Mini Transport Tank Filling Truck
1 Piece
$50,0001 Piece
$70,000Product information
High-quality Mini Transport Tank Filling Truck supplied by Jingmen Hongtu Special Aircraft Manufacturing Co., Ltd.. Bulk wholesale pricing ranges from $50,000 to $70,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Design Temperature:
-20~50℃ or Customized
Corrosion Allowance:
1 mm or Customized
Design Pressure:
1.724MPa/1.61 MPa or Customized
Specification:
10.26 CBM without Pump System
Tank Volume:
10001-15000L
Load Capacity:
11-20t
Max. Payload:
2 Tons ~ 20 Tons or Customized
Production Capacity:
2000 Sets/Year
Specifications
Design Temperature:
-20~50℃ or Customized
Corrosion Allowance:
1 mm or Customized
Design Pressure:
1.724MPa/1.61 MPa or Customized
Specification:
10.26 CBM without Pump System
Tank Volume:
10001-15000L
Load Capacity:
11-20t
Max. Payload:
2 Tons ~ 20 Tons or Customized
Production Capacity:
2000 Sets/Year
Horsepower:
251-350hp
Engine Capacity:
4-6L
Drive Wheel:
6×4
HS Code:
73110090
Model NO.:
CCC
Trade Term:
CIF, EXW, CFR, FOB
Trademark:
CIMC HONTO
Origin:
China
Thickness Of Tank:
Customized
Kerb Weight:
Customized
Power:
Diesel
Emission Standard:
Euro 5
Tire Certification:
ISO
Payment Term:
LC, T/T
Storage:
LPG
Transmission Type:
Manual
Condition:
New
Transport Package:
Normal
Material:
SA-516, SA-517, SA-612, P460, Q420r, Q370r, etc.
Tire Design:
Tubeless
Port Of Loading:
Wuhan Port; Jingzhou Port
Seats:
≤5
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2004-10-29
Annual Revenue Amount:
Not specified
Numbers Of Employees:
1326
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
CIF, EXW, CFR, FOB
Port Of Loading:
Wuhan Port; Jingzhou Port
Certificates:
ISO14001, ISO45001:2018, ISO50001, ISO9001:2015
Product descriptions from the supplier
Products Description
Jingmen Hongtu Special Aircraft Manufacturing Co., Ltd(hereinafter calledHONGTU, and branded asHONTO) has made prominent contributions to the development of China's aviation industry since established in 1971 as the AVIC Corp II factory No. 322. Now, Hongtu as a key enterprise under China International Marine Containers (Group) Ltd. (CIMC) (ranked the 68th in China's Top 500 businesses), is engaged in R & D of normal temperature storage & transportation equipment, cryogenic storage & transportation equipment, EPC services, chemical equipment and other types of energy chemical storage & transportation equipment. The Company has more than 1,300 employees, including approx. 200 R&D professionals, and has workshop area totaling 130,000 m2.
In the 1980s, HONGTU entered into the industry of hazardous chemicals storage & transportation equipment manufacturing based on the advantages of aviation technology, providing customers with individualized and integrated solutions in the fields of hazardous chemicals'storage & transportation, gasification in cities/towns and vehicle/vessel's oil-to-gas transformation.
The Company always leads the development of the industry. The production and sales of "HONTO" Brand LPG tanker has been ranking No.1 in China in the past 36 years. The domestic market share of HONGTO reaches over 60% all along. HONGTU has been engaged in the manufacturing of energy and chemical storage & transportation equipment for over 3 decades and is also China's only LPG full-industrial chain equipment manufacturer and solution provider.
The Company has ASME "U" and "U2" Stamps Qualification and all Chinese National Permits for design, manufacture and installation of various pressure vessels, spherical tanks, urban gas pipeline projects and marine fuel tanks, and has developed and drafted a number of national standards on pressurized and non-pressurized products of China.
The Company provides global customers and partners with safe, efficient and value-added energy and chemical storage &
transportation equipment under the concept of providing service in the full product life cycle and creating values for customers, through the three-in-one marketing mode of brand communication, product sale and lifelong service, and is committed to become a leading competitive supplier with in the field of global energy chemical industry.
"HONTO" brand LPG storage and transportation equipment has been distributed to more than 40 countries & regions in North America, South America, Southeast Asia, South Asia, Middle East and Africa, etc.
