Paper Pulping Wedge Wire Screen Baskets Pressure Screen
Piece
Negotiable
Product information
High-quality Paper Pulping Wedge Wire Screen Baskets Pressure Screen supplied by SUN HONG PAPER TECH XUZHOU CO., LTD.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Inlet Pressure:
0.15-0.3MPa
Inlet Consistency:
2-5%
HS Code:
8439990000
Manufacturing Process:
Casting
Origin:
China
Trade Term:
FOB, CFR, CIF, DAP, EXW
Certification:
ISO 9001:2000, ISO 9001:2008
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Specifications
Inlet Pressure:
0.15-0.3MPa
Inlet Consistency:
2-5%
HS Code:
8439990000
Manufacturing Process:
Casting
Origin:
China
Trade Term:
FOB, CFR, CIF, DAP, EXW
Certification:
ISO 9001:2000, ISO 9001:2008
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Condition:
New
Surface Treatment:
Polishing
Application:
Pulp Line
Specification:
SH-FF109
Model NO.:
SUNHONG
Port Of Loading:
Shanghai Seaport
Material:
Stainless Steel
Trademark:
SunHong
Transport Package:
Wooden Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2010-08-10
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
FOB, CFR, CIF, DAP, EXW
Port Of Loading:
Shanghai Seaport
Product descriptions from the supplier
Paper Pulp Making Process -- Pressure Screen
Pressure screen is mainly used for making the screen before the paper machine of paper making industry of pulp equipment.It can also be regard as the precise sieve of pulp making system,It has the advantage of great quantity,low pulse,not easy to stop,low energy consumption and having long performance life.
Main Technical Data
Remark:The yield will change with the size variety and concentration. Therefore, the output in the table is only for selection.
Screen Basket for Pressure Screen
The screen basket is used in pressure screen, but it is a wear parts need to be replaced regularly, so that the pressure screen can operate better. Mainly have two type of screen basket one is wedge wire type, the other one is drilled hole type. In the screen basket it will have rotor inside it. We can customize the screen basket and rotor for customers.
Wedge Wire Screen Basket Drilled Hole Screen Basket Screen Rotor
Pressure screen is mainly used for making the screen before the paper machine of paper making industry of pulp equipment.It can also be regard as the precise sieve of pulp making system,It has the advantage of great quantity,low pulse,not easy to stop,low energy consumption and having long performance life.
Inflow Pressure Screen
Inflow pressure screen is mainly used for previous screen and fine screen process.
1.Small motor power,energy saving,but big capacity.
2.Inflow structure,low pulsation,good formation on wire.
3.Diffuse outlet design,smooth accept flow,no spacer flange,inner surface polishing treatment,seamless connection of pipe line,no fiber hanging.
4.Modular desian of main machine and drive,stable and reliable structure,easy and fast installationand maintenance.
Inflow pressure screen is mainly used for previous screen and fine screen process.
1.Small motor power,energy saving,but big capacity.
2.Inflow structure,low pulsation,good formation on wire.
3.Diffuse outlet design,smooth accept flow,no spacer flange,inner surface polishing treatment,seamless connection of pipe line,no fiber hanging.
4.Modular desian of main machine and drive,stable and reliable structure,easy and fast installationand maintenance.
Upflow Pressure Screen
It is especially designed for recycle waste paper pulp and fiber grading and screening. It has functions of both grading the fiber,according to their length, and pulp screening. It has advantage of low energy consumption, high efficiency of removal of impurities.
It is especially designed for recycle waste paper pulp and fiber grading and screening. It has functions of both grading the fiber,according to their length, and pulp screening. It has advantage of low energy consumption, high efficiency of removal of impurities.
Middle Consistency Pressure Screen
1.Multi foil design,untwisting,gentle pulsation and screening for better cleanness,high pulsation frequency and big capacity.
2.Mid consistency screening(Max.4%, less water consumption,and energy saving,smaller screening area if for same capacitthan low consistency screening,less investment,low maintenance cost.
3.Less consistency increasing in screening area,high screening efficiency,longer life time of the basket.
1.Multi foil design,untwisting,gentle pulsation and screening for better cleanness,high pulsation frequency and big capacity.
2.Mid consistency screening(Max.4%, less water consumption,and energy saving,smaller screening area if for same capacitthan low consistency screening,less investment,low maintenance cost.
3.Less consistency increasing in screening area,high screening efficiency,longer life time of the basket.
Main Technical Data
| Model | Inlet consistency (%) |
Inlet pressure (MPa) |
Motor power (KW) |
Capacity (t/24h) |
| SHN0.6 | 0.5-1.2 | 0.1-0.3 | 15-22 | 20-30 |
| SHN0.9 | 18.5-30 | 25-60 | ||
| SHN1.2 | 22-37 | 30-80 | ||
| SHN1.5 | 30-45 | 40-120 | ||
| SHN2.0 | 37-55 | 80-210 | ||
| SHN2.5 | 37-75 | 100-230 | ||
| SHN3.5 | 45-110 | 140-280 | ||
| SHN4.5 | 55-132 | 180-350 | ||
| SHN6.0 | 75-160 | 230-500 |
Screen Basket for Pressure Screen
The screen basket is used in pressure screen, but it is a wear parts need to be replaced regularly, so that the pressure screen can operate better. Mainly have two type of screen basket one is wedge wire type, the other one is drilled hole type. In the screen basket it will have rotor inside it. We can customize the screen basket and rotor for customers.
