Hook Type Toroidal Coil Winding Machine



(SS200) semiautomatic toroid coil winding machine

Description of SS200 Hook type semiautomatic toroid coil winding machine :
SS-200 Hook type semiautomatic toroid coil winding machine is one simply semiautomatic winder which used for very thick wire of toroid coil, and very thick wire with big toroid core of coil.  Like as some big power factor corrector inductos, power inductors, UPS inductor, And wire insulation film can be protected in good.

The SS200 winder is customized by toroid coil of dimensions.

Featuresof SS200 Hook type semiautomatic toroid coil winding machine:
1. Easy to operate.
2. Need cut the required wire length before winding.

3. Easy to switch the winding fixture for different size core.
4. Operation with compressed air.
5. Spread wire by manual.

Specificationof SS200 Hook type semiautomatic toroid coil winding machine:
Wire diameter: 0.3 ~ 5.0mm
Min. finished coil inside diameter: 8mm (Will be different by hook size. )
Finished coil outside diameter: 25~300mm
Winding type: By Hook with the air compressor.
Air source: 0.7Mpa .

How to select the best suited automatic toroid coil winding machine for your toroid coil,

Tell us your toroidal coil of data as below please:

1, toroid coil outside diameter after winding?

2, toroid coil inside diameter after winding?

3, toroid coil height after winding?

4, the copper wire diameter ?
