High-Quality Quartz Sand for Superior Water Filtration Systems
100 Piece
$500Product information
High-quality High-Quality Quartz Sand for Superior Water Filtration Systems supplied by Shanghai Rui Tai Photoelectric Technology Co., Ltd.. Bulk wholesale pricing is $500 per Piece with a minimum order of 100 Piece. Inquiry for latest prices.
Package Size:
120.00cm * 120.00cm * 90.00cm
Package Gross Weight:
50.000kg
Production Capacity:
50000PCS/Year
HS Code:
84619090
Specification:
Based on size
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, CIF, CFR
Specifications
Package Size:
120.00cm * 120.00cm * 90.00cm
Package Gross Weight:
50.000kg
Production Capacity:
50000PCS/Year
HS Code:
84619090
Specification:
Based on size
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, CIF, CFR
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Origin:
Made in China
Model NO.:
RAY-SCQM-CL4929#
Trademark:
RAYTEK
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Transport Package:
Wooden
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2016-04-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
5
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Shanghai Port
Certificates:
ISO9001:2015
Product descriptions from the supplier
NC-200 series transparent quartz weights and products
Using the flaming method to produce the roundingot, through the furnace remelt the ingot to make the size bigger, quality better (few microbubbles and not concentrative, no tension ). According customer request process the ingotto plate/disc/flanges and so on.
NC-200 series produce are applied in semiconductor /solar/window disc/optical fiber.
Chemical element composition (Reference data)
ppm
Ingot, plate product size(mm):
(Transparent round ingot)
D150mmxH2000mm~D2000mmxH100-300mm;
(Transparent square ingot)
(max size)L2000mmxW2000mmxH300mm;
(Transparent polishing square plate)
L10mmxW10mmxT>0,5mm~L1200mmxW1200mmxT>2mm;
(Transparent rough square plate)
L10mmxW10mmxT>0.5mm~L1600mmxW1600mmxT>2mm;
(Transparent polishing disc)
( size) Dmax1600mmxT>2mm;
(Transparent rough disc)
( size) Dmax2000mmxT>50mm;
NC-W00 series opaque quartz weights and products
This series opaque quartz material uses the opaque quartz sand, adopting the flame melting method to produce opaque quartz roundweights, which are further processed for opaque quartz rounds, squares, fanges andspecial shaped products. These products have good heat insulation and temperatureresistance, which are mainlyused in semiconductor processing of heat insulationaccessories.
Chemical element composition (Reference data)
ppm
Transmission (Reference data T10mm)
Density (Reference data) : >2.0g/cm2
NC-H00 series low hydroxyl transparent quartz weights and products
Low OH quartz. We make big size quartz ingot with the low OH content by electricalmethod,to process quartz disc, square plate, flange and special shape products. lt hasgood transmission during infrared band, Now the max size 600mm.
Chemical element composition (Reference data)
ppm
Properties(Reference data)
NC-S00 series high-purity quartz sand
Quartz sand is divided into high purity natural quartz sand and ultra-high purity syntheticquartz sand.
The purity of high purity natural quartz sand can reach 99.998%, which is mainly used forthe production of the middle and outer layers of quartz crucibles, serving the fields osemiconductor and photovoltaic. The purity of synthetic quartz sand can reach 99.9999%which is mainly used for the production of full-wave transmitance quartz glass and theinner layers of high-end quartz crucibles, serving the fields of integrated circuit, advanced optics and military industry.
Chemical element composition (Reference data)
ppm
---------------------------------------------------------------------------------------------------------------------------------------
Transparent quartz glass properties
Opaque quartz glass properties
Using the flaming method to produce the roundingot, through the furnace remelt the ingot to make the size bigger, quality better (few microbubbles and not concentrative, no tension ). According customer request process the ingotto plate/disc/flanges and so on.
NC-200 series produce are applied in semiconductor /solar/window disc/optical fiber.
Chemical element composition (Reference data)
ppm
| Series | Al | Fe | Ca | Mg | Ti | Cu | B | K | Na | Li | OH |
| NC-200 | 18.00 | 0.40 | 0.50 | 0.05 | 1.15 | 0.01 | 0.20 | 0.80 | 0.90 | 1.20 | 120~260 |
| NC-210 | 15.00 | 0.20 | 0.40 | 0.05 | 1.20 | 0.02 | 0.10 | 0.60 | 0.80 | 0.40 | 120~200 |
Ingot, plate product size(mm):
(Transparent round ingot)
D150mmxH2000mm~D2000mmxH100-300mm;
(Transparent square ingot)
(max size)L2000mmxW2000mmxH300mm;
(Transparent polishing square plate)
L10mmxW10mmxT>0,5mm~L1200mmxW1200mmxT>2mm;
(Transparent rough square plate)
L10mmxW10mmxT>0.5mm~L1600mmxW1600mmxT>2mm;
(Transparent polishing disc)
( size) Dmax1600mmxT>2mm;
(Transparent rough disc)
( size) Dmax2000mmxT>50mm;
NC-W00 series opaque quartz weights and products
This series opaque quartz material uses the opaque quartz sand, adopting the flame melting method to produce opaque quartz roundweights, which are further processed for opaque quartz rounds, squares, fanges andspecial shaped products. These products have good heat insulation and temperatureresistance, which are mainlyused in semiconductor processing of heat insulationaccessories.
