Multiple Disc Purifying Waste Water Environmental Sludge Dewatering Screw Filter Press
Piece
Negotiable
Product information
High-quality Multiple Disc Purifying Waste Water Environmental Sludge Dewatering Screw Filter Press supplied by Yangzhou Pujiang Environmental Protection Technology Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
3000 Sets
Outlet Cake Moisture Content:
75%-85%
HS Code:
8421191000
Inlet Sludge Solid Content:
98%-99.75%
Trade Term:
FOB, CIF, CFR, EXW
Protection Level:
IP55f
Certification:
ISO9001
Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Specifications
Production Capacity:
3000 Sets
Outlet Cake Moisture Content:
75%-85%
HS Code:
8421191000
Inlet Sludge Solid Content:
98%-99.75%
Trade Term:
FOB, CIF, CFR, EXW
Protection Level:
IP55f
Certification:
ISO9001
Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Delivery Time:
Normally 35 Days Against Down Payment
Trademark:
PJEP
Model NO.:
PJXDL
Material:
SS304/SS316
Electrical Component:
Scheider/Omorn/Customized
Style:
Screw Press Sludge Dewatering
Motor:
Sew/Nord/Customized
Port Of Loading:
Shanghai Port
Performance:
Solid Liquid Separator
Motive Force:
Solid Liquid Separator
Transport Package:
Wooden Case
Origin:
Yangzhou, China
Specification:
according to customer's requirements
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-02-24
Annual Revenue Amount:
Not specified
Numbers Of Employees:
15
Preferred Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE, ISO9001:2015
Product descriptions from the supplier
Sewage Screw Type Wastewater Treatment Sludge Dewatering Machine Screw Press
Spiral sludge dehydrator, sludge dehydrating / dewatering press for wastewater treatment plant, sewage treatment plant, effluent treatment plant, sludge treatment plant, waste plant
24 hours fully automatic control Multi-disk screw press sludge dewatering machine for Oily Sludge Treatment
Application:municipal sewage petro-refining,leather making,printing and dyeing paper,coal-ification dressing,biochemical pharmacy,steel pickling and chemical sugar,food processing etc.
Working Principle
As the machine begins operation, sludge is fed into the filter housing via the inlet and transported toward the sludge cake exit, driven by the rotating helical blades. The spacing between these blades progressively decreases, increasing the compression on the sludge. This pressure buildup causes water to slowly seep out through the gap formed between the stationary and rotating plates, due to the pressure difference. The built-in cleaning mechanism of both the stationary and rotating plates effectively prevents clogging. Finally, once the sludge has been fully squeezed and dried, it is conveyed by the helical blades to the discharge port.
Advantages(Saving)1.Low operation cost:below 40% of belt press.
2.Power-saving:less than 5% of centrifuge.
3.Water-saving:less than 0.1% of belt filter press
4.Saving-drugs:saving around 60%.
5.Compact:saving more than 60% of the investment for dehy-dration room.
6.Non-clogging:processing the facts & oils and fiber sludge perfectly
Yangzhou Pujiang Environmental Protection Technology Co., Ltd. is situated in Yangzhou, a city adjacent to Shanghai, China. The company boasts robust production capabilities, advanced workshop infrastructure, and a wide range of processing units. Quality is central to Pujiang’s operations, and a comprehensive system for process control and management spans from R&D and material sourcing through production to final quality checks. The company specializes in environmental machinery, such as sludge handling systems and wastewater treatment solutions.Our range includes: screw press sludge dewatering unit, polymer injection system, screw conveyor, sludge storage bin, wastewater processing unit, solid-liquid separation device, sand-water separation system, and more. These solutions are extensively applied in urban wastewater management, petrochemical, food and drink, aquaculture and meat processing, oil and starch, pharmaceutical chemicals, iron and steel production, textile printing and dyeing, power generation, and paper manufacturing sectors. Pujiang machinery, highly appreciated by clients, is distributed throughout China and shipped internationally.
Spiral sludge dehydrator, sludge dehydrating / dewatering press for wastewater treatment plant, sewage treatment plant, effluent treatment plant, sludge treatment plant, waste plant
24 hours fully automatic control Multi-disk screw press sludge dewatering machine for Oily Sludge Treatment
Application:municipal sewage petro-refining,leather making,printing and dyeing paper,coal-ification dressing,biochemical pharmacy,steel pickling and chemical sugar,food processing etc.
