company offers value-added services such as equipment maintenance, spare parts supply, and technical consultations, ensuring clients receive end-to-end support throughout the machinery lifecycle.
Why Choose Us pose Us?
Customized service
CNC equipment can be customized according to customer requirements.
Delivery principle
on-time delivery and real-time update of production equipment progress service.
Pre-sales service
responsible for pre-sales technical consultation, product recommendation and selection, process solution discussion, etc.
Overhaul service
overhaul and renovation of machine tools, project repair, CNC system upgrade and technical service business.
Customized service
CNC equipment can be customized according to customer requirements.
Delivery principle
on-time delivery and real-time update of production equipment progress service.
Pre-sales service
responsible for pre-sales technical consultation, product recommendation and selection, process solution discussion, etc.
Overhaul service
overhaul and renovation of machine tools, project repair, CNC system upgrade and technical service business.
Q1. Are you a trade company or manufacturing company?
We are a manufacturing company.
Q2. What's your main products of your company?
We specialized in all kinds of machines, such as CNC Lathe, CNC Milling Machine, Vertical Machining Center,Conventional Lathe, Drilling Machine, Radial Drilling Machine, and so on.
Q3. Can you provide customized machine or SPM (Special purpose machine)?
Yes, we provide Smart CNC solutions for our customer in order to increase efficiency.
Q4: What's your warranty terms?
We will supply a replacement for parts that prove to be defective for a period of 12 months,
starting on the machine's bill of lading date.
Q5. What is the services?
Pr-sales:Customized solutions, planning and design;One-to-one service
After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
Q6: Why choose your company?
Products from the development, design, manufacture, assembly of the entire production process are
carried out between plants with a complete production chain which is your most reliable guarantee.
Q7: Can your company send the technical personnel to our company and direct our workers overseas?
We can supply this kind of service. When the machines arrive the buyer's installation site, we can timely send mechanical and electrical engineers to install according to the buyer's schedule. All these can be quoted and list in the contract. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
Q8: What's the Payment Terms?
T/T 30% initial payment when order, 70% balance payment before shipment. irrevocable letter ofcredit at sight
