PVD Coating Selective Absorbing Coating Film for Solar Thermal Collector
100-499 Square Meter
$11500 Square Meter
$10Product information
High-quality PVD Coating Selective Absorbing Coating Film for Solar Thermal Collector supplied by Fujian Summit Metallic Material Science & Technology Co., Ltd. Bulk wholesale pricing ranges from $10 to $11 per Square Meter with a minimum order of 100 Square Meter. Inquiry for latest prices.
Size:
0.4mm
Specification:
0.4mm
Model NO.:
0.4mm
Grade:
1000 Series
Delivery Time:
8-14 Days
Absorptance:
92-96%
Material:
Aluminum Alloy
Surface Treatment:
Coated
Specifications
Size:
0.4mm
Specification:
0.4mm
Model NO.:
0.4mm
Grade:
1000 Series
Delivery Time:
8-14 Days
Absorptance:
92-96%
Material:
Aluminum Alloy
Surface Treatment:
Coated
Processing Service:
Cutting
Color:
Dark Blue
Transport Package::
Exporting Wooden Case
Trade Term:
FOB
Type:
Flat Panel
Origin:
Fujian, China
Use:
Heat Water
Absorber Coating:
Highly Selective Vacuum Coating
Certification:
ISO
Certificate:
ISO9001
Standard:
International Standards
Payment Terms::
L/C, T/T
Working Temperature Range:
N/a
Pipe Material:
N/a
Concentrating:
N/a
Alloy Or Not:
Non-Alloy
Temper:
O-H112
Trademark:
SMMT
Payment Term:
To be discussed
Application:
Water Heater, Solar Thermal, Air Conditioning System
Port::
Xiamen, China
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
Audit Report, certification, ISO9001, patents
Product descriptions from the supplier
Product Description
The key accessory of every solar collectors is the solar absorber. Its efficiency is given by a high absorptive and low emission rate.
SMMT high selective solar absorber "Thermal Collector is manufactured by advanced PVD coating devices, which achieveabsorptive rate up to 95% and heat emission lower than 5%. It is also optimized to the wavelengths of sunlight with the high intensity to bring the maximum heating performance.
The SMMT high-performance solar absorber "Thermal Collector" utilizes continuous air-to-air vacuum deposition systems, enabling fast and efficient coating application. This technology integrates sputtering and electron beam methods to create selective absorber coatings on metal strip substrates.
This kind of PVD still achieves both the high quality of layers and the environment protection.
SMMT will be a reliable long-term cooperation partner for flat plate solar water heater and evacuate tube water heater supplier.
SMMT high selective solar absorber "Thermal Collector is manufactured by advanced PVD coating devices, which achieveabsorptive rate up to 95% and heat emission lower than 5%. It is also optimized to the wavelengths of sunlight with the high intensity to bring the maximum heating performance.
The SMMT high-performance solar absorber "Thermal Collector" utilizes continuous air-to-air vacuum deposition systems, enabling fast and efficient coating application. This technology integrates sputtering and electron beam methods to create selective absorber coatings on metal strip substrates.
This kind of PVD still achieves both the high quality of layers and the environment protection.
SMMT will be a reliable long-term cooperation partner for flat plate solar water heater and evacuate tube water heater supplier.
Product & Applications
Product Parameters
| Product Name | High Selective Solar Absorber | "Thermal collector" |
| Substrate Specification | Material | Aluminum Strip |
| Width[mm] | 1000-1250 | |
| Standard Thickness[mm] | 0.3-1.0 | |
| Standard Alloy | 1050 | |
| Temper | H18 | |
| Density [g/cm3] | 2.7 | |
| Thermal Conductivity [W/(m.K)] | ~230 | |
| Tensile Strength [N/mm2] | >=135 | |
| Yield Strength [N/mm2] | >=100 | |
| Optical Property | Solar Absorptive Rate(%) | 95±2 |
| Heat Emission Rate(%) | 5±2 | |
| Payment Term | TT, LC | |
| Packing | 1. Product surface attached with proctective film 2. Plastic film sealed 3. Anti-collision foam 4. Drying agent 5. Seaworthy exporting wooden case | |
| Delivery Time | Future goods: 25-35 work days; Ready Stock: 7- 10 days | |
