Low Power Consumption Minerals Ore Separation Flotation Machine
Set
Negotiable
Product information
High-quality Low Power Consumption Minerals Ore Separation Flotation Machine supplied by Gongyi Hengchang Metallurgical Building Material Equipments Plant. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Warranty:
1 Year
Production Capacity:
100 Set/Sets Per Month
Power:
11kw
Tank Size:
1750*1600*1100mm
Tank Volume:
2.8 Cubic Meter
Impeller Speed:
280 R/Min
Weight:
5T
Impeller Diameter:
600mm
Specifications
Warranty:
1 Year
Production Capacity:
100 Set/Sets Per Month
Power:
11kw
Tank Size:
1750*1600*1100mm
Tank Volume:
2.8 Cubic Meter
Impeller Speed:
280 R/Min
Weight:
5T
Impeller Diameter:
600mm
HS Code:
8474100000
Material:
Carbon Steel
Keyword:
Copper Flotation Machine
Energy Saving:
Energy Saving
Advantage:
Energy Saving and Environmental Protection
Trade Term:
FOB, CIF, CFR, EXW
Material Feature:
Fire Resistant
Other Namer:
Flotation Separator
Origin:
Gongyi City, Henan Province, China
Trademark:
Hengchang
Feature:
High Recovery Rate
Specification:
ISO9001: 2015
Certification:
ISO9001:2008, CE
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Color:
Multi Color
Condition:
New
Customized:
Non-Customized
Price:
Reasonable
Model NO.:
SF
Function:
Separating Various Ore
Transport Package:
Standard Packing
Payment:
T/T or L/C
Port Of Loading:
Tianjin Port, Qingdao Port, Shanghai Port
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2019-02-20
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Tianjin Port, Qingdao Port, Shanghai Port
Certificates:
CE certificate for crusher, CE certificate for trommel washer, CE certificate of ball mill, CE certificate of briquette machine, CE certificate of rotary dryer, CE certificate of sand washing machine, CE Certificate of Trommel Washer Gold trommel Wash Plant, CE Certificate of vertical dryer vertical coal briquettes dryer, Crusher CE certificate, Energy -saving crusher patent, High -efficiency dryer patent, ISO CERTIFICATE, ISO NEW CERTIFICATE, ISO9001-2015 certificate, Key demonstration enterprise of Zhengzhou Business Department, sand washerCE certificate, SGS CERTIFICATE, Zhengzhou Integrity Enterprise
Product descriptions from the supplier
1. Product Application of XJK Series minerals Ore Separation Flotation Machine
SF flotation machine has the advanced forward-type tank structure, double-blade wheel, with a diversion pipe and false bottom device. The slurry in the slot flows in an up and down double fixed direction cycle, which is good for the coarse-grained mineral flotation. It can absorb fresh air and slurry, no need foam pump, suitable for separation of non-ferrous metals, ferrous metals, precious metals, non-metallic mineral and chemical raw materials, recovery of useful minerals.
2. Working Principle of XJK Series minerals Ore Separation Flotation Machine
When the flotation machine works, the motor drives the impeller to revolve, so the centrifugal effect and negative pressure are produced. On one hand, ample air is absorbed and mixed with mineral slurry, on the other hand, the mixed mineral slurry is mingled with additive, meanwhile, the foams are thinning, the mineral is bounded with foams, and floats up to the surface of mineral slurry and the mineralized foam is formed. The liquid surface can be adjusted with the height of
adjustment flashboard, so that the useful foams are scraped with squeegee.
3. Main Features of XJK Series minerals Ore Separation Flotation Machine
(1). large air-absorption capacity
(2). low energy consumption
(3). less reagents consumption
(4). easy to maintenance and can be designed according to the users.
(5). horizpntal arrangement,
(6). no foam pump required,
(7). long service life of the impeller cover plate,
(8). upper and lower double circulation of the ore pulp in a fixed way
4.Technical Parameters of XJK Series minerals Ore Separation Flotation Machine
5. Our service
1) Installation and guidance
When the machine arrives at your company, we will dispatch our technicians to your company to guide the installation and commissioning at site. User should pay for the following fees air tickets, boarding and lodging and traffic in client's factory.
