Optical Fiber/High Oh Optical Fiber/High Temperature Optical Fiber/Medical Fiber/High Power Optical Fiber
1 Piece
$500Product information
High-quality Optical Fiber/High Oh Optical Fiber/High Temperature Optical Fiber/Medical Fiber/High Power Optical Fiber supplied by Shanghai Anttrans Technology Co., Ltd. Bulk wholesale pricing is $500 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Specification:
100mm-50m per pcs
Package Gross Weight:
12.000kg
Output Power:
1MW-100000W
Production Capacity:
50000PCS/Year
Package Size:
55.00cm * 55.00cm * 20.00cm
Model NO.:
AT-OF-0002#
Brand:
Anttrans
Trademark:
Anttrans
Specifications
Specification:
100mm-50m per pcs
Package Gross Weight:
12.000kg
Output Power:
1MW-100000W
Production Capacity:
50000PCS/Year
Package Size:
55.00cm * 55.00cm * 20.00cm
Model NO.:
AT-OF-0002#
Brand:
Anttrans
Trademark:
Anttrans
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, CIF
Materials:
Hpfs
Payment Term:
LC, T/T, D/P, PayPal
Bundle Type:
N-All-1
Certification:
RoHS, CE, ISO9001, CCC
Material Shape:
Round Wire
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Transport Package:
Wooden Case
Allowed Lateral Pressure:
as Per Demands
Sheath Material:
as Per Request
Connection Structure:
as Per Request
Allowed Tensile Strength:
as Per Request
Core:
as Per Request
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2024-11-08
Annual Revenue Amount:
Not specified
Numbers Of Employees:
5
Preferred Payment Term:
LC, T/T, D/P, PayPal
Preferred Trade Term:
FOB, CIF
Port Of Loading:
Shanghai Port
Certificates:
01-Anttranstech Quality Warranty Certification, 04. Anttranstech Audit Report Certification, 05. Anttranstech Products Conformity Certification, 06. Anttranstech Semiconduction Silicon Wafers Products Warranty Certiification, 07. Anttranstech Semiconduction Quartz Wafers Products Warranty Certiification, 08. Anttranstech Semiconduction AlN Wafers Products Warranty Certiification, 08. Anttranstech Semiconduction SIC Wafers Products Warranty Certiification, 10. Anttranstech Semiconduction Photomask Wafers Products Warranty Certiification
Product descriptions from the supplier
Anttranstech Optical Fibers for special applying fields, also called special optical fibers.
The birth of special optical fibers is to meet specific application requirements, such as use in extreme environments or situations that require special performance. Traditional optical fibers cannot meet the requirements in certain special environments. Manufacturers improve their performance by changing the design of optical fibers or using special materials to produce special optical fibers.
The working principle of special optical fibers is basically the same as that of traditional optical fibers, both transmitting optical signals through the principle of total reflection. However, special optical fibers usually have special designs or materials that enable them to exhibit superior performance in specific environments or applications. For example, some special optical fibers use special fiber materials such as silicon-based, fluoride, or heavy metal glass to improve their performance in extreme environments.
The important parameter indicators of special optical fibers mainly include loss, digital to analog, refractive index, temperature range, fiber diameter, etc. Loss refers to the loss of light energy in optical fibers during transmission, digital analog refers to the propagation mode of light waves inside the fiber, refractive index refers to the refractive ability of the fiber material towards light, temperature range refers to the temperature range at which the fiber can operate normally, and fiber diameter refers to the physical size of the fiber.
Special optical fibers are widely used in various fields, including communication, medical, laser, automation industry, new energy vehicles, AI intelligence, machine vision, high-temperature furnaces and reactors, etc. In the field of communication, special optical fibers can be used for long-distance fiber optic communication or communication in extreme environments. In the medical field, special optical fibers can be used for endoscopy, laser therapy, and other applications. In the field of lasers, special optical fibers can be used for submarine communication, laser guidance, and so on. In the industrial field, special optical fibers can be used for sensing and laser cutting in high-temperature environments.
Special optical fibers can be mainly divided into the following categories based on their performance and applications: high-temperature fibers, extremely low loss fibers, multimode fibers, maximum mode field diameter fibers, polarization maintaining fibers, fiber optic sensors, etc.
Our company generally operates some general projects: technical services, technology development, technology consulting, technology exchange, technology transfer, technology promotion: computer Wholesale of software, hardware, and auxiliary equipment: Retail of computer software, hardware, and auxiliary equipment: Import and export of goods: Import and export of technology: Credit Information consulting services (excluding licensing information consulting services): graphic and textual design and production: sales of functional glass and new optical materials Selling; Sales of optical instruments; Sales of specialized equipment for semiconductor devices: sales of experimental analysis instruments: sales of CNC machine tools: sales of instruments Sales of instruments and meters; Sales of electronic components and electromechanical equipment; Sales of metal cutting and welding equipment; Fiber optic sales;Sales of photovoltaic equipment and components; Sales of optical glass; Sales of electronic specialized materials.
Main Advantages:
(1). Satisfy special application scenarios and functional requirements..
(2). Strong promptly delivery ability
(3). Excellent OEM and ODM ability, 100% matching with customers' requests
(4).Be able to used in extreme environment and needs.
(5).Small qty., prototype,special request customized-manufacturing can be accepted.
