Horizontal Paddle Type Dry Powder Mixing Equipment
Piece
Negotiable
Product information
High-quality Horizontal Paddle Type Dry Powder Mixing Equipment supplied by Shanghai Chemix Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Batch Mixing Time:
5-20 Minutes
Size:
50-20000L
Production Capacity:
500PCS/Year
HS Code:
8474
Explosion Proof:
Available
Heavy Duty:
Available
Heating Jacket:
Available
Working Model:
Batch Mixing But Not Continuous
Specifications
Batch Mixing Time:
5-20 Minutes
Size:
50-20000L
Production Capacity:
500PCS/Year
HS Code:
8474
Explosion Proof:
Available
Heavy Duty:
Available
Heating Jacket:
Available
Working Model:
Batch Mixing But Not Continuous
Certification:
CE, ISO, GOST, SONCAP, CCC
Specification:
CE, SGS, GMP
Model NO.:
CMPP
Trademark:
CMX
Application Area:
Chemical
Operating Type:
Cycle Operating
Working:
Diffusion Mixer
Mixing Drum Shape:
Drum
Trade Term:
FOB, EXW, CFR, CIF
Stirring Type:
Gravity
Layout Type:
Horizontal
Mixer Tank:
Horizontal & W-Shaped Tank
Mixer Type:
Horizontal Weightlessness Mixer
Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Main Shaft Rotation Speed:
Low Speed or High Speed
Condition:
New
Mixer Agitator Type:
Paddle Type
Origin:
Shanghai
Port Of Loading:
Shanghai, Ningbo, Yiwu
Construction Material:
Stainless Steel or Mild Steel
Transport Package:
Wooden Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2015-07-31
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, EXW, CFR, CIF
Port Of Loading:
Shanghai, Ningbo, Yiwu
Product descriptions from the supplier
horizontal Paddle Type Dry powder Mixing Equipment
Questions for Buyer:
Please answer below questions and send answers toemail, and then we will send you offer as soon as possible.
1 Working principle:
CMPP series horizontal double shaft paddle mixer consist of W-shaped tank, top cover with/without openings, reverse rotation double shaft equipped with paddles, transmission unit, support frame, sealing element, discharge structure and so on. For the reason that double shaft rotate at reverse direction and specific angled paddles make materials get blended in the axial and radial, materials get homogeneously mixed. Materials form fluidized bed during its own up-throwing movement and produce instant weightlessness, so this series of mixer is also called weightlessness mixer.
2 Performance & features:
2.01 Material: stainless steel 304 / 316L or mild steel Q235;
2.02 Surface treatment: paint (mild steel), polish/sandblasting (stainless steel);
2.03 Paddle agitator: of certain angle;
2.04 Mixer tank: horizontal, W-shaped tank;
2.05 Shaft: horizontal, hollow, integral twin shaft;
2.06 Mixing time: 5-20 minutes;
2.07 Working model: batch mixing;
2.08 Speed reducer: cycloid reducer;
2.09 Rotation speed: fixed speed;
2.10 Main shaft seal: (Teflon) stuffing seal or air purge seal;
2.11 Openings: feeding inlet, manhole, and inspection door & connection port;
2.12 Discharge valve: pneumatic or manual/ flap or cylindrical discharge valve;
2.13 Working condition: NPT (normal pressure and temperature);
2.14 Not heavy duty: mixer can not be started with loading materials;
2.15 Power supply: 220V 50HZ single phase/ 380V 50HZ 3 phase;
2.16 Non ex-proof electronics (motor, electronic elements, control cabinet);
3 Optional features:
The following optional features are available: wear-resistant and anti-corrosion materials, surface treatment; continuous mixing; changeable speed; mechanical seal; customized openings and discharge valves; temperature control; pressure requirement; heavy-duty configuration; motors, electronic elements, electronic control panel are customized to different power and ex-proof requirements; light glass; sampling device; liquid spraying device; scrappers etc.