(2)Technical training
We provide free technical training service to your stuff. Training content contains the main work principle of machine, operating regulations, maintenance methods and steps, safety, etc.
(3)Warranty:
Three guarantees of our product quality, warranty for one year (not include man-made damaged). We will maintain the machine for free for the quality problem. If the damage is caused by your improperly operation, the cost of the maintenance burden by you. we also provide you the life-long follow-up service.
7. Our Company
Gongyi Hengchang Metallurgy Building Material Equipments plant was built in 1992, is a professional manufacturer specializing in the production of mineral beneficiation equipments, sand and stone crushing equipments, briquetting equipments, coal preparation equipments, drying and calcining equipments, cement plant equipments and compound fertilizer equipments. The products are widely used in mineral processing, metallurgy, building materials, chemicals, electricity, petroleum, coal, transportation, fertilizer , gas industry etc.
FAQ
1 Are you a trading company or manufacturer? What is your main products?
2 Can I visit your factory and clients' workshop? How to get to your factory?
Yes, welcome to visit our factory anytime, we can also arrange your visit in our China clients' workshop.
For getting to our factory, you can get a flight to Zhengzhou Airport. It just takes about 2 hour from Zhengzhou Airport to our factory by car.
3 What is your guarantee time and aftersale service?
--Our guarantee time is 1 years.
-- Each order machine we provide installation drawing and operation manual. If needed, engineers can be sent to your factory for installation and commissioning, trainin
--Any problem in operation or others about machines, we will give solution in 12-24hours.
4 What is your payment term?
We can accept various payment terms if it is convenient for you.
5 What is your delivery time?
machine leadtime is 7 working days in standard specification, 15~20 working days if customized.
Please tell your questions, Hengchang factory team are happy to serve&ready to be your business partner! If you want to know more details, please contact Winni ! Your satisfaction is our greatest pursuit.
SF flotation machine has the advanced forward-type tank structure, double-blade wheel, with a diversion pipe and false bottom device. The slurry in the slot flows in an up and down double fixed direction cycle, which is good for the coarse-grained mineral flotation. It can absorb fresh air and slurry, no need foam pump, suitable for separation of non-ferrous metals, ferrous metals, precious metals, non-metallic mineral and chemical raw materials, recovery of useful minerals.
2. Working Principle of XJK Series minerals Ore Separation Flotation Machine
When the flotation machine works, the motor drives the impeller to revolve, so the centrifugal effect and negative pressure are produced. On one hand, ample air is absorbed and mixed with mineral slurry, on the other hand, the mixed mineral slurry is mingled with additive, meanwhile, the foams are thinning, the mineral is bounded with foams, and floats up to the surface of mineral slurry and the mineralized foam is formed. The liquid surface can be adjusted with the height of
adjustment flashboard, so that the useful foams are scraped with squeegee.
3. Main Features of XJK Series minerals Ore Separation Flotation Machine
(1). large air-absorption capacity
(2). low energy consumption
(3). less reagents consumption
(4). easy to maintenance and can be designed according to the users.
