Nail File

Manufacturing Features
CNC FULLY GROUND, tolerance controlled at. 005-. 001mm
Made from Tungsten Carbide K20 Micrograin( hardness>90HRC). Solid up to 6mm;
With steel shank welded to the burr startin from 8mm.
Size of the sha 6*40mm or 6*100mm(Long Serious).
Nine different cut are availiable( Standard Single, Fine Single, Coarse cutter, Chip Breaker, Double-Cut(Cross) Coarse Double-cut, Fine Double-Cut, Diamond Cut, Non-Ferrous-Aluminium Cut).
All the burrs are availiable also with a Titanium Nitride coating(Tin), that makes them tougher reduces surface friction or with Titanium Nitride and Aluminium coating( TiALN), that makes the burrs frictionless and prevents binding.
We recommend to careful choose the cut of the burrs, according to the material to be worked.

INTRODUCTION TO TUNGSTEN CARBIDE ROTARY BURRS<o: P>

Rotary Burrs also called debur is a grinding tools used by Pneumatic or electric Grinder. <o: P>
Usages: <o: P>
For milling, deburring, break edges, trim process welding seams, and surface processing. <o: P>
Applications: For High-alloy steels, non-rusting steels, acid-resistant steels, heat-resistant steels, diecasis, roughing
Steels stainless steel, aluminium, light alloys, non-ferrous metals brass, copper, zinc, diecasts and plastics. <o: P>
Manufacturing Features: <o: P>
LCNC FULLY GROUDING, Tolerance controlled at. 005-. 001mm<o: P>
LMade from Tungsten Carbide K20 Micrograin (hardness >90 HRC). Solid up to Ø 6 mm; <o: P>
Lwith steel shank welded to the burr startin from Ø 8 mm. <o: P>
LSizes of the sha 6x40 mm or 6x100 mm (Long Series). <o: P>
LNine different cut are available (Standard Single, Fine Single, Coarse cutter, Chip Breaker, Double-Cut(Cross)
Coarse Double-cut, Fine Double-Cut, Diamond Cut, Non-Ferrous-Aluminium Cut). <o: P>
LAll the burrs are available also with a Titanium Nitride coating (TiN), that makes them tougher reduces surface
Friction or with Titanium Nitride and Aluminium coating (TiAlN), that makes the burrs frictionless and prevents binding. <o: P>
We recommend to careful choose the cut of the burrs, according to the material to be worked.



Single StandardSingle <o: P> Fine<o: P>Single Coarse<o: P>Chip Breaker<o: P>
Double Standard
Standard cut is a
General purpose
Tool designed for
Cast iron, copper,
Brass and other
Ferrous materials.
It will give good
Material removal
And good work
Piece finishes.
Fine cut improves
Finishes on hardened
Steel, stainless steel
And cast iron.
Operator control
Is improved.
Coarse cut is
Recommended
For use on soft
Material such as
Copper, brass,
Aluminum, plastics
And rubber where
Chip loading
Is a problem.
Chip breaker cut
Will reduce sliver
Size and improve
Operator control
At a slightly reduced
Surface finish.
Standard double
Cut allows for rapid
Stock removal and
Better operator control.
Chip size is reduced
And tool speed can
Be slower than
Normal speeds.

Double<o: P> Coarse<o: P> Double<o: P> Fine<o: P> Aluminium Cut
(Non-Ferrous)<o: P>
Diamond Cut<o: P>

Coarse double cut
Is for fast stock
Removal in
Soft materials.
Allows good
Operator control
And produces
Small chips.

Fine double cut is
Very effective on
Heat treated and
Tough alloy steels.
Chip size is
Reduced and it
Offers good
Operator control.

Aluminium cut is for
Use on non-ferrous
And non-metallic
Materials. It is
Designed for rapid
Stock removal with
Minimum chip
Loading.

DIAMOND CUT
Is very effective
On heat treated
And tough alloy
Steels. It produces
Very small chips
And good operator
Control. Surface
Finish and tool
Life is reduced.