4 Technical specifications:
5 Mixers Album:
6 Application Industry:
7 Factory Album:
Questions for Buyer:
Please answer below questions and send answers toemail, and then we will send you offer as soon as possible.
| 1, What materials do you mix? (Names of raw materials?) 2, What is the power fineness (or particle size)? (mesh, mm) 3, What is the bulk density (or specific gravity) of mixed materials? (kg/liter, kg/m3) 4, How many kgs or liters to be mixed per batch? 5, What is the distance from bottom discharge outlet to ground? (cm, mm, m) 6, What construction materials do you require? (Please choose below option) A, all construction materials mild steel; B, contact parts stainless steel, non-contact parts mild steel; C, all construction materials stainless steel; |
1 Working principle:
CMPP series horizontal double shaft paddle mixer consist of W-shaped tank, top cover with/without openings, reverse rotation double shaft equipped with paddles, transmission unit, support frame, sealing element, discharge structure and so on. For the reason that double shaft rotate at reverse direction and specific angled paddles make materials get blended in the axial and radial, materials get homogeneously mixed. Materials form fluidized bed during its own up-throwing movement and produce instant weightlessness, so this series of mixer is also called weightlessness mixer.
2 Performance & features:
2.01 Material: stainless steel 304 / 316L or mild steel Q235;
2.02 Surface treatment: paint (mild steel), polish/sandblasting (stainless steel);
2.03 Paddle agitator: of certain angle;
2.04 Mixer tank: horizontal, W-shaped tank;
2.05 Shaft: horizontal, hollow, integral twin shaft;
2.06 Mixing time: 5-20 minutes;
2.07 Working model: batch mixing;
2.08 Speed reducer: cycloid reducer;
2.09 Rotation speed: fixed speed;
2.10 Main shaft seal: (Teflon) stuffing seal or air purge seal;
2.11 Openings: feeding inlet, manhole, and inspection door & connection port;
2.12 Discharge valve: pneumatic or manual/ flap or cylindrical discharge valve;
2.13 Working condition: NPT (normal pressure and temperature);
2.14 Not heavy duty: mixer can not be started with loading materials;
2.15 Power supply: 220V 50HZ single phase/ 380V 50HZ 3 phase;
2.16 Non ex-proof electronics (motor, electronic elements, control cabinet);
3 Optional features:
The following optional features are available: wear-resistant and anti-corrosion materials, surface treatment; continuous mixing; changeable speed; mechanical seal; customized openings and discharge valves; temperature control; pressure requirement; heavy-duty configuration; motors, electronic elements, electronic control panel are customized to different power and ex-proof requirements; light glass; sampling device; liquid spraying device; scrappers etc.
4 Technical specifications:
| Mixer model |
Working volume (L) |
Rotation speed (rpm) |
Motor power (kw) |
Overall dimension (mm) |
Machine weight (kg) |
| CMPP-50 | 20-30 | 60 | 2.2 | 800×900×850 | 200 |
| CMPP-100 | 40-60 | 60 | 3 | 950×1100×900 | 300 |
| CMPP-300 | 120-180 | 60 | 4 | 1100×1300×1050 | 690 |
| CMPP-500 | 200-300 | 60 | 7.5 | 1400×1600×1200 | 950 |
| CMPP-1000 | 400-600 | 40 | 11 | 1700×1850×1550 | 1600 |
| CMPP-2000 | 800-1200 | 40 | 15 | 2100×2650×1900 | 2400 |
| CMPP-3000 | 1200-1800 | 40 | 18.5 | 2350×2800×2000 | 3100 |
| CMP-4000 | 1600-2400 | 40 | 22 | 2500×2900×2200 | 4000 |
| CMPP-5000 | 2000-3000 | 40 | 30 | 2700×3000×2300 | 4500 |
| CMPP-6000 | 2400-3600 | 35 | 37 | 2900×3050×2450 | 5000 |
| CMPP-8000 | 3200-4800 | 35 | 45 | 2800×3500×2600 | 6100 |
| CMPP-10000 | 4000-6000 | 30 | 55 | 3000×3700×2700 | 8000 |
| CMPP-15000 | 6000-9000 | 30 | 75 | 3100×4300×2900 | 9500 |
| CMPP-20000 | 8000-12000 | 20 | 90 | 3500×4600×3200 | 13000 |
5 Mixers Album:
6 Application Industry:
7 Factory Album:
