Metal Coating Equipment Electric Car Assembling Line Painting Machine
Set
Negotiable
Product information
High-quality Metal Coating Equipment Electric Car Assembling Line Painting Machine supplied by Shandong Alin Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Package Gross Weight:
10000.000kg
Production Capacity:
200 Sets/Year
Package Size:
20000.00cm * 15000.00cm * 1200.00cm
Trademark:
AL
Model NO.:
AL-Line
Method Type:
Automatic
Product2:
Automatic Electrophoresis Line
Certification:
CE, ISO
Specifications
Package Gross Weight:
10000.000kg
Production Capacity:
200 Sets/Year
Package Size:
20000.00cm * 15000.00cm * 1200.00cm
Trademark:
AL
Model NO.:
AL-Line
Method Type:
Automatic
Product2:
Automatic Electrophoresis Line
Certification:
CE, ISO
Product4:
Car Coating Line
Product3:
Car Electrophoresis Line
Origin:
China Electrophoresis Line
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Type:
Coating Line
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Items:
E-Coating Equipment
Item2:
E-Coating Line for Electrophoresis
Name:
E-Coating Line
Quality:
Electrophoresis Coating Line
Name3:
Electrophoresis Coating Production Line
Product:
Electrophoresis Line
After Sales Service:
Engineer Service
Trade Term:
FOB, CIF, CFR
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Name2:
Painting Line
Coating:
Powder
Port Of Loading:
Qingdao Port
Transport Package:
Seaworthy Packing
Payment Methods:
Support payments in USD
Specification:
big line
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2018-09-04
Annual Revenue Amount:
Not specified
Numbers Of Employees:
9
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Qingdao Port
Certificates:
CE
Product descriptions from the supplier
Electric Car Electrophoresis Coating Line with Pretreatment
Color Painting Line and Assembling Line
Color Painting Line and Assembling Line
E-coating line is for applying materials to any electrically conductive surface, especially for complex
fabricated objects. It has been widely used to coat automobile parts, tractors and heavy equipment,
electrical switch gear, appliances, metal furniture, automobile parts and other industrial products.
Processing Flow:
Pretreatment→ Loading→ Degreasing →Water washing→ Derusting→ Water Washing→ Neutralizing→ Water Washing→ Phosphating→ Water Washing→ Passivating→Electrophoresis Painting→ Cleaning up the tank→ Ultra-filtration cleaning→ Drying→ Unloading
In the production of new energy electric vehicles, due to the large output and high quality requirements, automatic production lines are mainly used. Electrophoretic painting of electric vehicles is carried out in a modern painting workshop.
The coating process design is based on the prerequisites such as the production program, the surface condition of the workpiece, the quality requirements of the workpiece coating, the status of the plant, and the power supply.
With more than 20 years working experience, we have more than 30 chief engineers for the project design and more than 100 skillful workers for project assembling and debugging. Our team can guarantee high quality equipments and the production line perfectly working.
Electrophoresis coating equipment composition:
The electrophoretic coating production line is mainly composed of water washing equipment, electrophoresis and post-processing equipment, electrophoretic paint drying equipment, conveying equipment, control system, etc.
Cathodic electrophoresis equipment composition
Cathodic electrophoresis equipment is mainly composed of chamber body (closed room), electrophoresis tank, paint circulation system, filtration device, diaphragm electrode and anolyte circulation system, temperature adjustment system, ultrafiltration system, ventilation device, lighting device, transfer tank, paint supply system, DC power supply, washing system after electrophoresis and other parts.
Configuration for electrophoresis and post-swimming equipment
| No. | Equipment configuration name, specification, material | quantity | Remarks |
| 1 | Electrophoresis Shed Specification: 15000×2.800×5000mm (L×W×H) - Steel frame - Wall panels are rock wool insulation boards |
1 | |
| 2 | Electrophoresis working tank Specification: 15000×2250×2250mm (L×W×H) - The tank body is made of 5mm thick carbon steel and glass fiber reinforced plastic, with main and auxiliary tank structure. |
1 | |
| 3 | Paint circulation system (SUS304). - Use pumps made in Shanghai - Filter (bag type 40-75μm (material acrylic phenol), ejector, heat exchanger, stainless steel pipe, valve, etc.). |
1set | |
| 4 | Anode System - Equipped with conductivity meter, flow meter, pressure gauge, etc. -The ratio of cathode to anode is 5:1 - PVC anolyte tank - Domestic high-quality stainless steel pump |
1 set | |
| 5 | Ultrafiltration system - The permeation rate of ultrafiltrate is 1000L/h, and the main pump adopts national premium products - The filter system is SUS304 |
1set | |
| 6 | Ultrafiltration water washing system - The sink body is made of stainless steel - Stainless steel pumps, pipes, valves, PP ejectors, etc. |
1set | |
| 7 | Rectifier (300V 600A) - Use a dedicated rectifier |
1set | |
| 8 | Control System | Full set | |
| 9 | Refrigeration unit | 1set | |
| 10 | -Plate heat exchanger | 1set | |
| 11 | The ultrafiltration tank uses a level gauge to alarm for high and low alarms, and artificial water replenishment. | Full set | |
| 12 | Flashlight - Flameproof lamp |
Full set |
We also supply Electric cars / trucks /bikes full sets painting lines, welding lines, assembling lines, can make proper design according to customer's request:
Certifications:
Company Profile:
Alin Machinery Co., Ltd belongs to Alin group, whichare famous manufacturer group ofelectric cars,
tricycles and cargo tricycles in China.we have advanced metalhardware stampingwelding line,
automatic electrophoresis coatingline,automaticspraypainting line and assembling lines.
Our dailyproductioncapacity is 500 unitsof E cars and tricycles.More than 85% spare parts aremade
byour own factories.
Below are our products list for your reference:
2. Cargo truck, refrigerated truck, fire-fighting truck, garbage truck, road sweeping truck and so on.
3. Electric vehicle factory design and equipment supply. We offer technical support forequipment
installation, debugging and training service.
4. EV spare parts & accessories; Technical service of EV projects.
We are qualified and certificated by ISO9001. Our products have passed CE certification.
Our Electric vehicles have been exported to more than 50 countries, and we have rich experience of
exports. We have professional engineers team, advanced testing equipment and training department.
Welcome to visit our factory!