General Technical Parameters:
ANTTRANSTECH mainly produces special optical fibers based on HPFS. These fiber core materials are divided into low hydroxyl, medium hydroxyl, high hydroxyl, as well as fluorine doped, ytterbium doped, erbium doped, etc. These optical fibers have excellent transmittance across the entire wavelength range from extreme ultraviolet to far-infrared. By using different coating layers (including acrylic, carbon, silver, aluminum, copper, gold, etc.), our optical fibers can be suitable for special needs in different temperatures, interference levels, and extreme environments
The categories are following: :
| No. | Core Materials | Doped Type | Wave Band | Output Power | Temperature-resistant |
| (1). | Ultra-Low OH | Fluorine doped | 150-190nm | <100w | <350Celsuis degrees |
| (2). | Low OH | Erbium doped | 190-1200nm | <200W | <450Celsuis degrees |
| (3). | Middle OH | Ytterbium | 200-1400nm | <300W | <550Celsuis degrees |
| (4). | High OH | Customized | 355nm | <500W | <650Celsuis degrees |
| (5). | Ultra-high OH | 400-700nm | <1000w | <750Celsuis degrees | |
| (6). | Customized | 650nm | <3000w | <850Celsuis degrees | |
| (7). | 880nm | <5000w | <950Celsuis degrees | ||
| (8). | 940nm | <10000w | <1000Celsuis degrees | ||
| (9). | 970nm | <10,000w | <1100Celsuis degrees | ||
| (10). | 1064nm | Customized | Customized | ||
| (11). | 1310nm | ||||
| (12). | 1550nm | ||||
| (13). | 2200nm | ||||
| (14). | Other Customized |
Main Applying Fields:
Special optical fibers are used to manufacture sensing fiber optic devices, such as pressure and temperature sensors, as well as fiber optic gyroscopes, hydrophones, etc.
In the aerospace field, polarization maintaining fibers play an important role as the core component of fiber optic gyroscopes. In addition, high-temperature resistant fibers, bending insensitive fibers, radiation resistant fibers, and ultraviolet fibers are also widely used.
Polarization maintaining fiber is one of the most mature and widely used special fibers in technology, and it is also the main material for manufacturing fiber rings in fiber optic gyroscopes. The manufacturing process of fiber optic rings is quite complex, and solving the problem of fiber optic wrapping is the key to improving the accuracy of fiber optic gyroscopes. In the field of guided weapons, the application of fiber optic gyroscopes is also very common. Fiber optic rings and special optical fibers, as the core components of fiber optic inertial navigation, are considered as "bottlenecks" in key technologies.
Special fiber is a key component of fiber lasers and is widely used in the manufacture of fiber optic communication devices, such as optical amplifiers and wavelength converters; Special optical fibers are used in the medical field to produce medical fiber optic devices such as endoscopes.
Signal transmission type: constructing a human physiological monitoring system through embedded fiber optic network
Luminescence therapy type: applied to jaundice blue light therapy, wound healing therapy, and photodynamic therapy for skin diseases through wavelength modulation technology
Biosensing type: including three types of sensors: grating (FBG), macro bending, and micro bending. The FBG sensor can detect body temperature, while the macro bending sensor has been used in the development of real-time respiratory monitoring systems
Medical laser fiber optic connector: responsible for coupling with the laser generator optical path
Medical laser fiber optic transmission body: flexible light guiding medium with a diameter of 0.2-1.5mm
Medical laser handle: integrated control and safety protection device
Medical laser treatment head: The divergence angle and power density parameters of the system should be configured according to different conditions, and the overall system should comply with the sterilization standards for disposable medical devices. The core material is mainly fused quartz glass, and fluoride glass fiber optic is used in some scenarios.
Clinical application scenarios
Skin beauty: Erbium laser (2940nm) used for epidermal repair and scar treatment
Urology: Holmium laser (2100nm) fiber optic for non-invasive lithotripsy surgery
Vascular treatment: closure of varicose veins in the lower limbs with 1470nm wavelength laser
Minimally invasive tumor treatment: 980nm semiconductor laser ablation is applied to solid tumors such as liver cancer. Compared with traditional surgical methods, fiber optic intervention therapy has the advantages of minimal trauma and fast recovery.
Manufacturing sensing fiber optic devices, such as pressure and temperature sensors, as well as fiber optic gyroscopes, hydrophones, etc.
The core components of manufacturing fiber optic gyroscopes play an important role, and in addition, high-temperature resistant fibers, bending insensitive fibers, radiation resistant fibers, and ultraviolet fibers are also widely used.
The key part of manufacturing fiber lasers is also widely used in manufacturing fiber optic communication devices, such as optical amplifiers, wavelength converters, etc; Special optical fibers are used in the medical field to produce medical fiber optic devices such as endoscopes.
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Mexico, Brazil, Argentina, India, Portugal, Canada, New Zealand, South Africa, UAE, Egypt, Norway, Netherland, Australia, Turkey, Finland, Denmark, Poland ,etc.
Payment Method: by T/T, L/C, Western Union,etc.
Trade Terms: EXW, FOB, CNF, CIF, FCA,DDU,DDP,etc accepted.
Delivery time: 8 Weeks.
Quality Warranty: Anttranstech provides full quality warranty and post-sale service for our lasers products.
Anttranstech' s "5-R" post-sale policy for any inferior-quality products, "Research, Return, Re-do, Replacement & Refund" can be executed.
