Baffle Type Paddle Flow Switch
Description
FSP series paddle flow switches is made of reed swiches, PP switches housing and brass body,SUS304 paddle, the flow switches can beadjustable in line, changed the switches from N.O. to N.C.also you may changed the setting flow ratting.
FSP series paddle flow switches is used for testing the fulid flow in pipe, ideal for critical low flow orhigh flow protection applications such as pump seal cooling water, pump inlet flow protection, coolingcircuit protection, high and low flow rate alarm, valve failure, pump starting or failure, pipe blockage orrupture. Using these in-line flow switches to monitor min/max values of liquid flow in order toswitches a valve or to establish an on or off control loop, electrical circuit is isolated from the fluidpath.

Technical Data
1. Medium: compatible gas or liquid
2. Material:
Paddle: SUS 304
Switch body: Brass or SUS304
Pin: SUS302
Spring: SUS316
Magnet: Ceramicmagnet
3.Fluid temperature range: 93˚C(200˚F)Max 100ºCor 125ºC
4.Pressure range: Brass body 1000psi(69bar); SS body:2000psi(138bar)
5.Contact Mold: SPDT or N.O. or N.C. adjustable in line
6.Electrical rating: 1.5A @ 24VDC resistive,
100mA @200VDC resistive,
0.5A @ 125VAC resistive,
0.7A@ 220VAC resistive.
7.Wire:UL2462 AWG 22,1000mm.
8.Pipe:1/8"BSP external or 1/2"BSP external thread
9. Material of switches: PP
10.Mounting mode: Vertical or Horizontal, but there is a length that is 5 times diameter of pipe at the switches
of left or right.
Photos
Mini Paddle Flow Switches for Flow Protection
Mini Paddle Flow Switches for Flow ProtectionMini Paddle Flow Switches for Flow Protection
Mini Paddle Flow Switches for Flow Protection
