PIC16F877A Primer Microcontroller Boards Relay Count 2 Analog Input Count 2 Logic Output Count 8 Digital Input Count 8 I2c Eeprom Module
Negotiable
Product information
High-quality PIC16F877A Primer Microcontroller Boards Relay Count 2 Analog Input Count 2 Logic Output Count 8 Digital Input Count 8 I2c Eeprom Module supplied by Pantech Prolabs India Private Limited. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Clock Frequency:
10mhz Crystal, Max 20 Mhz
Analog Input Count:
2
Relay Count:
2
I2c Eeprom Module:
24c04
Spi Eeprom Module:
25c040
Lcd Display:
2x16 Character Lcd With Background Light
Seven Segment Display Count:
4
Socket Type:
40pin-sif Socket
Specifications
Clock Frequency:
10mhz Crystal, Max 20 Mhz
Analog Input Count:
2
Relay Count:
2
I2c Eeprom Module:
24c04
Spi Eeprom Module:
25c040
Lcd Display:
2x16 Character Lcd With Background Light
Seven Segment Display Count:
4
Socket Type:
40pin-sif Socket
Expansion Connector:
4x10-pin
Keypad Type:
4x4 Matrix Keypad
Digital Input Count:
8
Logic Output Count:
8
Flash Memory Size:
8k-32k
Stepper Motor Interface:
Available
Rtc Module:
Ds1307 With Battery Backup
Digital Temperature Sensor:
Ds18s20
Supported Programming Languages:
Embedded C, Asm
Real Time Application Support:
Evaluate Real Time Applications
External Device Interface:
Facility To Interface External Devices
Interrupt Features:
Interrupts Study And Reset Button
Programming Support:
Isp, Spi, I2c
Temperature Sensor Type:
Lm35
Supported Mcus:
Pic16f877a, Pic18f452, Pic18f4341
Buzzer Type:
Piezo Electric
Analog Input Type:
Potentiometer
Trade Term:
To be discussed
Payment Term:
To be discussed
Serial Communication Interface:
Usart Rs232
Usb Programmer:
Usb 2.0 Enabled
Business Details
Country:
India
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2014
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
Not specified
Port Of Loading:
Not specified
Product descriptions from the supplier
Key Features
- 40pin-SIF Socket
- 8 Nos. Point LEDs (Logic Output)
- 8 Nos. Digital Input (DIP Switch)
- 4x4 Matrix Keypad
- 2X16 Character LCD (Background Light)
- 4 Nos. 7-Segment Display
- 2 Nos. Analog Input (Potentiometer)
- Temperature Sensor (LM35)
- Stepper Motor Interface
- 2 Nos. of SPST Relay
- DS1307 RTC with Battery-Backup
- USART(RS232)
- USB 2.0 Enabled Programmer
- Interrupts Study, Reset Button
- SPI – EEPROM.25C040
- I2C EEPROM 24C04
- Digital Temperature Sensor(DS18S20)
- 4x10-Pin Expansion Connector
- Piezo Electric Buzzer
- Evaluate Real Time Applications
- Supports Embedded C, ASM
- ISP Programming | SPI | I2C Communications
- Facility to interface external devices
- Devices :PIC16F877A, PIC18F452, PIC18F4341 Devices compatible with PIC16F877A
- Memory :8K-32K FLASH - Program
- Clock:10MHz crystal, Max = 20 MHz
- PIC16F/18F Development Kit
- Power Adaptor
- RS232 Cable, USB Cable
- User Guide HW/SW
- CD Contains:
