Jacketed Mass Flow Meter Thermally Insulated Flow Meter

Manufacture supply directlyJacketed Mass Flow Meter - Precision Flow Measurement for High-Temperature Applications

Ajacketed mass flow meteris a specialized flow measurement instrument designed to handle fluids that require precise temperature control. It features an additionalinsulating jacketwelded around the outer shell of the flow meter. By injectinghigh-temperature mediasuch as steam or heat transfer oil into the jacket, the device maintains a stable fluid temperature inside the meter through heat transfer. This preventscooling, solidification, and viscosity fluctuations, ensuring accurate and reliable flow measurement in demanding industrial applications.

Phase Difference:The phase difference is caused by the Coriolis force, which is generated when the medium moves in a rotating system. The Coriolis force at the inlet of the flowmeter opposes the movement of the measuring tube, while the Coriolis force at the outlet of the flowmeter helps the measuring tube move. This results in a phase difference between the two detectors, as shown in the figure on the right.

1. Jacketed Structure for Thermal Stability

2. The integratedinsulation jacketkeeps the process fluid at a stable temperature, preventing heat loss and ensuring measurement accuracy.
3. Ideal for applications where fluid viscosity, phase changes, or crystallization may occur due to temperature fluctuations.
4. High-Temperature Calibration for Enhanced Accuracy
5. Useshigh-temperature heat transfer oilduring calibration to replicate real-world operating conditions.
6. The calibration system supports temperatures up to204°C, optimizing the meter for accurate readings in high-temperature environments.
7. Designed for Extreme Temperatures
8. Specially engineered to withstand and measure fluids with temperatures up to350°C, making it suitable for industries handling heated liquids, viscous fluids, and sensitive chemical processes.
9. Wide Range of Fluid Compatibility
10. Effectively measures the flow ofliquids, gases, and slurriesthat require temperature regulation.
11. Minimizes measurement errors caused bythermal expansion, contraction, or changes in fluid properties.
12. Reliable Performance in Harsh Environments
13. Robust construction ensuresdurability and longevityin high-pressure, high-temperature, and corrosive industrial settings.
14. Compatible withvarious process control systems, offering seamless integration into automated operations.

Thejacketed mass flow meteris widely used in industries wheretemperature-sensitive fluid measurementis essential. Key applications include:

Petrochemical & Chemical Industry
Monitoring high-temperaturehydrocarbons, asphalt, bitumen, and resins
Ensuring accurate dosing and blending ofchemical process fluids
Preventing solidification of waxes, tars, and polymers

Food & Beverage Production & Pharmaceutical Industry
Measuring the flow ofmolten chocolate, syrups, edible oils, and dairy products
Controlling precise temperature conditions in pharmaceuticalliquid formulations
Maintaining hygienic and regulatory compliance inclean-in-place (CIP) systems

Water Treatment & Environmental Monitoring
Regulating the flow ofheated process waterin industrial treatment plants
Monitoring chemical dosing inwastewater treatment and desalination facilities
Ensuring stable fluid conditions inpower plant cooling systems

Other High-Temperature Applications

Steel & Metallurgy: Flow control ofmolten metals, lubricants, and cooling fluids
Paper & Pulp Industry: Measuring hot liquids likeblack liquor and bleaching agents
Textile & Dyeing Industry: Regulating flow inhot dye baths and textile processing chemicals

All the products  certificated by ISO, ATEX, CCS, IECEx, UKEX, QAN, QAR and PESO .

It can be used to directly measure the mass flow rate of fluid in pipeline without the influence of temperature, pressure and flow velocity.
High accuracy and excellent repeatability. Wide range ratio (100:1).
Cryogenic and high pressure calibration is employed for high -pressure flowmeter. Compact structure and strong installation interchangeability. Small pressure loss and wide range of working conditions.
The hydrogen mass flowmeter has excellent small flow measurement performance, which can fully meet the working conditions of the hydrogen dispensers. There are currently two types of hydrogen mass flowmeters: 35MPa and 70MPa (rated operating pressure). Due to the high safety requirements of hydrogen flowmeter, we have obtained the IIC explosion-proof certificate.



Mass flow meters are known for their high accuracy, wide measuring range and reliable performance, and have been successfully used in various industries over the past many years.
Unlike other instruments that are limited to measuring liquids at normal pressure and temperature, ANDISOON excels in measuring under challenging conditions, including high pressure, high viscosity, and high and low temperatures. For example, when measuring CNG (compressed natural gas), the difficulty lies in the high pressure. However, ANDISOON's sensors can withstand high pressures, allowing the necessary increase in flow tube thickness, allowing the transmitter to detect signals with greater sensitivity. Therefore, ANDISOON's mass flow meters specially designed for CNG gas dispensers have been widely used in the domestic market
In the field of cryogenics, Andisoon has developed a backflow meter and a liquid phase injection meter for LNG refueling stations, with a minimum temperature of -196°C.
In the field of process control, Andisoon has developed a micro-bend type mass flowmeter, with a maximum flow rate of up to 300t/h, widely used in petroleum, chemical and other industrial conditions.


Why choose uS?

(1) For electronic products, we have automatic chip mounter (SMT) production line and high/low temp. testing equipment.
(2) For mechanical products, we have advantage on casting, machining, and welding which is the key point in eyes of Russian.
(3) For calibration, we have calibration facilities approved by China government for oil, water and gas.
(4) For flowmeter, we are Top leaders in China for both of Coriolis Mass Flowmeter & PD flowmeter, which be approved the UL, CE, CCS (China) and BV certificate (France) for marine market.
(5) For pump, we combined Russian  technology with China low cost to manufacture for large capacity transportation of oil, chemical, water, and wastewater even if contain some participles and we also design and produce twin-screw pump for high pressure, high viscosity liquid with multiphase.
(6) For SCADA loading & metering/ Skid Mount System, we also have much experience in China and in Afghanistan, Equatorial Guinea and are trying to promote in all over the world.
