PE Film Heat Shrink Tunnel Packaging Wrapping Machine for Water Bottles Cans Packaging Semi-Automatic
1 Piece
$5,5001 Piece
$6,000Product information
High-quality PE Film Heat Shrink Tunnel Packaging Wrapping Machine for Water Bottles Cans Packaging Semi-Automatic supplied by Jiangsu Sinopak Tec Machinery Co, Ltd.. Bulk wholesale pricing ranges from $5,500 to $6,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Warranty Time:
12 Months
Bottle Size:
200ml-2000ml
Specification:
2500*730*1580
Package Size:
255.00cm * 75.00cm * 158.00cm
Weight:
350kg
Production Capacity:
4- Bags /Minute
Package Gross Weight:
400.000kg
Automatic Grade:
Automatic
Specifications
Warranty Time:
12 Months
Bottle Size:
200ml-2000ml
Specification:
2500*730*1580
Package Size:
255.00cm * 75.00cm * 158.00cm
Weight:
350kg
Production Capacity:
4- Bags /Minute
Package Gross Weight:
400.000kg
Automatic Grade:
Automatic
Transport Package:
Carton
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Driven Type:
Electric
Adjust Speed:
Electronic Speed Control
Trade Term:
FOB
Packaging:
Film
Manner Of Packing:
Film Shrink Packaging
Application:
Food, Alcohol, Toy, Chemical, Apparel, Gifts & Arts
Type:
PE Shrink Film Machine
Bottle Material:
Pet
Packaging Material:
Plastic
Model NO.:
SP-10A
Trademark:
Sinopak
Heating Mode:
Stainless Steel Heating
Payment Methods:
Support payments in USD
Payment Term:
To be discussed
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2014-07-09
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
Environmental Management System Certification Certificate, High tech enterprises, Intellectual Property Management System Certification, Jiangsu Private Technology Enterprises, Machinery directive attestation of conformity, Occupational Health and Safety Management System Certification, quality management system certification, Utility Model Patent Certificate
Product descriptions from the supplier
3-in-1 filling machine, combined with rinsing, filling and capping. It is used for mineral water, pure water, and other drinking water filling in PET bottles ranges from 200ml-2L, and capacity from 2000-42000BPH.
Main features
Machine discription :
Specially designed for packaging production line of beer, beverage, pure water, fruit juice, dairy products, etc.
With full automatic functions of bottle transfer and arrange, membrane packing, sealing and cutting, shrinkage, cooling and shaping, etc.
Using advanced constant temperature membrane heat binding technology in the world with clear and secure sealing.
Adopt with PLC automatic program circulation control with stable and reliable performance.
The original imported guide bar cylinder guarantee correct operation and durable using.
The hot shrink film packaging machine adopts the shrink packaging method of the upper and lower two films. Our model can apply different sizes of PE shrink film, and the equipment parameters can be adjusted according to the size of the bottle.
- Suitable to PE PVC film packaging.
- PLC control system, automatic working.
- Colorful touch-screen control panel, easy operate.
- Bottle entering, Auto unscrambling bottle, Pushing bottle, Heat sealing-Saw cutting, Pressing PE, Shrink, Cooling automatically
- Capacity is adjustable through adjust the convey speed
- The height of the conveyor shall be made towards client's demand, can handle 6, 9,12,15, 18, 20, 24 bottle per package
- Double air blowers, guarantees the temperature balance in the shrink stove with PAD temperature controller that apparently saves energy.
- The height of the conveyor shall be made towards client's demand.
- Heavy duty coated iron machine construction
- It applies wing shape stainless steel heating system, which is durable for long time use.
Feature details
1) The machine has compact structure, perfect control system, convenient operation and high automation .
2) Parts in contact with materials are made of imported high quality stainless steel, no process dead Angle, easy to clean.
3) High precision, high speed quantitative filling valve, accurate liquid level without liquid loss, to ensure excellent filling quality.
4) The capping head adopts constant torque device to ensure the capping quality.
5) Adopt efficient capping management system, with perfect cap loading technology and protection device.
6) It is not necessary to adjust the height of the equipment to change the bottle size. It can be realized by replacing the star wheel of the bottle, which is simple and convenient to operate.
7) The filling system adopts the bottle - bottling technology to avoid the secondary pollution of the bottle mouth.
8) The control system has the functions of automatic water level control, missing cap detection, automatic stop of bottle flushing and output counting.
9) The bottle washing system adopts the efficient cleaning spray nozzle produced by American spray Company technology, which can be cleaned to every place in the bottle.
10) The main electrical components, electronic control valves, frequency converters and so on are imported parts to ensure the excellent performance of the whole machine.
11) All components of pneumatic system adopt international famous products.
This machine integrated three function: 1. Rinse the empty pet bottle, 2. filling the rinsed bottles, 3. capping the filled bottles
2) Parts in contact with materials are made of imported high quality stainless steel, no process dead Angle, easy to clean.
3) High precision, high speed quantitative filling valve, accurate liquid level without liquid loss, to ensure excellent filling quality.
4) The capping head adopts constant torque device to ensure the capping quality.
5) Adopt efficient capping management system, with perfect cap loading technology and protection device.
6) It is not necessary to adjust the height of the equipment to change the bottle size. It can be realized by replacing the star wheel of the bottle, which is simple and convenient to operate.