Working Principle
As the machine begins operation, sludge is fed into the filter housing via the inlet and transported toward the sludge cake exit, driven by the rotating helical blades. The spacing between these blades progressively decreases, increasing the compression on the sludge. This pressure buildup causes water to slowly seep out through the gap formed between the stationary and rotating plates, due to the pressure difference. The built-in cleaning mechanism of both the stationary and rotating plates effectively prevents clogging. Finally, once the sludge has been fully squeezed and dried, it is conveyed by the helical blades to the discharge port.
Advantages(Saving)
2.Power-saving:less than 5% of centrifuge.
3.Water-saving:less than 0.1% of belt filter press
4.Saving-drugs:saving around 60%.
5.Compact:saving more than 60% of the investment for dehy-dration room.
6.Non-clogging:processing the facts & oils and fiber sludge perfectly
Product Attribute
| Model Number | DS handling capacity (KG/H) 10000mg/L≤ss≤20000mg/L |
External Dimension L(mm)×W(mm)×H(mm) | Net Weight(kg) | Operation Weight(kg) |
| PJXDL131 | 7-14 | 1870× 730× 1065 | 250 | 395 |
| PJXDL132 | 14-28 | 2000× 960× 1070 | 420 | 540 |
| PJXDL251 | 15-30 | 2690× 880× 1500 | 550 | 660 |
| PJXDL252 | 30-60 | 2810× 1120× 1500 | 550 | 660 |
| PJXDL301 | 35-70 | 3310× 1000×1700 | 900 | 1300 |
| PJXDL302 | 70-140 | 3460× 1270×1700 | 1350 | 2000 |
| PJXDL303 | 105-210 | 3630× 1620× 1700 | 1900 | 2700 |
| PJXDL304 | 140-280 | 3960× 2040× 1750 | 2500 | 3600 |
| PJXDL351 | 60-120 | 3610× 1100× 1850 | 1100 | 2000 |
| PJXDL352 | 120-240 | 3820×1410×1850 | 2100 | 3250 |
| PJXDL353 | 180-360 | 4120×1770×1850 | 3100 | 4600 |
| PJXDL354 | 240-480 | 4320× 2290× 1850 | 4100 | 5700 |
| PJXDL401 | 80-160 | 4550×1160×2250 | 2200 | 4200 |
| PJXDL402 | 160-320 | 4870×1680×2250 | 3500 | 6000 |
| PJXDL403 | 240-480 | 4790×2550×2250 | 5500 | 8000 |
| PJXDL404 | 320-640 | 4840×3120×2250 | 7000 | 9500 |
Yangzhou Pujiang Environmental Protection Technology Co., Ltd. is situated in Yangzhou, a city adjacent to Shanghai, China. The company boasts robust production capabilities, advanced workshop infrastructure, and a wide range of processing units. Quality is central to Pujiang’s operations, and a comprehensive system for process control and management spans from R&D and material sourcing through production to final quality checks. The company specializes in environmental machinery, such as sludge handling systems and wastewater treatment solutions.
Q: Are you trading company or manufacturer?
A: We are factory. We are professional manufacturer which specializes in producing waste water treatment equipments.
Q: Where is your factory located?
A: Yangzhou City, which is very close to Shanghai with only less than 3 hours' driving.
Q: Do you provide OEM service?
A: Yes. Any required logos are available.
Q: How about the production capacity of your company?
A: We produces machines more than 30000 sets per year.
Q: How could we trust you and your company? This is first time transaction?
A: With decades of dedicated expertise, we've served more than 1,000 clients across China and international markets. Our products are shipped to nearly 40 countries globally. We warmly invite you to explore our facility and see our manufacturing operations at any time.
Q: Do you offer after-sales service?
A: Yes. Engineers available for technology assistence.
Q: How long is your warranty?
A: One year after the arrival of the goods.
Q: What about your delivery Time?
A: Normally within 45 days against down payment.
Q: What about the package of your export product?
A: Normally we use anticorrosion wooden case.
Q: What kind of payment do you accept?
A:Normally we do T/T, L/C.
Q: What kind of transportation do you offer?
A: Customers decide freight mode, Air&express & Sea .
