High Rigid 4 Axis Metal Universal Milling Machinery CNC Boring and Milling Machines
1-2 Piece
$59,9993 Piece
$53,999Product information
High-quality High Rigid 4 Axis Metal Universal Milling Machinery CNC Boring and Milling Machines supplied by Henan Rowdai Machinery Equipment Co., Ltd.. Bulk wholesale pricing ranges from $53,999 to $59,999 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Headbox Travel Y Axis:
1000mm~1800mm
Table Horizontal Travel Z Axis:
1000mm~2000mm
Max.Torque Of Facing Slide:
12250n
Max.Torque Of Spindle:
1225n.M
Speed Number Of Radial Facing Slide:
18
Spindle Speed Level:
22
Max.Permissible Load Of Table:
2500kg
Production Capacity:
600/Pieces
Specifications
Headbox Travel Y Axis:
1000mm~1800mm
Table Horizontal Travel Z Axis:
1000mm~2000mm
Max.Torque Of Facing Slide:
12250n
Max.Torque Of Spindle:
1225n.M
Speed Number Of Radial Facing Slide:
18
Spindle Speed Level:
22
Max.Permissible Load Of Table:
2500kg
Production Capacity:
600/Pieces
Main Motor Power:
7.5kw
HS Code:
8459410000
Transverse Travel Of Worktablel X Axis:
900mm~2000mm
Worktable Size:
960mm*1100mm
Automatic Grade:
Automatic
Controlling Mode:
CNC
Origin:
China
Trade Term:
FOB, CIF, CFR, EXW
Tool Type:
Fine Knife/Crude Knife
Certification:
GS, CE, ISO 9001
Precision:
High Precision
Structure:
Horizontal Boring Machine
Coordinate Boring Machine Type:
Horizontal Type
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Condition:
New
Port Of Loading:
Qingdao Port
Trademark:
Rowdai
Model NO.:
TPX611
Transport Package:
Transport Package
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2022-06-30
Annual Revenue Amount:
Not specified
Numbers Of Employees:
8
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Qingdao Port
Certificates:
CE
Product descriptions from the supplier
High quality Heavy duty CNC boring and milling machine Metal processing milling and boring machine
By using a CNC boring machine and a CNC milling machine, you can work on large and heavy workpieces such as nachine beds, frames and housings in a particularly economic way. In just one set-up, lowering, turning, milling and drilling operations can be carried out on four sides. The modern CNC control with servo-axis drives is easy to program and allows to create complex contours and hole patterns.The table with long travels simplifies handling and can optionally be replaced by a controlled positionable rotary table.
This series ofhorizontal boring machines are optimized on the basis of tra ditional boring machines. The machine tool performs drilling, reaming boring,reaming,milling and threading under the condition of a fixture.At the same time the horizontal boring machine series are eguipped with a rotating plane rotating disc and the flat rotating disc enters radially when the slider rotates, and can cutlarge-sized boring holes, turning circles planes, and cutting.
| Model/Specifications | Units | TPX6111B | TPX6111B/2 | TPX6111B/3 |
| Spindle diameter | mm | 110 | ||
| Spindle taper | Morse 6 (ISO 7:24 No50) | |||
| Spindle speed level | steps | 22 | ||
| Spindle speed | r/min | 8~1000 | ||
| Facing head diameter | mm | 600 | ||
| Max.torque of spindle | N.m | 1225 | ||
| Max.torque of facing slide | N | 12250 | ||
| Max travel of spindle | mm | 600 | ||
| Max travel of radial facing slide | mm | 180 | ||
| Max.permissible load of table | Kg | 2500 | 3000 | 3000 |
| Speed number of radial facing slide | steps | 18 | ||
| Speed range of radial facing slide | r/min | 4~200 | ||
| Rapid traverse speed of pindle.headstock. cross & longitudinal saddles | mm/min | 2500 | ||
| Worktable Size | mm | 960*1100 | 1200*1400 | 1300*1600 |
| Worktable rotation angle | ° | 360° | ||
| Transverse travel of worktablel--X axis | mm | 900 | 1250 | 1600 |
| headbox travel--Y axis | mm | 1000 | 1100 | 1300 |
| Table Horizontal travel--Z axis | mm | 1000 | 1000 | 1400 |
| Main motor power | Kw | 7.5 | ||
| Weight | Kg | 13000 | 14500 | 17000 |
| Model/Specifications | Units | TPX6113 | TPX6113/2 |
| Spindle diameter | mm | 130 | |
| Spindle taper | Metnc 80 (ISO 7:24) | ||
| Spindle speed level | steps | 24 | |
| Spindle speed | r/min | 4~800 | |
| Facing head diameter | mm | 800 | |
| Max.torque of spindle | N.m | 3136 | |
| Max.torque of facing slide | N | 31360 | |
| Max travel of spindle | mm | 900 | |
| Max travel of radial facing slide | mm | 250 | |
| Max.permissible load of table | Kg | 7000 | 8000 |
| Speed number of radial facing slide | steps | 18 | |
| Speed range of radial facing slide | r/min | 2.5~125 | |
| Rapid traverse speed of pindle.headstock. cross & longitudinal saddles | mm/min | 2500 | |
| Worktable Size | mm | 1400*1600 | 1600*1800 |
| Worktable rotation angle | ° | 360° | |
| Transverse travel of worktablel--X axis | mm | 2000 | 2000 |
| headbox travel--Y axis | mm | 1500 | 1800 |
| Table Horizontal travel--Z axis | mm | 1800 | 2000 |
| Main motor power | Kw | 15 | |
| Weight | Kg | 25000 | 30000 |
Henan Rowdai Machinery Equipment Co., LTD
we are located in Zhengzhou city, Henan Province. We are specialized in the manufacture of CNC machine center, Lathe machine,CNC Lathe Machine, Milling Machine, CNC Milling Machine, Grinding Machine, Band Saw. Our products are widely used in the auto,mould,construction machinery, aviation, high speed railway and energy industry. We have our own share in many markets, and the products have been widely exported to Europe, America, Australia, Middle East, Southeast Asia, and Africa and so on.
Our workers are all have over 10 years working experience with Machine tools, we have professional inspector team, Focusing on addressing customers' needs, we aim at quality machines and perfect after-sales services to the customers.What we offer:
1) Good quality control
2) Highly competitive prices
3) state-of-art technology products
4) Best professional team of lifestyle consumer electronics.
5) Smooth communication
6) Effective OEM&ODM service
Our workers are all have over 10 years working experience with Machine tools, we have professional inspector team, Focusing on addressing customers' needs, we aim at quality machines and perfect after-sales services to the customers.What we offer:
1) Good quality control
2) Highly competitive prices
3) state-of-art technology products
4) Best professional team of lifestyle consumer electronics.
5) Smooth communication
6) Effective OEM&ODM service
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you choose the exact model . You can also send us the products drawing ,we will choose the most suitable machines for you .
2:What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Machining Center ,Grinding Machines,Milling Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: What about the quality of the machine?and after-sales service?
A : Our machine warranty period is 1 years,and we provide free technical service.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
