Magnetic Level Gauge Water Level Meter Fuel Level Transmitter
1 Piece
$2881 Piece
$158Product information
High-quality Magnetic Level Gauge Water Level Meter Fuel Level Transmitter supplied by ZHENGZHOU MEINTE INSTRUMENT CO., LTD.. Bulk wholesale pricing ranges from $158 to $288 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Process Temperature:
-40~300℃
Range:
0-5m
Accuracy:
0.25%; 0.5%
Warranty:
1 Year
Production Capacity:
100PCS/Month
Power Supply:
24VDC
Delivery Time:
5-7 Working Days
HS Code:
90261000
Specifications
Process Temperature:
-40~300℃
Range:
0-5m
Accuracy:
0.25%; 0.5%
Warranty:
1 Year
Production Capacity:
100PCS/Month
Power Supply:
24VDC
Delivery Time:
5-7 Working Days
HS Code:
90261000
Structure:
All in One
Certification:
CE
Transport Package:
Carton
Origin:
China
Trade Term:
FOB, CFR, CIF
Model NO.:
HMT. MFLM86
Specification:
ISO
Kind:
Liquid Level Transmitter
Trademark:
Meinte
Material:
SS304
Payment Term:
T/T, PayPal, Western Union, Money Gram
Port Of Loading:
Tianjian, Qingdao, Shanghai
Measurement Accuracy:
±5mm
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2010-05-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, PayPal, Western Union, Money Gram
Preferred Trade Term:
FOB, CFR, CIF
Port Of Loading:
Tianjian, Qingdao, Shanghai
Certificates:
Explosion-proof certification, Golden supplier of MIC since 2012, High-technology enterprises certificate, Patent for vortex flow meter, Patent Of Integrated tubular swirl flowmeter (28-May-2003), SGS certificate, Third Party Certification by SGS Inc
Product descriptions from the supplier
Summary
HMT.MFLM86 series magnetic flap gauge, its working principle is based on the principle of buoyancy and magnetic . It can be equipped with an electrical analogue level transducer system and/or limit switches. Due to its special design, it is particularly suitable for use in connection with aggressive, noxious or flammable substances and tough service conditions. Magnetic flap level gauge is applied to petroleum processing, food processing, chemicals, water treatment, pharmaceutical, power, paper making, metallurgy, shipbuilding and boiler liquid level in areas such as measurement, control and monitoring.
Features :
- Structure simple , performance reliable .
- Isolated medium, indicator, transmitter and switch
- Wide range of operating pressure: vacuum to 16Mpa
- Wide range of operating temperature: -190°C to 425 °C
- Independent of medium's physical and chemical states.
- electrical analogue level transducer system and limit switches are selectable to realize remote control and measurements -
| - Center-center distance | = | 200~6000mm |
| - Medium density | = | >0.5g/cm3 |
| - Nominal pressure | = | 0.6,1.6,2.5,4.0Mpa, 10MPa to35MPa |
| - Body material | = | SS304, SS304+PTFE,316L ,316Ti |
| - Operating temperature | = | Stainless Steel -190 ~ +420°C,PPR-120°C,ABS-70°C |
| - Precision | = | ±10mm |
| - Medium viscosity | = | ≤1st(10-4m2/s) |
| - Process connection | = | Flange PN20 to PN40 |
| - Limitation switch | = | Control sensitive 10mm, output capacity AC220V 2A , Explosion-proof iaIICT4 |
| - Analogue output | = | Precision ±1.5%; load 750Ω ,2 wire 4-20mA Explosion-proof iaIICT4 |
| - Bottom structure | = | Blind flange(please note if need PTFE liner valve) |
| - Protection degree | = | IP65 |
Measured Range 4400mm
Process connection :3/4"
Operate pressure :20Bar
Max pressure <4Mpa ,
Measured range :4400mm
Total length :4550mm
Power supply 24VDC ,Output 4-20mA
Float material : SS316
Control switch : 2 magnetic switch
