Mechanical Water Filter Screen Bar Screen Filter for Sewage Wastewater Treatment
Piece
Negotiable
Product information
High-quality Mechanical Water Filter Screen Bar Screen Filter for Sewage Wastewater Treatment supplied by Yangzhou Pujiang Environmental Protection Technology Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
30000 Sets/Year
Grid Gap:
3mm-15 mm
HS Code:
8421219990
Electric Component:
Customized
Motor:
Customized
Trade Term:
FOB, CIF, CFR, EXW
Protection Level:
IP55 F
Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Specifications
Production Capacity:
30000 Sets/Year
Grid Gap:
3mm-15 mm
HS Code:
8421219990
Electric Component:
Customized
Motor:
Customized
Trade Term:
FOB, CIF, CFR, EXW
Protection Level:
IP55 F
Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Trademark:
PJEP
Port Of Loading:
Shanghai Port
Transport Package:
Wooden Case
Model NO.:
XQ
Origin:
Yangzhou, China
Specification:
according to customer's requirements
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-02-24
Annual Revenue Amount:
Not specified
Numbers Of Employees:
15
Preferred Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE, ISO9001:2015
Product descriptions from the supplier
mechanical water filter screen bar screen filter for sewage wastewater treatment
PJEP's multi rake fine bar screening system for sewage processing is extensively adopted and highly regarded as an effective pre-treatment and debris removal unit in water treatment processes. Suitable for use in urban sewage systems, stormwater pumping stations, municipal wastewater, industrial effluents, and similar applications.
It consists of transmission device, rake chain system, supporting frame.
The primary structure is securely fastened to a dedicated mounting base used during component fabrication. The rake chain mechanism forms a rotating surface consisting of numerous small rake elements, each constructed from either nylon or stainless steel.
A mechanical rotary fine bar mesh consists of tiny rake blades. Powered by a chain, it moves upward from the base, lifting suspended particles to the upper surface.
Company Profile
Yangzhou Pujiang Environmental Protection Technology Co., Ltd. is situated in Yangzhou, a city adjacent to Shanghai, China. The facility boasts robust production capabilities, advanced workshop infrastructure, and a wide range of processing units. Quality is central to our operations, and we have implemented a comprehensive system covering product design, sourcing of materials, production stages, and final inspection. The company specializes in environmental technology solutions, such as sludge handling systems and wastewater treatment systems.
Our machinery includes: screw press sludge dewatering unit, polymer injection system, screw conveyor, sludge storage bin, wastewater processing unit, solid-liquid separation device, sand-water separation unit, and others. These solutions are extensively applied in urban wastewater management, petrochemical, food and beverage, aquaculture and meat processing, oil and starch, pharmaceutical chemistry, iron and steel production, textile printing and dyeing, power generation, and paper manufacturing sectors. Pujiang machinery, highly appreciated by clients, is distributed throughout China and shipped internationally.
Q: Where is your factory located?
A: Yangzhou City, which is very close to Shanghai with only less than 3 hours' driving.
Q: Do you provide OEM service?
A: Yes. Any required logos are available.
Q: How about the production capacity of your company?
A: Our factory produces machines more than 2000 sets per year.
Q: How could we trust you and your company? This is first time transaction?
A: With decades of dedicated expertise, we've served more than 1,000 clients across China and internationally. Our products are shipped to nearly 40 countries globally. We warmly invite you to explore our facility and see our manufacturing operations at any time.
Q: Do you offer after-sales service?
A: Yes. Engineers available.
Q: How long is your warranty?
A: One year after the arrival of the goods.
Q: What about your delivery Time?
A: Normally within 45 days against down payment.
Q: What about the package of your export product?
A: Normally we use anticorrosion wooden case with foam inside.
Q: What kind of payment do you accept?
A: T/T, L/C, PAYPAL, Cash, D/P, D/A, WESTERN UNIION, MONEYGRAM
Q: What kind of transportation do you offer?
A: Customers decide freight mode, Air&express & Sea .
PJEP's multi rake fine bar screening system for sewage processing is extensively adopted and highly regarded as an effective pre-treatment and debris removal unit in water treatment processes. Suitable for use in urban sewage systems, stormwater pumping stations, municipal wastewater, industrial effluents, and similar applications.
It consists of transmission device, rake chain system, supporting frame.
The primary structure is securely fastened to a dedicated mounting base used during component fabrication. The rake chain mechanism forms a rotating surface consisting of numerous small rake elements, each constructed from either nylon or stainless steel.
A mechanical rotary fine bar mesh consists of tiny rake blades. Powered by a chain, it moves upward from the base, lifting suspended particles to the upper surface.
Features
In case of mechanical faults or excessive load, the electrical overload protection system uses a thermal relay to instantly halt operation and trigger an alert. This mechanism operates with high precision and consistent performance.
2.This device can act accurately and it can effectively prevent damage caused by over-loading.
3.The rake chain screen system can operate integratedly.
4.Whole fine bar screen for supply& convenient installation.
Structure Diagram
Models&Specification
| Item Model |
Equipment Width B1(mm) | Canal Width B(mm) | Efficiency of passing through water | Power(kw) | ||||
| Grid Gap(mm) | Canal Depth(m) | |||||||
| 3mm | 5mm | 10mm | 15mm | 1.5(m)-5(m)-7.5(m) | ||||
| XQ0.4 | 300 | 400 | 0.27 |
0.36 |
0.48 |
0.54 |
0.37 | 0.37 |
| XQ0.5 | 400 | 500 | 0.55 | |||||
| XQ0.6 | 500 | 600 | 0.55 | |||||
| XQ0.7 | 600 | 700 | ||||||
| XQ0.8 | 700 | 800 | 0.75 | |||||
| XQ0.9 | 800 | 900 | 0.75 | |||||
| XQ1.0 | 900 | 1000 | 1.1 | |||||
| XQ1.1 | 1000 | 1100 | 1.1 | |||||
| XQ1.2 | 1100 | 1200 | ||||||
| XQ1.3 | 1200 | 1300 | 1.5 | |||||
| XQ1.4 | 1300 | 1400 | 1.5 | |||||
| XQ1.5 | 1400 | 1500 | ||||||
Company Profile
Yangzhou Pujiang Environmental Protection Technology Co., Ltd. is situated in Yangzhou, a city adjacent to Shanghai, China. The facility boasts robust production capabilities, advanced workshop infrastructure, and a wide range of processing units. Quality is central to our operations, and we have implemented a comprehensive system covering product design, sourcing of materials, production stages, and final inspection. The company specializes in environmental technology solutions, such as sludge handling systems and wastewater treatment systems.
Our machinery includes: screw press sludge dewatering unit, polymer injection system, screw conveyor, sludge storage bin, wastewater processing unit, solid-liquid separation device, sand-water separation unit, and others. These solutions are extensively applied in urban wastewater management, petrochemical, food and beverage, aquaculture and meat processing, oil and starch, pharmaceutical chemistry, iron and steel production, textile printing and dyeing, power generation, and paper manufacturing sectors. Pujiang machinery, highly appreciated by clients, is distributed throughout China and shipped internationally.