Chemical element composition (Reference data)
ppm
| Series | Al | Fe | Ca | Mg | Cu | K | Na | Li |
| NC-W00 | 25.00 | 0.50 | 0.80 | 0.10 | 0.10 | 1.60 | 2.20 | 0.30 |
Transmission (Reference data T10mm)
| Wavelength(nm) | 400 | 500 | 600 | 700 |
| Transmission | 1.0% | 1.2% | 1.2% | 1.2% |
Density (Reference data) : >2.0g/cm2
NC-H00 series low hydroxyl transparent quartz weights and products
Low OH quartz. We make big size quartz ingot with the low OH content by electricalmethod,to process quartz disc, square plate, flange and special shape products. lt hasgood transmission during infrared band, Now the max size 600mm.
Chemical element composition (Reference data)
ppm
| Series | Al | Fe | Ca | Mg | Ti | Cu | B | K | Na | Li | OH |
| NC-H00 | 14.00 | 0.40 | 0.50 | 0.05 | 1.20 | 0.01 | 0.10 | 0.35 | 0.70 | 0.80 | <5 |
| NC-H01 | 8.00 | 0.20 | 0.70 | 0.04 | 1.20 | 0.01 | 0.10 | 0.20 | 0.60 | 0.50 | <5 |
Properties(Reference data)
| Series | Bubbles mm | Homoge neity *10-6 | Striae | Birefringence nm/cm |
| NC-H00/101 | <0.1 | <15 | 1D | <15 |
NC-S00 series high-purity quartz sand
Quartz sand is divided into high purity natural quartz sand and ultra-high purity syntheticquartz sand.
The purity of high purity natural quartz sand can reach 99.998%, which is mainly used forthe production of the middle and outer layers of quartz crucibles, serving the fields osemiconductor and photovoltaic. The purity of synthetic quartz sand can reach 99.9999%which is mainly used for the production of full-wave transmitance quartz glass and theinner layers of high-end quartz crucibles, serving the fields of integrated circuit, advanced optics and military industry.
Chemical element composition (Reference data)
ppm
| Series | Al | Fe | Ca | Mg | Ti | Cu | B | K | Na | Li | Mn | Ni | Co | Total |
| NC-S00 | 18.50 | 0.60 | 0.50 | 0.05 | 1.15 | 0.01 | 0.20 | 1.50 | 2.00 | 1.50 | 0.01 | 0.02 | 0.01 | 26.05 |
| NC-S01 | 14.00 | 0.59 | 1.00 | 0.15 | 0.79 | 0.22 | 0.06 | 0.70 | 1.50 | 0.80 | 0.01 | 0.02 | 0.01 | 19.85 |
| NC-S02 | 13.20 | 0.59 | 0.80 | 0.15 | 0.79 | 0.22 | 0.06 | 0.70 | 1.50 | 0.80 | 0.01 | 0.02 | 0.01 | 18.85 |
| NC-S10 | 0.07 | 0.11 | 0.02 | 0.01 | 0.01 | 0.01 | 0.01 | 0.03 | 0.03 | 0.01 | 0.01 | 0.01 | 0.01 | 0.34 |
---------------------------------------------------------------------------------------------------------------------------------------
Transparent quartz glass properties
| Property | NC-100 | NC-110 | NC-200 | NC-300 / NC-H00 |
| Density g/cm2 | 2.20 | 2.20 | 2.21 | 2.22 |
| Hardness KHN100 | 570 | 580 | 580 | 585 |
| Tensile *107Pa(N/m2) | 4.8 | 4.9 | 4.9 | 5.0 |
| Compression *109Pa | 1.1 | 1.1 | 1.1 | 1.1 |
| CTE(20-300ºC) *10-7/ºC | 5.5 | 5.5 | 5.5 | 5.5 |
| Thermal Conductivity(20ºC) W/mºC | 1.4 | 1.4 | 1.4 | 1.4 |
| Specific Heat(20ºC) J/kgºC | 660 | 670 | 680 | 680 |
| Softening Point ºC | 1630 | 1680 | 1690 | 1700 |
| Annealing Point ºC | 1180 | 1215 | 1210 | 1220 |
Opaque quartz glass properties
| Series | Density | Compression | CTE(20-300ºC) | Thermal Conductivity | Specific Heat | Softening Point | Annealing Point |
| NC-U300 NC-U400 |
1.95g/cm3 | >1.0*109Pa | 5.4*10-7/ºC | 1.1W/ºC.m | 650J/kgºC | 1600ºC | 1100ºC |
Our transparent quartz materials have excellent transmittance, especially in the infraredand visible wavelengths. Transmittance in the UV is related to metal impurities and theabsorption peak at 2730nm indicates OH content.
