Modern Design Hydraulic Press Waste Plastic Baler Machine
Set
Negotiable
Product information
High-quality Modern Design Hydraulic Press Waste Plastic Baler Machine supplied by Jiangsu Xutian Environmental Protection Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Capacity:
1.5-3tons/H
Feed Opening Size:
1200*720mm
Power:
15kw
Cycle Time:
17s
Bale Line:
3
Bale Density:
350-450kgs/M³;
Hydraulic Power:
40tons
Oil Reservoir:
540L
Specifications
Capacity:
1.5-3tons/H
Feed Opening Size:
1200*720mm
Power:
15kw
Cycle Time:
17s
Bale Line:
3
Bale Density:
350-450kgs/M³;
Hydraulic Power:
40tons
Oil Reservoir:
540L
Package Size:
595.00cm * 320.00cm * 250.00cm
Machine Size:
5950*3200*2500mm
Machine Weight:
7 Tons
Package Gross Weight:
7000.000kg
Cooling System:
Air Cooler/Water Cooler
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Bale Ejection:
Continuously
Trade Term:
FOB, CIF, CFR, EXW
Transport Package:
Film Winding and Steel Wire Rope Fixing
Bale Size:
L*750*750mm
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Specification:
Machine size: 5950*3200*2500mm
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Application:
Waste Paper, Cardboard, Plastic Film
Door Style:
Without Door Style
Trademark:
XTPACK
Model NO.:
XTY-400W7575-20
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2012
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE
Product descriptions from the supplier
Modern Design Hydraulic Press Waste Plastic Baler Machine
Usage
Specially used for recycling waste paper, cardboards trims/ scrapes etc.which are popular in packaging/ corrugation industrial, paper/ printing plants etc.
Features
1.Photoelectric switch activates baler when charge box is full
2.Unique double-cutting design of cutters improves the cutting efficiency and lengthens the lifespan of the cutters
3.Particular anti-slide design of the machine makes nicer bales
4.Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals
5.Equipped with rapid automatic tying system, easy for cleaning and maintaining
6.Use differential technique for the hydraulic system, makes shorter cycle time so that improve the working efficiency and save electricity
7.Automatic tension system ensures "brick-like" bales on all loose materials.
8.Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient
9.Automatically detect and show the errors of the machine which improve the machine inspection efficiency
10.nternational standard electric circuit layout, graphic operation instruction and detailed parts marks make the operation been more easily understanding and improves the maintenance efficiency
11.The press heads are specially processed by planomiller, ensures the precise running of the ram
12.Use high quality hydraulic system from Taiwan, ensures the stable running of the machine
13.The heavy duty machine body makes sure only flat ground is required by the installation
14."HARDOX"in my body
Specifications
| Model | XTY-200W5050-15 | XTY-400W7575-20 XTY-600W7575L-25 |
XTY-400W7280-20 | XTY-600W7585-25 |
| Pressure | 20tons | 40tons/60tons | 40tons | 60tons |
| Main Motor Power | 11kW | 15kW/18.5kW | 15kW | 18.5kW |
| Cooling System | air cooler/ water cooler |
air cooler/ water cooler |
air cooler/ water cooler |
air cooler/ water cooler |
| Cycle Time(Unload) | 14s | 17s 24s |
20s | 16s |
| Oil Reservoir | 280L | 540L | 540L | 600L |
| Number of Belting | 3lines | 3lines/4lines | 4lines | 4lines |
| Wire Size | Ø2.4-3.2 | Ø2.4-3.2 | Ø2.4-3.2 | Ø2.4-3.2 |
| Feeding Opening Size(L×W) | 650×480mm | 1200×720mm 1600×720mm |
1200×690mm | 1200×720mm |
| Bale Size (L×W×H,L can be adjustable) |
L×500×500mm | L×750×750mm | L×720×800mm | L×750×850mm |
| Bale Density(OCC) | 350-450kgs/m³ | 350-450kgs/m³ | 350-450kgs/m³ | 380-480kgs/m³ |
| Throughput(30-60kgs/m³) | 1-1.5tons/h | 1.5-3tons/h 2-3.5tons/h |
1.5-3tons/h | 2.5-5tons/h |
| Machine Weight | 3tons | 7tons 8 tons |
7tons | 8tons |
| Machine Overall Dimension | 3600×2500×1650mm | 5950×3200×2500mm 7000×3200×2500mm |
5950×3200×2500mm | 6100×3250×2500mm |
| Feeding Device (optional) | Cyclone/conveyor | Cyclone/conveyor | Cyclone/conveyor | Cyclone/conveyor |
| Cyclone | ||||
| Air Volume | 9000-15000m³/h | 10000-20000m³/h | 15000-30000m³/h | 20000-35000m³/h |
