LPC2148 Development Boards Package Type Lqfp64 Analog Input Channels 14 Usb Endpoint Ram Size 2 Kb Interface Speed Up To
Negotiable
Product information
High-quality LPC2148 Development Boards Package Type Lqfp64 Analog Input Channels 14 Usb Endpoint Ram Size 2 Kb Interface Speed Up To supplied by Teamembedded Techlabs India Private Limited. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Analog Input Channels:
14
Usb Endpoint Ram Size:
2 Kb
Cpu Operating Voltage Range:
3.0 V To 3.6 V
On Chip Static Ram Size:
40 Kb
I/O Voltage Tolerance:
5 V Tolerant
On Chip Flash Memory Size:
512 Kb
Microcontroller Type:
Arm7tdmi-s
Primary Application Use:
High Speed Wireless Communication, Usb Based Data Logging, Real Time Data Monitoring And Control, Interactive Control Panels
Specifications
Analog Input Channels:
14
Usb Endpoint Ram Size:
2 Kb
Cpu Operating Voltage Range:
3.0 V To 3.6 V
On Chip Static Ram Size:
40 Kb
I/O Voltage Tolerance:
5 V Tolerant
On Chip Flash Memory Size:
512 Kb
Microcontroller Type:
Arm7tdmi-s
Primary Application Use:
High Speed Wireless Communication, Usb Based Data Logging, Real Time Data Monitoring And Control, Interactive Control Panels
Real Time Clock Feature:
Low Power With Independent Power And 32 Khz Clock Input
Package Type:
Lqfp64
Digital To Analog Converter:
Single 10-bit
Trade Term:
To be discussed
Payment Term:
To be discussed
Analog To Digital Converter Count:
Two
Bootloader Type:
Uart Boot Loader
Interface Speed:
Up To 12mb/s
Usb Controller Compliance:
Usb 2.0 Full-speed
Business Details
Country:
India
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2014
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
Not specified
Port Of Loading:
Not specified
Product descriptions from the supplier
LPC2148 Pro Development Board is a powerful development platform based on LPC2148
ARM7TDMI microcontroller with 512K on-chip memory. This board is powered by USB port and
does not need external power supply. It is ideal for developing embedded applications
involving high speed wireless communication (Zigbee / Bluetooth / WiFi), USB based data
logging, real time data monitoring and control, interactive control panels etc. The on-chip USB
controller provides direct high speed interface to a PC/laptop with speeds up to 12Mb/s. The
UART boot loader eliminates need of an additional programmer and allows you to program
using serial port
LPC2148 Features:
LPC2148 Features:
- 16-bit/32-bit ARM7TDMI-S microcontroller in a tiny LQFP64 package
- Two 10-bit ADCs provide a total of 14 analog inputs
- Single 10-bit DAC provides variable analog output
- Low power Real-Time Clock (RTC) with independent power and 32 kHz clock input
- USB 2.0 Full-speed compliant device controller with 2 kB of endpoint RAM.
- 40 kB of on-chip static RAM and 512 kB of on-chip flash memory.
- CPU operating voltage range of 3.0 V to 3.6 V (3.3 V +- 10 pct) with 5 V tolerant I/O pads
