Plastic Waste Bottle Washing Line Crushing Drying Recyclable Recycle Plastic Machine
Piece
Negotiable
Product information
High-quality Plastic Waste Bottle Washing Line Crushing Drying Recyclable Recycle Plastic Machine supplied by Suzhou Deedo Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Model NO.:
1000
Weight:
15200kg
Package Gross Weight:
2600.000kg
Package Size:
2600.00cm * 1300.00cm * 1700.00cm
Model:
300-6000kg/H
Machine Material:
304 Stainless Steel
Production Capacity:
5 Lines Per Month
Recycling Machine Output:
500-6000kg
Specifications
Model NO.:
1000
Weight:
15200kg
Package Gross Weight:
2600.000kg
Package Size:
2600.00cm * 1300.00cm * 1700.00cm
Model:
300-6000kg/H
Machine Material:
304 Stainless Steel
Production Capacity:
5 Lines Per Month
Recycling Machine Output:
500-6000kg
Specification:
500-6000kg/h
HS Code:
84778000
Automation:
Automation
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Product:
Clean Flakes
Computerized:
Computerized
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Color:
Customized
Trademark:
DEEDO
Trade Term:
FOB, CIF, CFR
Raw Material:
Film/ Bottle/ Pipe /Bag
Certification:
ISO9001:2008, CE
Origin:
Jiangsu, Chian
Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Screw:
None
Plastic Type:
PET
Control Cabniet:
PLC
Name:
Pet Bottle Recycling Washing Machine
Material:
Pet Bottles
Machine:
Pet Recycling Washing Machine
Material Processed:
Plastic Bottle
Bearing Brand:
SKF and NSK
Port Of Loading:
Shanghai Port
Motor Brand:
Siemens, ABB or Chinese Best Brand
Payment Methods:
Support payments in USD
Inverter:
Teco ABB
Quality Control:
Test Before Delivery
Transport Package:
Wood Base and Wood Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2014-08-13
Annual Revenue Amount:
Not specified
Numbers Of Employees:
24
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Shanghai Port
Certificates:
CE
Product descriptions from the supplier
PET waste bottles flakes recycling washing machine line
1.Application for PET bottle recycling washing line:
This Plastic Waste Bottle Washing Line Crushing Drying Recyclable Recycle Plastic Machine line is composed of garbage separation (automatic & manual), bottle & flake crushing, cold & hot washing & cleaning, flake dewatering & drying, dust & label removal, packing, etc.
2.Introduction
Material: carbonated beverage bottles, drinking water bottles, fruit juice bottles, oiler, tea drink bottles, etc
Finished product size: Less than 14mm or customized
Purpose of use: Be used for short fibre, long fibre or sheet, filament yarn, PET strap, PET sheet or PET film or bottle to bottle.
Remark: We can customize the recycling line according to client's requirement.
De-baling(bale opener)------Trommel----- Label Scrapping(lable remover) ------ Manual Sorting and Metal Detecting-----Wet Grinding(crusher)-------Screw conveyor------Gravity Separation(floating washer)-------Screw conveyor------Chemical Washing for PET Flakes(Hot washer)-------Screw conveyor------High speed friction washer ------- Screw conveyor------Floating washing tank ------- Dewatering machine--------Drying pipe system--------Label separator(Zigzag air label separator type)------Packing/storage hopper
4.Feature for PET washing line:
1. PET bottle flakes produced by PET bottle recycling and cleaning production line are mainly used to produce polyester filament, packing tape, sheet, film and other products.
2.Efficient trommel ensures separation of materials from other debris: removal of stones, wood chips, small metals.
Material: carbonated beverage bottles, drinking water bottles, fruit juice bottles, oiler, tea drink bottles, etc
Finished product size: Less than 14mm or customized
Purpose of use: Be used for short fibre, long fibre or sheet, filament yarn, PET strap, PET sheet or PET film or bottle to bottle.
Remark: We can customize the recycling line according to client's requirement.
3.Basic Production Process
De-baling(bale opener)------Trommel----- Label Scrapping(lable remover) ------ Manual Sorting and Metal Detecting-----Wet Grinding(crusher)-------Screw conveyor------Gravity Separation(floating washer)-------Screw conveyor------Chemical Washing for PET Flakes(Hot washer)-------Screw conveyor------High speed friction washer ------- Screw conveyor------Floating washing tank ------- Dewatering machine--------Drying pipe system--------Label separator(Zigzag air label separator type)------Packing/storage hopper
4.Feature for PET washing line:
1. PET bottle flakes produced by PET bottle recycling and cleaning production line are mainly used to produce polyester filament, packing tape, sheet, film and other products.
2.Efficient trommel ensures separation of materials from other debris: removal of stones, wood chips, small metals.