(5). horizpntal arrangement,
(6). no foam pump required,
(7). long service life of the impeller cover plate,
(8). upper and lower double circulation of the ore pulp in a fixed way
4.Technical Parameters of XJK Series minerals Ore Separation Flotation Machine
| Model | SF-0.15 | SF-0.37 | SF-1.2 | SF-2.8 | SF-4 | SF-6 | SF-8 | SF-10 | SF-16 | SF-20 | |
| Tank Volume (m3) | 0.15 | 0.37 | 1.2 | 2.8 | 4 | 6 | 8 | 10 | 16 | 20 | |
| Tank size (mm) |
0.5×0.5 ×0.6 |
0.7×0.7 ×0.75 |
1.1×1.1 ×1.1 |
1.7×1.6 ×1.15 |
1.85×2.05 ×1.2 |
2.2×2.2 ×1.3 |
2.2×2.2 ×1.4 |
2.2×2.9 ×1.7 |
2.9×3.8 ×1.7 |
2.85×3.8 ×2 |
|
| Capacity (m3/min) |
0.06-0.18 | 0.2-0.4 | 0.6-1.2 | 1-3 | 2-4 | 3-6 | 4-8 | 5-10 | 5-15 | 5-20 | |
| Suction intensity(m3/m2/min) | 0.5-1.0 | 0.8-1.0 | 0.8-1.0 | 1-1.2 | 1-1.2 | 0.9-1.0 | 0.9-1.0 | 0.9-1.0 | 0.9-1.0 | 0.9-1.0 | |
| Main motor |
Model | Y100L-6 | Y90L-6 | Y132M2-6 | Y180L-8 | Y200L-8 | Y250M-8 | Y250M-8 | Y250M-8 | Y250M-8 | Y250M-8 |
| Power (kw) |
1.5 | 1.5 | 5.5 | 11 | 15 | 30 | 30 | 30 | 30 | 30x2 | |
| Speed (r/min) |
940 | 1400 | 960 | 730 | 730 | 730 | 730 | 730 | 730 | 730 | |
| Impeller | Dia. (mm) |
200 | 296 | 450 | 550 | 650 | 700 | 760 | 760 | 760 | 760 |
| Height (mm) |
57 | 80 | 104 | 124 | 131 | 186 | 186 | 186 | 186 | 186 | |
| Speed(r/min) | 536 | 386 | 312 | 268 | 220 | 191 | 191 | 191 | 191 | 191 | |
| circle Speed(r/min) | 5.6 | 6.0 | 7.35 | 7.7 | 7.3 | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 | |
| Scraper Power | Model | Y80L-4 | Y80L-4 | Y90S-4 | Y100L-6 | Y100L-6 | Y100L-6 | Y100L-6 | Y100L-6 | Y100L-6 | Y100L-6 |
| Power(kw) | 0.55 | 0.55 | 1.1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
| Scraper Speed (r/min) |
16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | |
| Reducer Model | WHT80-41 | WHT80-41 | WXJ120-50 | WXJ 120-31 | WXJ 120-31 | WXJ 120-31 | WXJ 120-31 | WXJ 120-31 | WXJ 120-31 | WXJ 120-31 | |
| weight(kg) | 538/2 | 936/2 | 2745/2 | 4676/2 | 5165/1 | 3000/1 | 4129/1 | 4686/1 | 8230/1 | 8530/1 | |
5. Our service
1) Installation and guidance
When the machine arrives at your company, we will dispatch our technicians to your company to guide the installation and commissioning at site. User should pay for the following fees air tickets, boarding and lodging and traffic in client's factory.
(2)Technical training
We provide free technical training service to your stuff. Training content contains the main work principle of machine, operating regulations, maintenance methods and steps, safety, etc.
(3)Warranty:
Three guarantees of our product quality, warranty for one year (not include man-made damaged). We will maintain the machine for free for the quality problem. If the damage is caused by your improperly operation, the cost of the maintenance burden by you. we also provide you the life-long follow-up service.
7. Our Company
Gongyi Hengchang Metallurgy Building Material Equipments plant was built in 1992, is a professional manufacturer specializing in the production of mineral beneficiation equipments, sand and stone crushing equipments, briquetting equipments, coal preparation equipments, drying and calcining equipments, cement plant equipments and compound fertilizer equipments. The products are widely used in mineral processing, metallurgy, building materials, chemicals, electricity, petroleum, coal, transportation, fertilizer , gas industry etc.
FAQ
1 Are you a trading company or manufacturer? What is your main products?
2 Can I visit your factory and clients' workshop? How to get to your factory?
Yes, welcome to visit our factory anytime, we can also arrange your visit in our China clients' workshop.
For getting to our factory, you can get a flight to Zhengzhou Airport. It just takes about 2 hour from Zhengzhou Airport to our factory by car.
3 What is your guarantee time and aftersale service?
--Our guarantee time is 1 years.
-- Each order machine we provide installation drawing and operation manual. If needed, engineers can be sent to your factory for installation and commissioning, trainin
--Any problem in operation or others about machines, we will give solution in 12-24hours.
4 What is your payment term?
We can accept various payment terms if it is convenient for you.
5 What is your delivery time?
machine leadtime is 7 working days in standard specification, 15~20 working days if customized.
Please tell your questions, Hengchang factory team are happy to serve&ready to be your business partner! If you want to know more details, please contact Winni ! Your satisfaction is our greatest pursuit.