7) The filling system adopts the bottle - bottling technology to avoid the secondary pollution of the bottle mouth.
8) The control system has the functions of automatic water level control, missing cap detection, automatic stop of bottle flushing and output counting.
9) The bottle washing system adopts the efficient cleaning spray nozzle produced by American spray Company technology, which can be cleaned to every place in the bottle.
10) The main electrical components, electronic control valves, frequency converters and so on are imported parts to ensure the excellent performance of the whole machine.
11) All components of pneumatic system adopt international famous products.
Water Treatment System
1 Raw water tank + Raw water pump
2 Silica sand filter + Active carbon filter + Sodium ion exchanger + Precision filter + Security filter
3 Reverse Osmosis(Hollow ultrafiltration)
4 UV sterilizer
5 Finished water tank + Pure water pump
1 Raw water tank + Raw water pump
2 Silica sand filter + Active carbon filter + Sodium ion exchanger + Precision filter + Security filter
3 Reverse Osmosis(Hollow ultrafiltration)
4 UV sterilizer
5 Finished water tank + Pure water pump
Bottle Blowing Machine
Bottle blowing machine is to make plastic bottles for mineral water, carbonated drink, juice and so on. It is widely used in the food and beverage package industry.
Bottle blowing machine is to make plastic bottles for mineral water, carbonated drink, juice and so on. It is widely used in the food and beverage package industry.
Automatic 3 in 1 Filling Machine
This machine is specially designed for the filling of pure water, mineral water and other non-gas and sugar free bveverages in bottles, it is an integrated equipment for bottle washing, filling and capping.
This machine is specially designed for the filling of pure water, mineral water and other non-gas and sugar free bveverages in bottles, it is an integrated equipment for bottle washing, filling and capping.
Labeling Machine
There are mainly three kinds labeling machine, PVC sleeve shrink labeling machine, sticker labeling machine and OPP hot glue labeling machine.
Customers can choose according to their own production capacity and label material.
All of our label machines run very stable, easy to operate, to meet the needs of different customers.
There are mainly three kinds labeling machine, PVC sleeve shrink labeling machine, sticker labeling machine and OPP hot glue labeling machine.
Customers can choose according to their own production capacity and label material.
All of our label machines run very stable, easy to operate, to meet the needs of different customers.
High laser power
The laser power is controlled by software, continuously adjustable
Low processing costs, without any marking supplies
Carving depth range to manipulate the tag
Clear, not easy to wear and long life
Can adapt to a variety of products
The laser power is controlled by software, continuously adjustable
Low processing costs, without any marking supplies
Carving depth range to manipulate the tag
Clear, not easy to wear and long life
Can adapt to a variety of products
Packaging Machine
There are mainly two kinds of case packing machine, film shrink wrapping machine and carton packing machine.
For film shrink wrapping machine, there is also with for unprinted film and for printed film, then there is also shrink film with carton tray. For carton packing machine, there is tape sealing type and hot glue sealing type.
Parameter
Technical Parameter
| Item | Parameter |
| Capacity: | 4-5p/min |
| Suitable to Plastic Thickness | 0.03- 0.15mm |
| Max packaging dimension | L×W×H(mm) 600×400×350 |
| Working Air Pressure | 0.6-0.8Mpa, 0.8cube meter air per minute |
| Sealing Time needed & temperature: | 0.5 to 1.5 sec, 140oC-160oC |
| Machine Dimension L×W×H(mm) | L2500mm×W730mm×H1580mm |
| Total Power: | 17Kw |
| Power Supply | 380V 50hz 3phase 220V/60HZ |
| weight | 350kg |
A to Z layout
Q1: Do you have reference project?
A1: We have reference project in most countries,If we get the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
And you are always welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.
Contact our sales people you can get video of our reference running machine
Q2: Do you have agent and after-service stations?
A2: So far we have agent in Yemen,Nigeria,Dubai,India,Kenya,Dubai welcome to join us!
Q3: Do you provide customized service
A3: We can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.
Q4: What's your guarantee or the warranty of the quality if we buy your machines?
A4: We offer you high quality machines with 1 year guarantee and supply life-long technical support.
Q5: How long time for installation?
A5: According your machines order,we will send one or two engineers to your plant,it will take about 10 days to 25 days.
Jiangsu Sinopak Tec Machinery Co Ltd is located in the national level development zone of Zhangjiagang city, Jiangsu Province. which has developed industry, good environment, and convenient transportation. It is convenient to transportation, just one hour trip from Wuxi Sunan Shuofang International Airport, Shanghai Hongqiao International Airport, Shanghai Pudong International Airport.
Sinopak Tec is a professional filling & packaging machine manufacturer from China, who dedicated to manufacture kinds of filling & packaging equipment & water treatment system &different beverage making system &bottle making machine. Sinopak has built in 2006, with over 8000 square meters modern standard workshop & over 60 workers.Sinopak Tec is a professional filling & packaging machine manufacturer from China, who dedicated to manufacture kinds of filling & packaging equipment & water treatment system &different beverage making system &bottle making machine. Sinopak has built in 2006, with over 8000 square meters modern standard workshop & over 60 workers.
Factory
To help our customers build an ideal factory. With efficient cost control, we have found the right balance with our customers: diversified production range, high-class packaging forms. Meanwhile market competitivness has been improved because of the efficient operation mode of equipments.
