Overhead Pole Mounted Cutout Fuse Holders
Piece
Negotiable
Product information
High-quality Overhead Pole Mounted Cutout Fuse Holders supplied by Cowin Electrical Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
20000sets/Month
Size Of Fuse:
82mm
HS Code:
85361000
Type:
Auto Fuse Holder
Execution Standard:
BS
Form Of Installation:
Bolted
Model NO.:
CEC-400
Trademark:
Cowinelec
Specifications
Production Capacity:
20000sets/Month
Size Of Fuse:
82mm
HS Code:
85361000
Type:
Auto Fuse Holder
Execution Standard:
BS
Form Of Installation:
Bolted
Model NO.:
CEC-400
Trademark:
Cowinelec
Brand:
Cowinelec
Installation:
Cut out
Environmental Protection:
Environmental Protection Fuse Holder
Fusing Speed:
F
Trade Term:
FOB, CFR, CIF
Transport Package:
Foam Safety Boxes
Payment Term:
LC, T/T, PayPal, Western Union
Specification:
Max 415A
Shape:
Square
Origin:
Wenzhou, China
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union
Preferred Trade Term:
FOB, CFR, CIF
Port Of Loading:
Not specified
Product descriptions from the supplier
Product Description
Cutout Fuse and base
Product Description
J wedge fuse is according with GB13539, IEC60269 and BS88 standard.
The product has been used for overload and short circuit protection of distributing line. its rated voltage is 415V and rated current up to 415A AC 50Hz.
Technical Data
Rated voltage:415V AC
Breaking capacity:80KA
Function grade:gG /gL/gtr/aM/gM
CEC-400
400A Fuse cut-out for pole or wall mounting c/w M12 coach screw.
Structure Feature
Vandal resistant tough design, using our own formulation of GRP.
Slide fit front cover for ease of jointing.
'Easy fit' studs accept cable sockets(lugs) up to 300mm².
Designed to accept standard 'J' type fuse links
Compliant with the requirements of BS7656:1993
Compliant with the design criteria of IP43
Fuse links
This fused Cut-out is designed to accommodate standard wedge type fuse links to BS88-5:1988, conform to 415AC80.
Fixing centre requirement is 82mm.
Standard fuse link rating range from 20A to 400A.
Product Description
J wedge fuse is according with GB13539, IEC60269 and BS88 standard.
The product has been used for overload and short circuit protection of distributing line. its rated voltage is 415V and rated current up to 415A AC 50Hz.
Technical Data
Rated voltage:415V AC
Breaking capacity:80KA
Function grade:gG /gL/gtr/aM/gM
| Type | Spec | Competitor part number | Rated voltage(V) | Class rating(A) | Dimensions(mm) | |||||||||||
| A | B | C | D | E | F | G | H | I | J | K | L | |||||
| J | 82 | RGJ | 415 | 32~200 | 110 | 82 | 45.2 | 40.5 | 30 | 14.8 | 18 | 6.5 | 2.4 | 17.5 | 9.8 | 30.8 |
| J | 82 | RGJ | 415 | 200~400 | 110 | 82 | 44.8 | 40 | 30 | 14.4 | 18 | 6.5 | 2.4 | 17.5 | 9.8 | 38 |
| J | 92 | RGJ | 415 | 20~315 | 131 | 92 | 46.8 | 40.5 | 41 | 17.4 | - | 8.7 | 3.2 | 20.7 | 11 | 30.8 |
| J | 92 | RGJ | 415 | 355~400 | 131 | 92 | 46.4 | 40 | 41 | 17.4 | 24 | 8.1 | 3.2 | 20.7 | 10 | 38 |
| J | 92 | RGJ | 415 | 315~500 | 131 | 92 | - | 45 | 38 | 16.5 | 22 | 8 | 3.2 | 20.6 | 11 | 50 |
| J | 92 | RGJ | 415 | 560~630 | 129 | 92 | 44.5 | 47.8 | 38 | 16.5 | 22 | 8 | 3.2 | 20.6 | 11 | 73.3 |
CEC-400
400A Fuse cut-out for pole or wall mounting c/w M12 coach screw.
Structure Feature
Vandal resistant tough design, using our own formulation of GRP.
Slide fit front cover for ease of jointing.
'Easy fit' studs accept cable sockets(lugs) up to 300mm².
Designed to accept standard 'J' type fuse links
Compliant with the requirements of BS7656:1993
Compliant with the design criteria of IP43
Fuse links
This fused Cut-out is designed to accommodate standard wedge type fuse links to BS88-5:1988, conform to 415AC80.
Fixing centre requirement is 82mm.
Standard fuse link rating range from 20A to 400A.