3.The label removing machine is mainly used to peel the label paper on the PET bottle surface, especially the PVC or PS label applied on the PET bottle.Through the cooperation of the rotary and the fixed knives, the labels on the bottle body are peeled together, and the difference between wind force and gravity is used to completely separate the bottle body and the label, to preserve the integrity of the bottle and the bottleneck, and reduce the loss of high-quality bottle material.
4.The sorting system is the final classification and screening of the bottle body before crushing. It screens out a small amount of foreign matter (including heterogeneous bottles, heterochromatic bottles, a small amount of label scraps, metal reactants, garbage, etc.) remaining in the front-end units, and a buffer system. It is one of the necessary means for large-capacity production regulation, which is crucial to the stability of process control. Manual sorting is a re-inspection and a necessary way to ensure quality.
5.The crushing system adopts wear-resistant design to ensure that the system runs continuously for a long time.
6.Hot washing machine effectively removes sticky glue, oil stains and some small impurities on the surface of bottle flakes, which is critical to the life of downstream product filter components and product quality.
7.The high-speed firction washer applies the corresponding blade striking force to different materials at a suitable rotation speed to achieve the desired cleaning effect.
8.The floating washing tank is designed for strong pressure underwater cleaning to remove residual impurities
9.Can be equipped with the corresponding centrifugal dewatering machine and hot air drying system according to the water content set by the production requirements.
10.The entire line is automatically controlled, and the units of the system operate in association with each other. It has a pre-judgment function for possible abnormal situations to ensure system safety.
5.Technical Parameters:
| Model | BXA-300 | BXA-500 | BXA-1000 | BXA-2000 | BXA-3000 | BXA-5000 |
| Product capacity | 300kg /h | 500kg /h | 1000kg /h | 2000kg /h | 3000kg/h | 5000kg/h |
| Workshop(L*W*H) | 40m *4m*5m | 42m *5m*5m | 85m *5m*5m | 110m *6m*6m | 125m*6m*6.5m | 130*8m*7m |
| Needed worker | 2-3 persons | 3-4persons | 4-5persons | 5-6persons | 6-8persons | 8-10persons |
| Water supply (recycle use) |
2-3ton/h | 3-4ton/h | 4-5ton/h | 6-8ton/h | 10-12ton/h | 12-15ton/h |
| Installed power(KW) | 150-180 | 180-210 | 210-260 | 400-460 | 600-670 | 920-1200 |
| Final product quality | Moisture: max 1% Particle size: 3-12mm or customized Total impurity content:≤150PPM PH:7.5±0.5 |
|||||
6.Spec of end products---PET Flakes(Filament grade)
|
Intrinsic Viscosity (IV) (dl/g) |
0.65-0.86 (depends on raw materials) |
|
|
Melt point (ºC) |
252-260 |
|
|
Moisture |
0.5-1% |
|
|
Bulk density (kg/m3) |
280-450 |
|
|
Particle size (mm) |
3-12 |
|
|
Fraction |
1-3mm |
8-15% |
|
≤1mm |
Max. 2% |
|
|
PH Value |
7.5±0.5 |
|
|
PVC (ppm) |
Max. 30 (based on raw material & design) |
|
|
PE/PP (ppm) |
Max. 20 |
|
|
Label(ppm) |
Max. 20 |
|
|
Glue (ppm) |
Max. 20 |
|
|
Metal (ppm) |
Max. 10 |
|
|
Total impurity (ppm) |
Max. 150 |
|
7. Auxiliary equipments
8.Package and Loading
9.Why choose us
9.1.Quality Control(plastic machine):
· We have technical, engineer team design the sample machinery before enter into market
· Production QC team ensure the machine manufacturing quality
· We will running every machine after finished before shipment
· Optional choose by client running the machinery by material
9.2.Service System(plastic machine):
· Pre-sale: We given client the details technician offer, sign the sales contract etc.
· In-sales: We supply the details layout, installation instruction, technician support for the clients;
· After sales: We arrange engineer to install the machinery and training the workers for client;
· We have 24hours team to solve the after sales problem;
· We have free spare parts with the machine;
· We supply long term spare parts for every customer
· We always up date the new technology to every customer
10.Certificate
11.FAQ
YOU MIGHT INSTERESTED IN FOLLOWING QUESTIONS
1. Are you manufacturer or trading company?
We are a professional recycling machines manufacturer for more than 15years we supplying full technical support and solutions, timely and professional service, always effort on quality, honest, win-win business for every client.
2. How do you assistant to install the machine on worksite?
We are experienced on turn-key project, engineer and technicians will assistant client on construction, installation, commissioning.
3. How can I get spare parts for replacement in other countries?
Wearing parts like blades, it is necessary to buy with machine, other parts in stock could be delivery out by express if urgent or by sea within 5days.
4. Can I use mark machine with different LOGO and color?
Yes, please confirm details with sales.
5. Can your customers test the machines?
Before buying and after production before leaving factory, we test machine you interested or paid with specified materials, free of charge.
If you have any need ,pls feel free to contact with us.