LPG Bobtail Tanker
HONGTU is qualified to design and manufacture bobtail tankers with pumps and loading & unloading system on the side or at the rear of the tankers. The pump can be driven by PTO, hydraulic oil or electric motors. The valves and instruments used on the bobtail tankers are well-known international brands, catering to application requirements of Europe, America, Southeast Asia and other countries.
Technical Specification
Design Code:ASME BPVC VIII-1/VIII-2, EN 12493, GB/T19905, JB4732
Vessel Capacity:5m³~40m³
Material:SA-516, SA-517, SA-612, P460, Q420R, Q370R, etc.
The information of CIMC HONTO LPG bobtail tank truck listed in below tables are only for recommendations and references. CIMC Hongtu, as the TOP 1 manufacturer of LPG transport tankers in China, can provide customized products according to customers' requirements.
SPECIFICATIONS
| I. ASME Code | ||||||
| Volume | 5m³ | 10m³ | 17.04m³ | 21.6m³ | 22m³ | 23.3m³ |
| *Max. Payload |
2300kg
(2.5 t) |
4600kg
(5 t) |
7890kg
(8.52 t) |
10000kg
(10.8 t) |
10000kg
(11 t) |
11110kg
(11.65 t) |
| Kerb Weight | - | - | - | 15560kg | 15170kg | 14800kg |
| Gross Vehicle Weight | - | - | - | 25560kg | 25300kg | 26040kg |
| Outline Dimension |
L:7482mm
W:2400mm
H:2640mm |
L:8387mm
W:2400mm
H:2690mm |
- |
L:9945mm
W:2500mm
H:3550mm |
L:10130mm
W:2500mm
H:3550mm |
L:10340mm
W:2490mm
H:3650mm
|
| Design Pressure | 1.724MPa | 1.724MPa | 1.724MPa | 1.724MPa | 1.724MPa | 1.724MPa |
| Design Temperature | 50ºC | 50ºC | 50ºC | -20/50ºC | 50ºC | -23.3/51.7ºC |
| Corrosion Allowance | 1 mm | 1 mm | 1 mm | 1 mm | 1 mm | 0 |
| Material of Shell | SA-516 | SA-516 | SA-612 | SA-612 | SA-612 | SA-612 |
| Material of Head | SA-516 | SA-516 | SA-612 | SA-612 | SA-612 | SA-612 |
|
Test Pressure
(Hydraulic Horizontal) |
2.25MPa | 2.25MPa | 2.25MPa | 2.25MPa | 2.25MPa | 2.25MPa |
| Air Test Pressure | 1.724MPa | 1.724MPa | 1.724MPa | 1.724MPa | 1.724MPa | 1.724MPa |
| *Please note that different medium component will cause different density and different payload.
**Please contact for more different kinds of capacity and standard tanks.
|
||||||
| II. Chinese GB Standard | |||||
| Capacity | 10m³ | 13.58m³ | 20m³ | 23.81m³ | 36m³ |
| *Max. Payload |
4200kg
(5 t) |
5700kg
(6.79 t) |
8400kg
(10 t) |
10000kg
(11.905 t) |
15120kg
(18 t) |
| Kerb Weight | 10800kg | 10170kg | 15300kg | 15320kg | 15750kg |
| Gross Vehicle Weight | 15130kg | 16000kg | 23700kg | 25450kg | 31000kg |
| Outline Dimension |
L:8830mm
W:2490mm
H:3050mm |
L:8140mm
W:2450mm
H:3450mm
|
L:11800mm
W:2495mm
H:3937mm
|
L:10040mm
W:2490mm
H:3580mm
|
L:11980mm
W:2500mm
H:3770mm
|
| Design Pressure | 1.61/-0.1 MPa | 1.61/-0.1 MPa | 1.61/-0.1 MPa | 1.61/-0.1 MPa | 1.61 MPa |
| Design Temperature | 50ºC | 50ºC | -20/50ºC | 50ºC | -20/50ºC |
| Corrosion Allowance | 1 mm | 1 mm | 1 mm | 1 mm | 1 mm |
| Material of Shell | Q345R | Q345R | Q345R | Q345R |
Q420R
(WH590D) |
| Material of Head | Q345R | Q345R | Q345R | Q345R | Q345R(N) |
| Thickness of Shell | 9mm | 10.5mm | 9.5mm | 12mm | 9.8mm |
| Thickness of Head | 10mm | 11mm | 10mm | 13mm | 8mm |
| Hydraulic Test Pressure | 2.10MPa | 2.10MPa | 2.10MPa | 2.10MPa | - |
| Pressure of Leak Test | 1.61MPa | 1.61MPa | 1.61MPa | 1.61MPa | - |
| *Please note that different medium component will cause different density and different payload.
