IP Intercom System Door Intercom with Camera Door Access Control Keypad
10-499 Piece
$189500 Piece
$179Product information
High-quality IP Intercom System Door Intercom with Camera Door Access Control Keypad supplied by Shenzhen Niteray Industry Limited. Bulk wholesale pricing ranges from $179 to $189 per Piece with a minimum order of 10 Piece. Inquiry for latest prices.
Weight:
0.8kg
Production Capacity:
10k/Month
Dimension:
170*120*40
Specification:
170*120*40mm
HS Code:
8531809000
Trade Term:
FOB, CFR, CIF, FCA, EXW
Origin:
Guangdong, China
Wire:
IP Line
Specifications
Weight:
0.8kg
Production Capacity:
10k/Month
Dimension:
170*120*40
Specification:
170*120*40mm
HS Code:
8531809000
Trade Term:
FOB, CFR, CIF, FCA, EXW
Origin:
Guangdong, China
Wire:
IP Line
Payment Term:
LC, T/T, PayPal, Western Union, Money Gram
Trademark:
NiteRay
Touch Keyboard:
Numeric Keys
Transport Package:
Paper Box
Power:
Poe or Adapter
Model NO.:
Q520-3
Protocol:
SIP
Port Of Loading:
Shenzhen
Network:
Static/Pppoe/DHCP
Route/PBX:
Support
Swipe Card:
Support
Phone Unlock:
Support
Installation:
Wall-Mounted
Doorbell Function:
Yes
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Year Established:
2005-05-25
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Money Gram
Preferred Trade Term:
FOB, CFR, CIF, FCA, EXW
Port Of Loading:
Shenzhen
Certificates:
CE certificate of car charger, EN62368-1 certificates, FCC, REACH, ROHS
Product descriptions from the supplier
IP Intercom System Door Intercom with camera Door Access Control Keypad
Main Features:
- Video SIP door phone(Q520).
- Optional qty to buy: F600*N+Q520*N
- Hidden RFID Card Reader.
- Relay to Connect to Door Lock , NO/NC Relay Mode.
- Able to create Intercom with or without server/PBX.
- Use SIP Protocol, Easy to Deploy.
- Directly Call to Preset Telephone.
- Waterproof design.
- Hight Quality Conversation Voice.
- Full Duplex Intercom.
- Auto Answer , Auto Hand Down.
-
The design of Q520 SIP Video Door phone is based on experience and knowledge of NiteRay VoIP phone development. Voice transmission uses standard IP / RTP protocol and video transmission adopts RTSP. Q520 have a variety of enterprise-level features and it is compatible with lots of major platforms, such as 3CX, Asterisk, Broadsoft, Elastix, etc. The Q520 SIP Video door phone is designed for operation in indoor conditions. The robust mechanical construction offers protective coverage rating against dust and water (IP65). The Q520 is economical devices with triple function(All in one)- Access control by call, code , indoor switch and RFID card.
-
Datasheet:
Access control function · Video codec: H.264 · 1 indoor switch · Two SIP lines, support SIP 2.0 (RFC3261) · Resolution: The main stream1280 *720 · 1 relay: MAX DC30V/1A, AC125V/0.5A and related RFC Sub-stream 640*360, 352*288, 32*240 · Active switching output: 12V/700mA DC · Full-duplex handsfree (HF) · Viewing angle: 110 ° (H), 95 ° (V) · RFID reader: ID(12kHz) standard type · Default Auto Answer · Minimum illumination: 1Lux, temporarily IC(MIFARE ONE) custom type · Open the door operation: DTMF, does not support infrared lighting · RFID card number output: positive password, RFID card, switch Networking/ Protocols sequence output 8H10D · Support 200,000 door open records · Support PoE (802.3af) · Microphone: -38dB · Support 2000 remote access list · Primary and secondary DNS servers are · Speaker: 4Ω / 3W · Support2000 RFID cards supported · WAN port: RJ-45, 10 / 100M adaptive · Support electric lock internal or external · Support VLAN · Power supply: 12V ± 15%/1A DC or POE power supply options · Support SNTP client · PoE: 802.3af (Class 3 - 6.49 to 12.95W) · Support customized DSS keys · Support VPN L2TP / openVPN · Standby power: 2.76W, 12V / 230mA · Network Time Synchronization · Support SRTP · Network cable: CAT5 or better · Action URL / Active URI remote control · Support HTTP / HTTPS web pages · Shell material: metal surface, ABS body Audio · Support Qos: 802.1p / q, DSCP · Narrowband speech codec: G.711a / u, · Support MD5 authentication · Installation: wall-mounted installation G.723.1, G.726-32K, G.729AB · Support Web Filter · Operating temperature: -20 ~ 60 ºC · Broadband speech codec: G.722 · DHCP / static / PPPoE · Storage temperature: -40 ~ 70 ºC · Full Duplex Echo Cancellation (AEC) · Support STUN · Relative humidity: 10 ~ 90% · DTMF: In-band, out-of-band DTMF Physical Specifications · Protection class: IP65 (RFC2833) / SIP Info · 1 DSS button (speed dial button) · Equipment size: 160x93x35mm Video · 4 indicator lights (including hot-key · Packing size: 178x104x55mm · Sensor: 1/4 "color CMOS backlight) · Equipment weight: 530g · Pixels: 1 million · Numeric keypad · Package weight: 850g
