High-Speed Electronic Display Glass Cutter with CCD Vision
SET
Negotiable
Product information
High-quality High-Speed Electronic Display Glass Cutter with CCD Vision supplied by Luoyang DISAI Mechanical Equipment Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
1000
Package Size:
1203.00cm * 350.00cm * 269.00cm
Power Supply:
380V 50Hz
Specification:
40HQ
Package Gross Weight:
5000.000kg
HS Code:
8464901100
Origin:
China Luoyang
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Production Capacity:
1000
Package Size:
1203.00cm * 350.00cm * 269.00cm
Power Supply:
380V 50Hz
Specification:
40HQ
Package Gross Weight:
5000.000kg
HS Code:
8464901100
Origin:
China Luoyang
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Transport Package:
Container
Trademark:
DISAI EQUIPMENT
Model NO.:
DS-CM4228
Safety Features:
Emergency Stop Button
Trade Term:
FOB, CIF, CFR, EXW
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Port Of Loading:
Qingdao Port
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2015-05-12
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Qingdao Port
Certificates:
CE
Product descriptions from the supplier
DISAI, striving for precision and adhering to quality
Focusing on the research and development and intelligent manufacturing of glass equipment, we strive to create high-quality products with our heart.
DISAI Automatic glass cutting line ,more than 30 processes are strictly controlled, with traceable quality throughout the entire process and high-quality equipment delivered
DISAI's exclusive bidirectional cutting mode:
Different from the unidirectional cutting mode, the bidirectional cutting mode can select theknife position nearby, thereby reducing the empty knife moving distance, improving cuttingefficiency, increasing output, and saving costs.
Different from the unidirectional cutting mode, the bidirectional cutting mode can select theknife position nearby, thereby reducing the empty knife moving distance, improving cuttingefficiency, increasing output, and saving costs.
Linear guide rail and motor direct drive (dual drive):
DISAI glass cutting machine adopts dual-drive linear guide rail and motor direct drive modeto replace the traditional belt drive mode, thereby reducing the transmission error caused by beltdrive and improving cutting efficiency and accuracy
DISAI glass cutting machine adopts dual-drive linear guide rail and motor direct drive modeto replace the traditional belt drive mode, thereby reducing the transmission error caused by beltdrive and improving cutting efficiency and accuracy
Industrial computer controller:
The biggest difference between EVOS industrial computers and ordinary computers is thehigh-intensity resistance to electromagnetic interference, excellent dustproof ability, hightemperature and low temperature resistance, which can be used for high-intensity work in glassfactories, improve service life, and reduce failure rate.
The biggest difference between EVOS industrial computers and ordinary computers is thehigh-intensity resistance to electromagnetic interference, excellent dustproof ability, hightemperature and low temperature resistance, which can be used for high-intensity work in glassfactories, improve service life, and reduce failure rate.
| DISAI automatic glass cutting machine model size | |||||
| Models | Max Cutting .sheet | Cutting precision | Cutting thickness | Max Cutting. Speed | |
| DS-CM2621 | 2600×2100mm | ±0.15mm | 2-19mm | 200m/min | |
| DS-CM3725 | 3700×2500mm | ±0.15mm | 2-19mm | 200m/min | |
| DS-CM4228 | 4200×2800mm | ±0.20mm | 2-19mm | 200m/min | |
| DS-CM5133 | 5100×3300mm | ±0.25mm | 3-25mm | 200m/min | |
| DS-CM6133 | 6100×3300mm | ±0.25mm | 3-25mm | 200m/min | |
| DS-CM7537 | 7500×3700mm | ±0.25mm | 3-25mm | 200m/min | |
| DS-CM10037 | 10000×3700mm | ±0.30mm | 3-25mm | 200m/min | |
| DS-CM12037 | 12000×3300mm | ±0.30mm | 3-25mm | 200m/min | |
| DS-CM16037 | 16000×3300mm | ±0.30mm | 3-25mm | 200m/min | |
| DS-CM18033 | 18000×3300mm | ±0.30mm | 3-25mm | 200m/min | |
DISAI Equipment focuses on the research and development and manufacturing of high-end intelligent equipment for glass deep processing. The research and development team comes from well-known universities in China,and has honorary titles such as Luoyang Enterprise Research and Development Center,National High tech Enterprise,and Technological Small and Medium sized Enterprise. The products are exported to more than 80 countries and regions worldwide. DISAI high-end intelligent glass cutting machine,glass laser marking machine,glass raw material storage,ERP management system,intelligent chip management system,scanning code recognition and comparison system and other intelligent connected products make every piece of glass precise positioning,intelligent reading,reduce scratches,monitor the entire factory,making glass processing easier and glass quality more high-end.
DISAI Equipment is rooted in China and looking to the world. DISAI has always been committed to building a world-class high-end glass equipment brand. We always remember that quality is the foundation of DISAI′s survival,service is the soul of DISAI′s products,and quality and service are the reasons why customers choose DISAI
DISAI EQUIPMENT - Fully Automatic Glass Cutting Machine FAQ
1. What types of glass can your machine cut?
Our machines can cut float glass, Low-E glass, coated glass, mirror glass, and more - in thicknesses ranging from 2 mm to 25 mm. Edge deletion is available as an optional module.
2. What is the maximum sheet size it can handle?
We offer various models including jumbo-size tables. Our standard models handle up to 4200mm x 2800mm. Custom sizes are available upon request.
3. How accurate is the cutting?
Our cutting precision is ±0.15 mm, ensuring clean edges suitable for tempering, laminating, or IGU production.
4. Is the machine difficult to operate?
Not at all. The machine features a touchscreen interface, supports CAD/CAM files, and offers automatic nesting. We also provide full training for your team.
5. How long does installation and training take?
Standard installation takes 2-3 days, with training completed in 1-2 days. Our engineers are available both on-site and online.
6. What certifications does your equipment have?
All our machines are CE certified, and our factory is ISO 9001 certified. We also offer SGS inspection reports upon request.
7. What if the machine breaks down?
We provide 24/7 after-sales support, remote diagnostics, and fast shipping of parts. Most issues can be solved online within hours. Spare parts are always in stock.
8. Can I add more functions later?
Yes! Our system is modular. You can add components like edge deletion, barcode labelers, or automatic breaking tables as your needs grow.
9. What kind of return on investment (ROI) can I expect?
Our customers typically see ROI in 6-9 months, thanks to higher output, lower labor costs, and reduced glass waste from nesting.
10. Can I see the machine in action before buying?
Absolutely. We offer virtual demos, factory visits, and can even process your drawing to show real results.
