PLA 3D Filament Extruder Plastic 3D Printer Filament Extruder
set
Negotiable
Product information
High-quality PLA 3D Filament Extruder Plastic 3D Printer Filament Extruder supplied by Dongguan Miko Testing Instrument Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Product Size:
1.75/3.0mm Filament
Specification:
2500mm*600mm*1500mm
Screw Diameter:
25mm
Voltage:
3 Phase, 380V
Type:
3D Filament
Usage:
3D Filament
HS Code:
84772090
Automation:
Automatic
Specifications
Product Size:
1.75/3.0mm Filament
Specification:
2500mm*600mm*1500mm
Screw Diameter:
25mm
Voltage:
3 Phase, 380V
Type:
3D Filament
Usage:
3D Filament
HS Code:
84772090
Automation:
Automatic
Origin:
China
Computerized:
Computerized
Screw Channel Structure:
Deep Screw
Exhaust:
Don't Exhaust
Trade Term:
FOB
Product Type:
Granulating Extruder
Assembly Structure:
Integral Type Extruder
Engagement System:
Intermeshing
Model NO.:
MK-8009FE
Feeding Mode:
One Feed
Plastic Processed:
PLA/ABS/PVA/PETG/PA
Control System:
PLC Control
Transport Package:
Plywood Case
Screw:
Single-Screw
Payment Term:
To be discussed
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
Certificate
Product descriptions from the supplier
SONA2024 2.2.1
Lab Plastic 3D Printer Filament Extruder
3D Printing Filament Extruder/ Extruding Machine is mainly used to produce high quality ABS/PLA for all brands of 3D printers.This 3D Printing Filament Extruder/ Extruding Machine has high output and and performance. It can produce ABS/PLA filament with diameter of 1.75 and 3mm. We use laser gauge in the 3D Printer Plastic Filament extruding line to measure the diameter and control the tolerance within 0.03mm.
Specification
Technical Specifications
Model | MK-8009FE-25 | MK-8009FE-45 | |
Screw Diament | 25mm | 45mm | |
L/D | 25:1 | 28:1 | |
Output Capacity | 2.5-3kg/h | 18-20kg/h | |
Processing Raw Materials | ABS/PLA/PETG/WPC | ||
Filament Diameter | 1.75 mm/ 3 mm | ||
Diameter tolerance | ±0.03mm | ||
Main Motor Power | 2.2kW | 11kW | |
Control system | 10inch SIEMENS PLC touch screen | ||
Machine Size | 3m*0.6m*1.8m | 13.5m*1.5m*2.5m | |
Voltage | 3 phase, 380V/50 Hz (can be customized) | ||
Applications
1. Material Development & R&D:Developing and testing new filament formulations for additive manufacturing.
Enables researchers to formulate custom filament materials with specific properties (mechanical, thermal, electrical)
Supports testing of a wide range of materials including PLA, ABS, PETG, PA (Nylon), PEEK, PEKK, TPU, TPE, and composite materials.
Supports testing of a wide range of materials including PLA, ABS, PETG, PA (Nylon), PEEK, PEKK, TPU, TPE, and composite materials.
2. Process Optimization & Parameter Studies: Investigating extrusion parameters to achieve desired filament quality and consistency.
Studies the influence of extrusion temperature, screw speed, cooling rate, and puller speed on filament diameter tolerance and roundness.
Advanced systems feature real-time diameter monitoring with accuracy up to ±0.03 mm and closed-loop control.
Provides critical data for scaling up to production-scale filament extrusion lines.
Advanced systems feature real-time diameter monitoring with accuracy up to ±0.03 mm and closed-loop control.
Provides critical data for scaling up to production-scale filament extrusion lines.
3. Education & Academic Research:Hands-on training and fundamental research in polymer processing and additive manufacturing.
Demonstrates principles of extrusion, polymer melting, rheology, and filament production to students.
Used in materials science, mechanical engineering, and polymer technology programs.
Enables study of process-structure-property relationships: how extrusion parameters affect final filament and printed part performance.
Used in materials science, mechanical engineering, and polymer technology programs.
Enables study of process-structure-property relationships: how extrusion parameters affect final filament and printed part performance.
4. Small-Batch & Pilot Production:Producing small quantities of specialty filaments for prototyping, low-volume manufacturing, or custom applications.
Manufactures custom filaments for
Functional prototyping: Engineering-grade materials (PEEK, PEKK, carbon fiber composites).
Medical devices: Biocompatible filaments (surgical guides, implants, prosthetics).
Specialty products: Conductive, magnetic, glow-in-the-dark, or FDA-approved filaments
Medical devices: Biocompatible filaments (surgical guides, implants, prosthetics).
Specialty products: Conductive, magnetic, glow-in-the-dark, or FDA-approved filaments
5. Material Testing & Quality Control:Testing raw materials and ensuring consistency of filament production.
Validates incoming polymer pellets or recycled materials before production.
Ensures batch-to-batch consistency of filament diameter, ovality, and mechanical properties.
Prepares test specimens for tensile testing, impact testing, and rheological analysis.
Essential for QC laboratories in filament manufacturing facilities.
Ensures batch-to-batch consistency of filament diameter, ovality, and mechanical properties.
Prepares test specimens for tensile testing, impact testing, and rheological analysis.
Essential for QC laboratories in filament manufacturing facilities.
