Innovative Closed-Loop Cooling Systems for Optimized Data Centers
1 Piece
$2,000Product information
High-quality Innovative Closed-Loop Cooling Systems for Optimized Data Centers supplied by Shanghai Shenglin M&E Technology Co., Ltd.. Bulk wholesale pricing is $2,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Heat Transfer Range:
20~1500kw
Production Capacity:
3000units/Month
Package Gross Weight:
500.000kg
Package Size:
600.00cm * 1200.00cm * 2100.00cm
HS Code:
8415909000
Specification:
CE, ISO
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
System Type:
Closed System
Specifications
Heat Transfer Range:
20~1500kw
Production Capacity:
3000units/Month
Package Gross Weight:
500.000kg
Package Size:
600.00cm * 1200.00cm * 2100.00cm
HS Code:
8415909000
Specification:
CE, ISO
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
System Type:
Closed System
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Application Fields:
Data Center
Secondary Side Medium:
Deionized Water, Ethylene Glycol Solution, Propyle
Trade Term:
FOB, CFR, CIF, DDP, EXW
Fans Species:
Frequency Fan
Noise Level:
Low
Cooling Water:
Mineral Oil
Condition:
New
Cdu Type:
Rack Mounted, Floor Standing
Certification:
RoHS, ISO, CE, CCC
Model NO.:
SLCDU040W
Origin:
Shanghai, China(Mainland)
Port Of Loading:
Shanghai, Ningbo
Trademark:
Shenglin
Primary Side Medium:
Softened Water, Ethylene Glycol Solution
Payment Methods:
Support payments in USD
Payment Term:
T/T, Western Union
Type:
Water-Cooled
Transport Package:
Wrap Film or Customized
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2009-12-29
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, Western Union
Preferred Trade Term:
FOB, CFR, CIF, DDP, EXW
Port Of Loading:
Shanghai, Ningbo
Certificates:
CE Heat Pump-EMC, CE Heat Pump-LVD, CE Rooftop AC-EMC, CE Rooftop AC-LVD, CE-Chiller, CE-Dry Cooler, ROHS, UL-Dry Cooler
Product descriptions from the supplier
Introduction
The Coolant Distribution Unit (CDU) is the core component of the water cooling system, responsible for efficiently distributing the coolant to meet various cooling needs. By integrating auxiliary monitoring and support devices, the CDU ensures stable operation of the system.
It is mainly used for heat exchange control in liquid cooling systems, incorporating secondary side variable frequency circulating pumps, plate heat exchangers, electric control valves, temperature sensors, pressure sensors, filters, expansion tanks, flow meters, and online replenishment functions. The CDU is pre-installed and debugged at the factory, reducing on-site installation and commissioning work.
Performance Range
Features
· 10-inch Touch Screen: Multi-level authority control, easy to operate.
· Modular Design: Flexible expansion according to demand.
· High-Efficiency Variable Frequency Pump (Optional): Dual backup pumps automatically adjust flow rate, ensuring efficient operation.
· Dual Power Supply Backup (Optional): Enhances system reliability.
· Corrosion-Resistant Materials: Made with 304 stainless steel and above, ensuring long service life.
· Intelligent Control System: Includes temperature monitoring, secondary side temperature control, flow and differential pressure control, anti-condensation protection, and optional monitoring for conductivity, water turbidity, water hardness, and pH value.
· Ultra-Quiet Motor: Low noise and long service life, suitable for quiet environments.
· Standard Communication Protocol: Supports Modbus TCP, with comprehensive detection, alarm, and protection functions. Setup parameters are automatically protected, and operational parameters and alarm records are retained after power failure.
· Customizable Monitoring Protocol: Special format monitoring protocols can be customized according to customer requirements.
· Secondary Side Filtration Precision: Ultra-wide design range of 25~100μm, meeting various application needs.
Our Advantages
With Shenglin's innovative design, the CDU optimizes the performance and reliability of the water cooling system. It features six channels that connect the main circuit to the secondary water distributor of the water-cooled cabinet, reducing installation and production errors with the use of chucks and rubber hoses.
Shenglin's CDU incorporates a multi-stage centrifugal pump for industrial water circulation, ensuring efficient and reliable coolant flow. An integrated expansion tank compensates for temperature fluctuations, maintaining stable pressure levels and ensuring reliable system operation.
To prevent issues such as oxidation corrosion, poor circulation, and cavitation of the circulation pump, the CDU includes an automatic air vent valve on the top of the makeup water tank/main pipeline, which promptly eliminates non-condensable gases from the system.
Additionally, the CDU is equipped with a 150μm filter in the main path to protect the quality of the coolant, ensuring the reliable and stable operation of the entire system.
Choose Shenglin's Coolant Distribution Unit (CDU) for a more efficient and reliable water cooling system.
| Model | SLCDU020W | SLCDU030W | SLCDU040W | SLCDU050W | SLCDU060W | SLCDU070W | SLCDU080W | |
| supply power | 220V1Ph 50Hz | |||||||
| Unit performance parameters | ||||||||
| Primary side temp. 35/42ºC, Secondary side temp. 40/47ºC |
cooling capacity-kW | 21.1 | 32.2 | 41.3 | 53.2 | 62.5 | 70.6 | 82.1 |
| Secondary side flow rate-m3/h | 2.58 | 3.94 | 5.06 | 6.51 | 7.65 | 8.64 | 10.05 | |
| Secondary side pressure drop-kPa | 30.7 | 44.1 | 62.9 | 41.4 | 50.9 | 62.0 | 74.7 | |
| Primary side flow rate-m3/h | 2.58 | 3.94 | 5.06 | 6.51 | 7.65 | 8.64 | 10.05 | |
| Primary side pressure drop- kPa |
41.2 | 55.3 | 74.9 | 54.5 | 65.3 | 78.0 | 92.5 | |
| Rated power-kW | 0.46 | 0.59 | 0.73 | 0.83 | 0.91 | 1.00 | 1.13 | |
| FLA-A | 4.26 | 4.26 | 4.26 | 5.97 | 5.97 | 5.97 | 8.81 | |
| Primary side medium | Softened water,ethylene glycol solution | |||||||
| Secondary side medium | Deionized water,ethylene glycol solution,propylene glycol solution | |||||||
| Primary side pipeline | DN32 | DN32 | DN32 | DN40 | DN40 | DN40 | DN40 | |
| Secondary side pipeline | DN32 | DN32 | DN32 | DN40 | DN40 | DN40 | DN40 | |
| Interface type | Chuck interface |
Chuck interface |
Chuck interface |
Chuck interface |
Chuck interface |
Chuck interface |
Chuck interface |
|
| Width -mm | 600 | 600 | 600 | 600 | 600 | 600 | 600 | |
| Deep-mm | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | |
| Height-mm | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | |
| Weight-kg | 200 | 200 | 200 | 220 | 220 | 220 | 220 | |
