OLG 3 OLTC Distribution Transformer Phase 3 Brand OLG Power 300 AMP Rated Voltage 11 Kv Dimension Of Oltc View Oil Quantity 290
1 Unit
$2,090Product information
High-quality OLG 3 OLTC Distribution Transformer Phase 3 Brand OLG Power 300 AMP Rated Voltage 11 Kv Dimension Of Oltc View Oil Quantity 290 supplied by Volt Star. Bulk wholesale pricing is $2,090 per Unit with a minimum order of 1 Unit. Inquiry for latest prices.
Rated Voltage:
11 Kv
Maximum Number Of Tap Positions:
17
Rated Through Current:
200 A
Rated Insulation Level:
28 Kv (tap-changer To Earth), 28 Kv (between Phases), 25 Kv (between First And Last Contact), 20 Kv (between Any Two Adjacent Contacts), Na (between Contacts Of Change-over Selector)
Oil Quantity:
290 Liters
Phase:
3
Power:
300 AMP
Max Rated Step Voltage:
300 V
Specifications
Rated Voltage:
11 Kv
Maximum Number Of Tap Positions:
17
Rated Through Current:
200 A
Rated Insulation Level:
28 Kv (tap-changer To Earth), 28 Kv (between Phases), 25 Kv (between First And Last Contact), 20 Kv (between Any Two Adjacent Contacts), Na (between Contacts Of Change-over Selector)
Oil Quantity:
290 Liters
Phase:
3
Power:
300 AMP
Max Rated Step Voltage:
300 V
Switching Capacity:
35 Kva
Weight Of Tap Changer With Oil:
610 Kgs.
Full Wave Lightning Impulse Test:
75 Kv (tap-changer To Earth), 75 Kv (between Phases), 70 Kv (between First And Last Contact), 50 Kv (between Any Two Adjacent Contacts), Na (between Contacts Of Change-over Selector)
Tapping Arrangement:
Linear
Brand:
OLG
Trade Term:
To be discussed
Payment Term:
To be discussed
Direction Of Power Flow:
Uni-directional
Dimension Of Oltc:
View
Business Details
Country:
India
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2012
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
Not specified
Port Of Loading:
Not specified
Product descriptions from the supplier
| Rated voltage | 11 kV | ||
|---|---|---|---|
| Rated through-current | 200 A | ||
| Direction of power flow | Uni-Directional | ||
| Tapping arrangement | Linear | ||
| Maximum Number of Tap Positions | 17 | ||
| Max. Rated Step Voltage | 300 V | ||
| Switching Capacity | 35 KVA | ||
| Rated Insulation level | Applied voltage (KV) | Full wave lightning impulse test (KV) | |
| (a)Tap-changer to Earth | 28 | 75 | |
| (b)Between phases | 28 | 75 | |
| (c)Between First and Last Contact | 25 | 70 | |
| (d)Between any two adjacent contacts | 20 | 50 | |
| (e)Between contacts of Change-Over selector | NA | NA | |
| Oil quantity | 290 liters | ||
| Weight of tap changer with oil | 610 Kgs. | ||
| Dimension of OLTC | VIEW | ||
