Pet Food Sterilization Retort Machine Continuous Retort Kiln Autoclave Industrial Herb Sterilization Machine Pet Jar Sterilizers
1 Set
$23,0001 Set
$6,800Product information
High-quality Pet Food Sterilization Retort Machine Continuous Retort Kiln Autoclave Industrial Herb Sterilization Machine Pet Jar Sterilizers supplied by Zhucheng Lonkia Co., Ltd. Bulk wholesale pricing ranges from $6,800 to $23,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Package Gross Weight:
2200.000kg
Package Size:
300.00cm * 100.00cm * 100.00cm
Delivery Period:
7-45 Days
Specification:
700mm-4200mm
Production Capacity:
800-1000kg Per Batch
Automation:
Automatic
Certification:
CE
Certificate:
CE/ISO
Specifications
Package Gross Weight:
2200.000kg
Package Size:
300.00cm * 100.00cm * 100.00cm
Delivery Period:
7-45 Days
Specification:
700mm-4200mm
Production Capacity:
800-1000kg Per Batch
Automation:
Automatic
Certification:
CE
Certificate:
CE/ISO
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Operation:
Continuous
Customized:
Customized
Structure:
Double Layers
Energy:
Electriic
Trade Term:
FOB, CIF, CFR, EXW
Type:
High Voltage Electric Field Sterilization Equipment
Trademark:
LONKIA
Model NO.:
LY-SJG
Scale:
Large
Property:
Physical Sterilization
Port Of Loading:
Qingdao Port
Principle:
Rotary
Raw Materials:
SUS304
Origin:
Shandong, China
Service:
Support Inspection and Testing
Payment Methods:
Support payments in USD
Payment Term:
T/T, LC, D/P, PayPal, Western Union, Small-amount payment
Transport Package:
Wooden Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2018-08-29
Annual Revenue Amount:
Not specified
Numbers Of Employees:
54
Preferred Payment Term:
T/T, LC, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Qingdao Port
Certificates:
CE01, CE02, CE03, CE04, CE05, ISO9001
Product descriptions from the supplier
New Autoclave Horizontal Rotary Retort Hot Water Heating Sterilizer Soft Packaging Sterilization Pot
The horizontal high-temperature and high-pressure sterilization pot uses the technology of "saturated steam/hot water circulation+back pressure control" to create a sterilization environment of 121-135 ℃ and 0.15-0.3MPa in a closed container. It uses heat to destroy microbial cell membranes and enzyme activity, achieving commercial aseptic standards (killing 99.999% of microorganisms including spores).
1. Suitable for canned soup with high viscosity, During sterilization, the can rotates continuously 360 ° underthe drive of the rotating body inside the retort tank, causing the contents to move slowly and increasingthe speed of heat penetration. At the same time, it achieves uniform heating and cooling, without layeringor sedimentation. The use of variable frequency speed regulation enables the equipment to be used forproducts with different viscosities.
2. Heating methods: steam heating, electric heating, electric steam heating, etc.
3. Sterilization methods: water bath, steam, spray (side spray, top spray)
4. Uniform water exchange mode realizes uniform temperature without dead angle.
5. High temperature instant sterilization.
6. High sterilizing precision,Energy saving.
7. All of the sterilizing courses can be controlled by computer PLC.
3. Sterilization methods: water bath, steam, spray (side spray, top spray)
4. Uniform water exchange mode realizes uniform temperature without dead angle.
5. High temperature instant sterilization.
6. High sterilizing precision,Energy saving.
7. All of the sterilizing courses can be controlled by computer PLC.
Multiple Sterilization Methods
Multi-faceted Display
01. Various sterilization methods
Water spray sterilizer
Rotary high temperature and high pressure sterilizer
Water bath sterilizer
02. Various tank structures
Single-layer sterilizer Double layer sterilizer Three pots sterilizer
03. Various heating methods
Steam Heating
Electrical heating
Two heating methods:
electric and steam
Product Parameters
Model | 1000# | 1200# | |||
Cylinder length(mm) | 2400 | 2700 | 3600 | 4000 | 4500 |
Total length(mm) | 4200 | 4600 | 5600 | 6000 | 6600 |
Total width(mm) | 1600 | 1900 | 1900 | 1900 | 1900 |
Total height(mm) | 2800 | 3100 | 3100 | 3100 | 3100 |
Volume(m2) | 2.2 | 4.6 | 4.6 | 5.0 | 5.5 |
Pot body thickness(mm) | 4 | 5 | 5 | 5 | 5 |
Installed power(kw) | 7 | 13 | 13 | 13 | 13 |
Gas consumption(kg/Pot number) | 115 | 200 | 255 | 280 | 300 |
power consumption(kw/h) | 5 | 9 | 9 | 9.5 | 10 |
Design Press(Mpa) | 0.35 | 0.35 | 0.35 | 0.35 | 0.35 |
Design Temperature(℃) | 147 | 147 | 147 | 147 | 147 |
Product Details
PLC intelligent control system
Thickened SUS304 material
Strong sealing
The equipment adopts microcomputer control.intelligent control module, fully automated design, and precise temperature
and pressure.
The whole machine is made of pure thickened 304 stainless steel raw material pressure-proof,anti-corrosion, heavy duty,easy to clean.
The pot cover is sealed with inflatable silicone rubble ring,reliable sealing and long service life.
Large heating area
Level gauge
Boiler door cylinder
It has the advantages of high thermal efficiency, even heating, short boiling time, and easy control of heating temperature.
Instantly see the height of the liquid level in the pan.
Seal the boiler door to ensure stable internal pressure.
Support Customization
Support customizing different types of baskets
Support the customization of the entire sterilization loading and unloading line, support the whole factory planning, and provide you with the most reasonable and efficient sterilization production line.
Product Photography
Successful Cases
Laboratory High-pressure Sterilization Kettle
Vertical Flexible Packaging Continuous Sterilization Kettle
Fully Automatic Pasteurization Line with Lifting System