**Please contact for more different kinds of capacity and standard tanks.
|
|||||
Jingmen Hongtu Special Aircraft Manufacturing Co., Ltd(hereinafter calledHONGTU, and branded asHONTO) has made prominent contributions to the development of China's aviation industry since established in 1971 as the AVIC Corp II factory No. 322. Now, Hongtu as a key enterprise under China International Marine Containers (Group) Ltd. (CIMC) (ranked the 68th in China's Top 500 businesses), is engaged in R & D of normal temperature storage & transportation equipment, cryogenic storage & transportation equipment, EPC services, chemical equipment and other types of energy chemical storage & transportation equipment. The Company has more than 1,300 employees, including approx. 200 R&D professionals, and has workshop area totaling 130,000 m2.
In the 1980s, HONGTU entered into the industry of hazardous chemicals storage & transportation equipment manufacturing based on the advantages of aviation technology, providing customers with individualized and integrated solutions in the fields of hazardous chemicals'storage & transportation, gasification in cities/towns and vehicle/vessel's oil-to-gas transformation.
The Company always leads the development of the industry. The production and sales of "HONTO" Brand LPG tanker has been ranking No.1 in China in the past 36 years. The domestic market share of HONGTO reaches over 60% all along. HONGTU has been engaged in the manufacturing of energy and chemical storage & transportation equipment for over 3 decades and is also China's only LPG full-industrial chain equipment manufacturer and solution provider.
The Company has ASME "U" and "U2" Stamps Qualification and all Chinese National Permits for design, manufacture and installation of various pressure vessels, spherical tanks, urban gas pipeline projects and marine fuel tanks, and has developed and drafted a number of national standards on pressurized and non-pressurized products of China.
The Company provides global customers and partners with safe, efficient and value-added energy and chemical storage &
transportation equipment under the concept of providing service in the full product life cycle and creating values for customers, through the three-in-one marketing mode of brand communication, product sale and lifelong service, and is committed to become a leading competitive supplier with in the field of global energy chemical industry.
"HONTO" brand LPG storage and transportation equipment has been distributed to more than 40 countries & regions in North America, South America, Southeast Asia, South Asia, Middle East and Africa, etc.
01 Powerful R&D Ability
HONGTU has been rated as "Hubei Province Technical Center for Pressure Vessels", "Hubei Province Workstation for High-skilled Talents", etc. We have acquired more than 120 patents through the "Producing, Learning and Researching" practice, and frequent technical communications and cooperation with China Standardization Committee on Boilers and Pressure Vessels, China Classification Society, Tsinghua University, Shanghai Jiao Tong University, Zhejiang University, Fuzhou
University, Huazhong University of Science and Technology, YPDI(Nanjing Yangzi Petrochemical Design Engineering Co., Ltd.), Burg Industries B.V., TGE GAS INVESTMENT SA, Department of Energy Business(DOEB in Thailand), Australia MLI company, and other Government agencies at home and abroad, Universities, famous companies in the industry.
02 Top Expert Team
We have more than 330 professional technical staff, 30 senior engineers(including 5 Researcher-level Engineers), about 500 staff who are multi-skilled technical talents and senior technicians, 9 outsourced experts and professors employed in the industry. We are the Editorial Board of the China National Boards of Supervision Regulation on Safety Technology for Transportable Pressure Vessel; We have participated in the compiling of many other standards, such as Road Tanker for Liquefied Gas, Road Tankers for Cryogenic Liquid, Supervision Regulation on Safety Technology for Transportable Pressure Vessel, Road Tanker for Dangerous Liquid Goods Transportation.
03 Strong Production Capacity
HONGTU has been facilitated with more than 2000 sets of equipment, such as plasma cutting machines, US Lincoln welding machines, welding robots, all kinds of large and medium-sized rolling machines, beveling machines, cranes, heat treatment furnace, NDT equipment, 2000 tons of spherical shell press machines and other large heavy equipment. Among them, there are more than 200 sets of testing equipment.
