Keylink High Efficiency Precision Vacuum Plasma Cleaner for Industrial Use
Piece
Negotiable
Product information
High-quality Keylink High Efficiency Precision Vacuum Plasma Cleaner for Industrial Use supplied by Keylink Technology Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
1000sets/Year
Package Gross Weight:
200.000kg
Voltage:
220V
Package Size:
62.00cm * 55.00cm * 68.00cm
HS Code:
8479899990
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Usage:
Clean
Specifications
Production Capacity:
1000sets/Year
Package Gross Weight:
200.000kg
Voltage:
220V
Package Size:
62.00cm * 55.00cm * 68.00cm
HS Code:
8479899990
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Usage:
Clean
Type:
Clean Machine
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Specification:
Contact us
Size:
Customization
Trade Term:
FOB, CIF, CFR, EXW
Trade Terms:
Fob
Function:
Improve Adhesion of Suface
Trademark:
KEYLINK
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Port Of Loading:
Ningbo Port
Application:
Printing, ED Interest and Creative Work etc
Payment Methods:
Support payments in USD
Product Name:
Vacumn Plasma Surface Treater
Model:
Vl-10-F
Model NO.:
Vl-10-F
Color:
White
Transport Package:
Wooden Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2016-01-13
Annual Revenue Amount:
Not specified
Numbers Of Employees:
48
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Ningbo Port
Certificates:
Others
Product descriptions from the supplier
| VL-10-F Powder Vacuum Plasma Cleaning Machine | ||||
| Technical specification | ||||
 |
Factory requirements | Input Voltage | AC220V(±10%) | |
| Compressed gas | ≥0.4Mpa | |||
| Process gas | 0.2~0.3Mpa | |||
| Host | Dimension | 620(L)×550(W)×680(H)mm(subject to our available products) | ||
| Weight | About 200Kg | |||
| Appearance | White | |||
| Total power of device | 1.8KW | |||
| Power | Power | 300W | ||
| Supply frequency | 13.56MHz | |||
| Vacuum system | Vacuum pump | 40m³/h | ||
| Vacuumize until cleaning preparation time | within 30s | |||
| Vacuum line | All stainless steel pipes and high-strength vacuum bellows | |||
| Cavity material | Stainless steel | |||
| Cavity thickness | 10mm | |||
| Leakproofness | Ultimate vacuum degree <5Pa, leakage rate >15Pa/s | |||
| Cavity internal dimensions (customizable) | 200(W)×200(H)×250(D)mm(Width x height x depth) | |||
| Effective plate size (customizable) | 143(W)×80(D)mm(Width x Depth) | |||
| Barrel size (customizable) | 138(W)×110(D)mm(Width x Depth) | |||
| Gas system | Process gas flow range | 0~300SCCM | ||
| Process gas path (customizable) | Standard configuration: Argon and oxygen two-way process gas (1 MFC) | |||
| Gas Pipeline | ||||
| Control system | Systems control | PLC (Siemens) |
||
| Interactive mode | Touch interaction:7-inch touch screen (Siemens) |
|||
| Control mode | Automatic and manual mode control (switchable) |
|||
Product Description
What is plasma?
Plasma is an appellation for a kind of unstable aggregation state of high energy level. Through the input of energy, the material is transformed from solid and liquid to gas. Additional energy is injected into the gas through the discharge action, and then the plasma state is produced. The input of the energy allows electrons to break away from their atomic orbitals and can break the chemical bonds to form free electrons, ions, and molecules. The result of this process is regarded as the fourth state of material existence except for solid, liquid and gas states.
Plasma cleaner can used on Box folding-gluing bonding in the industry of print and package;Reliable bonding of automobile headlights;Bonding of household appliances;Bonding of safety components in the automobile.Quick Details
Product Application
(1)Automotive and aerospace industries
1.Car headlights 2.EPDM profiles 3.Control devices 4.Tyres 5.Motor pump housing 6.Bicycles 7.Motor bikes 8.Trucks 9.Aircraft
(2)High demands for purity and freedom from electric charge
1.Mobile phones 2.Flat screens 3.Displays 4.Discs 5.Microphones and loudspeakers 6.Computers
(3)Invisible yet indispensable - and solvent-free in the supermarket
1.Cardboard packaging 2.Bottle caps, lids on cans 3.Tamper evident seals 4.Plastic films 5.Wet labeling
(4)House and home
1.Solar panels 2.Window frames 3.Safety glass 4.Roller blinds. 5.Façade cladding elements 6.Garden furniture 7.Concrete sealing strips 8.Furniture edges
(5)Cleaning and sterilisation
1.Infant oxygenators 2.Operating instruments/implants 3.Infusion 4.Cardiac pacemakers 5.Cardiac catheters 6.Heart-lung machines.
(6)Leisure and sports equipment
1.Shoes 2.Textile fibres 3.Golf tees 4.Golf balls 5.Golf clubs 6.Watches
(7)Special applications
1.On board the liquid natural gas (LNG) Supertanker
2.Plasma for aircraft manufacturing and maintenance
3.Plasma for large-area pretreatment applications in the construction of truck semitrailers.
1. What is the shipping warehouse location?
Answer:Our main shipping warehouse is located in Zhejiang, China, and we ship globally via trusted logistics partners.We also accommodate customer-preferred shipping methods or carriers.
2.What is the production lead time?
Answer:Lead time varies based on order size and product type:
- For small to medium orders (e.g., 10-20 machines), the lead time is approximately3-4 workdays.
- We expedite production to meet tight deadlines whenever possible, especially before holidays like the Spring Festival.
3.Can I customize my order (e.g., specific configurations or spare parts)?
Answer:Yes, customization is available! We can tailor machine configurations, spare parts, and accessories (e.g., nozzles orcable lengths) based on your specific requirements. Please share your customization needs during the order confirmation process.
4.What are the payment terms?
Answer:We offer flexible payment terms, including:
- Full payment before shipping
- 50% depositupon order confirmation.
- Remaining balance before shipment.
Payments are typically made viaSWIFT transfer. For long-term partners, we can explore customized payment plans based on mutual agreement.
5.What kind of after-sales support do you provide?
Answer:We offer comprehensive after-sales support, including:- Technical Assistance: Troubleshooting via email, phone, or video calls.
- Spare Parts: Quick access to replacement parts for machines under warranty or through spare part orders.
- Documentation: User manuals, maintenance guides, and troubleshooting SOPs for all products.
- On-Site Support: For critical issues, we can dispatch technicians to your location (subject to availability and agreement).
