Package Unit Air Conditioning System Condition New Noise Level Low Model NO. WRF28ZA HS Code 8415909000 Lifetime >20
1-4 Piece
$2,0005-9 Piece
$1,70010 Piece
$1,568Product information
High-quality Package Unit Air Conditioning System Condition New Noise Level Low Model NO. WRF28ZA HS Code 8415909000 Lifetime >20 supplied by Shanghai Shenglin M&E Technology Co., Ltd.. Bulk wholesale pricing ranges from $1,568 to $2,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Production Capacity:
10000 Unit/Units / Month
Operating Voltage:
380/400 VAC
HS Code:
8415909000
Lifetime:
>20 years
Keywords:
Air Conditioning System
Application Fields:
Air Conditioning System
Performance:
Cooling/Heating
Trade Term:
FOB, CFR, CIF, DDP, EXW
Specifications
Production Capacity:
10000 Unit/Units / Month
Operating Voltage:
380/400 VAC
HS Code:
8415909000
Lifetime:
>20 years
Keywords:
Air Conditioning System
Application Fields:
Air Conditioning System
Performance:
Cooling/Heating
Trade Term:
FOB, CFR, CIF, DDP, EXW
Mounting:
Floor Standing
Corrosion Durability:
Higher
Noise Level:
Low
Condition:
New
Refrigerant:
R22/R134A/R417A/R407c/R404A/R410A
Specification:
ROHS, BV, SGS, ISO
Certification:
RoHS, ISO, CE, ISO9001
Origin:
Shanghai, China
Port Of Loading:
Shanghai, Ningbo
Trademark:
Shenglin
Housing Material:
Stainless Steel, Coated Metal
Payment Term:
T/T, Western Union
Model NO.:
WRF28ZA
Transport Package:
Wooden Packing
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2009-12-29
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, Western Union
Preferred Trade Term:
FOB, CFR, CIF, DDP, EXW
Port Of Loading:
Shanghai, Ningbo
Certificates:
CE Heat Pump-EMC, CE Heat Pump-LVD, CE Rooftop AC-EMC, CE Rooftop AC-LVD, CE-Chiller, CE-Dry Cooler, ROHS, UL-Dry Cooler
Product descriptions from the supplier
air air conditioning system
| Model | WRF12ZA | WRF 15ZA | WRF18ZA | WRF24ZA | WRF30ZA | WRF 35ZA | ||||
| WF12ZA | WF 15ZA | WF18ZA | WF24ZA | WF30ZA | WF 35ZA | |||||
| Cooling capacity | kW | 12 | 15.2 | 17.5 | 24 | 30.3 | 35.6 | |||
| Heating capacity | kW | 13.2 | 16.6 | 18.4 | 26.5 | 33.3 | 37.7 | |||
| Energy regulation |
% | 0,100% | 0,50,100% | |||||||
| Power | 380V / 3Ph / 50HZA | |||||||||
| Cooling input capacity | kW | 4.1 | 5.3 | 5.5 | 8.8 | 11.3 | 12.3 | |||
| Heating input capacity | kW | 3.8 | 4.8 | 5.1 | 8.2 | 10.4 | 11.3 | |||
| Start current | A | 48 | 62 | 63 | 63 | 74 | 76 | |||
| Cooling running current | A | 7.4 | 9.7 | 10.2 | 16.1 | 21.2 | 23.3 | |||
| Heating running current | A | 6.9 | 9.2 | 9.7 | 15.1 | 20.1 | 22.2 | |||
| Throttling method |
Thermal expansion valve |
|||||||||
| Cooling system | 1 | 1 | 1 | 1 | 2 | 2 | ||||
| Refrigerant | R410A | |||||||||
| Compressor | Compressor type | Hermetic scroll compressor |
||||||||
| Qty | 1 | 1 | 1 | 1 | 2 | 2 | ||||
| Condensation side |
||||||||||
| Condenser | Type | Copper tube and aluminum fin | ||||||||
| Qty | 1 | 1 | 1 | 1 | 1 | 1 | ||||
| Drive type | Direct drive | |||||||||
| Motor power | kW | 0.25 | 0.37 | 0.37 | 0.55 | 0.75 | 0.75 | |||
| Air volume | m3 /h | 4600 | 7800 | 7800 | 9000 | 12600 | 12600 | |||
| Evaporation side |
||||||||||
| Evapotator | Type | Copper tube and aluminum fin | ||||||||
| Qty | 1 | 1 | 1 | 1 | 1 | 1 | ||||
| Motor power | kW | 0.32 | 0.37 | 0.45 | 1.1 | 1.5 | 2.2 | |||
| Air volume | m3 /h | 2100 | 2600 | 3400 | 4100 | 5200 | 6300 | |||
| Drive type | Direct drive | Pulley | ||||||||
| Static pressure(Pa) | 100 | 100 | 100 | 200 | 200 | 250 | ||||
| Filter | Aluminum filter G3 | |||||||||
| Noise dB(A) | 67 | 67 | 68 | 71 | 72 | 72 | ||||
| Refrigerant filling volume(kg) | 3.1 | 3.1 | 4.3 | 2x3.1 | 2x3.1 | 2x4.3 | ||||
| External dimension | L | mm | 1410 | 1410 | 1410 | 1978 | 1978 | 1978 | ||
| W | mm | 1100 | 1100 | 1100 | 1175 | 1175 | 1175 | |||
| H | mm | 1095 | 1095 | 1095 | 1095 | 1095 | 1095 | |||
| Weight | kg | 240 | 260 | 290 | 420 | 480 | 500 | |||
air conditioning system feature:
1, Complying with above China Standard, which is from ARI standard. ISO9001 and ISO14001 qualified.
2, Choose best materials, main components are from China top brand or imported.
3, The modular casing design, easy interchanging each other. easy install,easy transport,easy maintaince.
4, Unique no-cold-bridge design, improve the insulation and air tightness, total air leak rate ≤2.5%;
5, With dynamic balanced double inlet Centrifugal fan, with good air dynamic features, and accurate working, high efficiency, low vibration, low noise etc.
6, High efficient heat exchanger coil, ensure to provide the enough cooling capacity to the unit. And also high efficient breakwater panel is provided if required, water flow in coil ≤3×10-4kg/kg
7, Strong structure, good looking and permanent color.
8, Reasonable inside structure, with the suitable space for maintenance and cleaning.
9, Casing sheet: Provide double-skin construction constructing Sandwich type comprising 0.5mm thick galvanized internal and external skins and with 30mm thick polystyrene insulation of minimum 45kg/m3 density. Good airproof material is use between the casing and the frame to reduce the rate of the air leak.
The combined air handling untis are modular designed ,each modular can be used independently and can also work together and company with fan coil units to add refresh air. Not only reduce operation costs and energy saving, but also optimize air quality and create a congnitive indoor space to meet the human health requirements
air conditioning system Application:
The units are widely used in the air system of many inductries like mechanical ,electronic, textile,medical,chemical,energy and foo inductries ,etc. the units are also ideal solution for restaurants, office buildings,hospitals,theaters,supermarkets and palaestra.
air conditioning system structure diagram
1. Conventional
2. Technical purification
3. Heat recovery type
