Low-Shear Powder Transfer Pump Air-Driven Fine Powder Conveying System
1 Piece
$3,5001 Piece
$350Product information
High-quality Low-Shear Powder Transfer Pump Air-Driven Fine Powder Conveying System supplied by JIANGYIN HETAI INDUSTRIES COMPANY LTD.. Bulk wholesale pricing ranges from $350 to $3,500 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Voltage:
0
Rated Current:
0
Production Capacity:
20000pieces Per Year
Max. Pressure:
8.6bar
HS Code:
8413
Material:
Aluminum Alloy, Cast Iron, Stainless Steel, Plasti
Certification:
CE, ISO9001:2015
Transport Package:
Carton Box & Wooden Case
Specifications
Voltage:
0
Rated Current:
0
Production Capacity:
20000pieces Per Year
Max. Pressure:
8.6bar
HS Code:
8413
Material:
Aluminum Alloy, Cast Iron, Stainless Steel, Plasti
Certification:
CE, ISO9001:2015
Transport Package:
Carton Box & Wooden Case
Performance:
Corrosion, No Leak, Explosion, Health, Wearable
Model NO.:
DJ
Trademark:
DJ pump
Trade Term:
FOB, CFR, CIF, DDP, DAP, CIP, CPT, FCA
Origin:
Jiangsu
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Diaphragm Material:
Neoprene, FKM, Santoprene, PTFE, Nitrile Rubber
Quality:
Original
Power:
Pneumatic
Port Of Loading:
SHANGHAI, ZHANGJIAGANG
Function:
Solenoid Valve, Electronic Type, Intelligent Type, Field Bus
Valve Body Type:
Spherical, Diaphragm, Triple, Butterfly, Sleeve
Payment:
T/T, L/C, O/a
OEM:
Yes
Specification:
metallic, non-metallic
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2004-05-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CFR, CIF, DDP, DAP, CIP, CPT, FCA
Port Of Loading:
SHANGHAI, ZHANGJIAGANG
Product descriptions from the supplier
ThisAir-Operated Powder Transfer Pump (AODD Pump)is designed forefficient, dust-free powder handlingin industrial applications. Powered bycompressed air, this pump ensuressafe, explosion-proof, and contamination-free powder conveyingwithno moving seals, no lubrication, and minimal maintenance.
Pneumatic Operation- No electricity required, ideal forhazardous environments
Optimized for Powder Handling- Prevents material clogging and fluidization
Aluminum & Stainless Steel Options- Available in1.5", 2", 3" sizes
Sealed & Leak-Proof Design- No contamination, protects workers and material purity
Low Shear Transfer- Prevents powder degradation, maintains quality
Portable & Easy to Install- Can be relocated easily for various industrial needs
Chemical Processing- Ideal forsilica, carbon black, calcium carbonate, and specialty powders
Construction & Coatings- Handlescements, pigments, and industrial additives
Pharmaceutical & Healthcare- Suitable forpowdered medicine and intermediates
Battery Manufacturing- Efficient forlithium powder and electrode materials
Food & Agriculture- Supportsstarch, flour, and powder-based additives
This pump is suitable forlightweight, dry, and non-cohesive powders, including:
Silica, Precipitated Silica, Carbon Black
Resins, Light Calcium Carbonate, Nano-Active Calcium Carbonate
Talc, Aluminum Hydroxide, Mica Powder, Expanded Perlite, Diatomaceous Earth
Starch, Flour, Flame Retardants, and More
Powder Requirements:
- Particle Size ≤ 75μm (200 mesh)
- Bulk Density ≤ 750 kg/m³
Our factory supplies the following powder pumps:
1.5" Aluminum Powder Pump | 1.5" Stainless Steel Powder Pump
2" Aluminum Powder Pump | 2" Stainless Steel Powder Pump
3" Aluminum Powder Pump | 3" Stainless Steel Powder Pump
Heavy Duty Flap Valve Series- Available in 2" & 3" models
Why Choose This Powder Transfer Pump?
Explosion-Proof & ATEX Certified- Safe fordust-sensitive environments
No Powder Leakage- Fully sealed system, prevents contamination
Low Maintenance- No mechanical seals, no lubrication required
Superior Suction & High Flow Rate- Efficient powder conveying
Gravity-Assisted "Top In, Bottom Out" Design- Prevents powder accumulation
Difference Between Flap Valve & Ball Valve Models:
- Flap Valve Model- Higher flow rate, better for cohesive powders
- Ball Valve Model- Ideal for finer, free-flowing powders
* ldeally suited for intermittent/on-demand, portable moderately abrasive fluids, and suspended solids.
* Simple air distribution system design, minimal moving parts.
* Clamped design for lightweight and quick maintenance.
* AODD pumps can pass even large, shear-sensitive solids without degradation or heat buildup transferred to pumped medium
* AODD pumps are able to run dry without damage to the pump
* Lead time: Normal Stock
| Liquid Inlet/Outlet Size | Wetted Part Material | Diaphragm Material |
| 1/4" | Aluminum alloy | PTFE |
| 1/2" | Cast iron | Neoprene |
| 3/4" | Stainless Steel 316 | Santoprene |
| 1" | PVDF | Buna-N |
| 1 1/2" | PP | FKM |
| 2" | EPDM | |
| 3" |
Pump Replacements, Pump parts
Diaphragm
Valve Ball
Pilot Valve Assembly
Liquid Level Controller
Manual Ball Valve
Air Valve
Muffler
Pulsation Damper
......
"DJ pump" is a high-tech company specializing in R & D, production and sales of AODD pumps and parts,
Since 2011, Our products have been widely sold and accepted in North America, South America, Europe, and Southeast Asia.
air-operated diaphragm pump, including metal and non-metal series, widely applied in chemical, paints & coatings, food processing, pharmaceutical, construction, mining, utilities, pulp & paper, metal finishing
"DJ pump" supplies original quality Replacement Parts that fit DJ pump®, serfico®, Aro®, Blagdon®, Depa®, Flux®, G raco®, Sandpiper®, Tapflo®, Verderair®, Versa-Matic®, and Yamada® Air Operated Double Diaphragm Pumps.
Full range of parts:
diaphragms, seats, balls, pistons, gaskets, air valves, O-rings, hardware, clamp bands, shafts, mufflers, and repair kits.
"DJ pump" is committed to supplying convenient delivery and one-step solutions in the chemical pump industry.