04 Comprehensive Industrial Chain Solution
HONGTU has been engaged in manufacturing of energy and chemical storage & transportation equipment for over 3 decades. Focusing on the production, storage and transportation, application and intensive processing of upstream, midstream and downstream liquefied petroleum gas industry chain, HONGTU forms complete industrial equipment cluster from oil refining device, spherical tank, large scale flat bottomed vertical tank to mounded type tank, from lightweight and large-volume liquefied gas tanker to core equipment manufacturing of various types of end applications and engineering application, is China's only LPG whole industry chain equipment manufacturer and solution provider.
05 Scientific and Reorous QA&QC System
HONGTU has a sound quality assurance system and perfect quality control procedures. Products from the entry of raw materials to the delivery to the user must pass 111 quality control points, 243 quality control procedures and 47 procedure document reviews. Annual radiographic inspection films of the products exceed more than 400,000 copies and each product quality files keep for more than 20 years, so each weld quality can be tracked. HONGTU continues to carry out the LEAN Management, introduce the ONE module, passes the HSE system(quality, occupational health and safety, environment) certification and realizes the comprehensive management of information, quality and workers in the manufacturing site.
06 Professional International Services and Marketing Network
HONGTU has its own international business network and a sound international business organization structure, including 50 plus professionals engaged in technical service and overseas marketing, dedicated to providing overseas customers with technical consultation, business negotiation, product service, personnel training and a full range of integrated solutions services, and has built a three-level service assurance system comprised of salesperson, engineer and professional service personnel.
University, Huazhong University of Science and Technology, YPDI(Nanjing Yangzi Petrochemical Design Engineering Co., Ltd.), Burg Industries B.V., TGE GAS INVESTMENT SA, Department of Energy Business(DOEB in Thailand), Australia MLI company, and other Government agencies at home and abroad, Universities, famous companies in the industry.
02 Top Expert Team
We have more than 330 professional technical staff, 30 senior engineers(including 5 Researcher-level Engineers), about 500 staff who are multi-skilled technical talents and senior technicians, 9 outsourced experts and professors employed in the industry. We are the Editorial Board of the China National Boards of Supervision Regulation on Safety Technology for Transportable Pressure Vessel; We have participated in the compiling of many other standards, such as Road Tanker for Liquefied Gas, Road Tankers for Cryogenic Liquid, Supervision Regulation on Safety Technology for Transportable Pressure Vessel, Road Tanker for Dangerous Liquid Goods Transportation.
03 Strong Production Capacity
HONGTU has been facilitated with more than 2000 sets of equipment, such as plasma cutting machines, US Lincoln welding machines, welding robots, all kinds of large and medium-sized rolling machines, beveling machines, cranes, heat treatment furnace, NDT equipment, 2000 tons of spherical shell press machines and other large heavy equipment. Among them, there are more than 200 sets of testing equipment.
04 Comprehensive Industrial Chain Solution
HONGTU has been engaged in manufacturing of energy and chemical storage & transportation equipment for over 3 decades. Focusing on the production, storage and transportation, application and intensive processing of upstream, midstream and downstream liquefied petroleum gas industry chain, HONGTU forms complete industrial equipment cluster from oil refining device, spherical tank, large scale flat bottomed vertical tank to mounded type tank, from lightweight and large-volume liquefied gas tanker to core equipment manufacturing of various types of end applications and engineering application, is China's only LPG whole industry chain equipment manufacturer and solution provider.
05 Scientific and Reorous QA&QC System
HONGTU has a sound quality assurance system and perfect quality control procedures. Products from the entry of raw materials to the delivery to the user must pass 111 quality control points, 243 quality control procedures and 47 procedure document reviews. Annual radiographic inspection films of the products exceed more than 400,000 copies and each product quality files keep for more than 20 years, so each weld quality can be tracked. HONGTU continues to carry out the LEAN Management, introduce the ONE module, passes the HSE system(quality, occupational health and safety, environment) certification and realizes the comprehensive management of information, quality and workers in the manufacturing site.
06 Professional International Services and Marketing Network
HONGTU has its own international business network and a sound international business organization structure, including 50 plus professionals engaged in technical service and overseas marketing, dedicated to providing overseas customers with technical consultation, business negotiation, product service, personnel training and a full range of integrated solutions services, and has built a three-level service assurance system comprised of salesperson, engineer and professional service personnel.
