Plate Forging Cold Forging Induction Forging Multidirectional Forging
1 Piece
$101 Piece
$20Product information
High-quality Plate Forging Cold Forging Induction Forging Multidirectional Forging supplied by Shanghai Bosheng Industries Co., Ltd.. Bulk wholesale pricing ranges from $10 to $20 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Forging Tolerance:
+/-0.2mm
Production Capacity:
5000000pieces/Year
HS Code:
7307990000
Standard:
BS
Trademark:
BS
Certification:
CE, RoHS, ISO 9001:2000, ISO 9001:2008
Origin:
China
Trade Term:
FOB, EXW, CFR, CIF, DDP
Specifications
Forging Tolerance:
+/-0.2mm
Production Capacity:
5000000pieces/Year
HS Code:
7307990000
Standard:
BS
Trademark:
BS
Certification:
CE, RoHS, ISO 9001:2000, ISO 9001:2008
Origin:
China
Trade Term:
FOB, EXW, CFR, CIF, DDP
Application:
Hardware
Quality:
High Quality
Payment Term:
LC, T/T
Surface Treatment:
Passivation
Molding Technics:
Pressure Casting
Port Of Loading:
Shanghai, Tianjin, Qingdao
Material:
Steel
Heat Treatment:
Tempering
Transport Package:
Wooden Package
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2014-12-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, EXW, CFR, CIF, DDP
Port Of Loading:
Shanghai, Tianjin, Qingdao
Certificates:
AAA Rated Credit Enterprise, China's Honest Enterpreneurs, China's Honet Manager, Credit Management Demonstration Unit, Enterprise Abiding By Contracts And Keeping Promises, Enterprise Credit Rating Certificate, Honest Supplier Enterprise, ISO 14001, ISO 45001, ISO 9001, Quality Oriented And Trustworthy Enterprise, Quality Service Integrity Unit, Service Oriented And Trustworthy Enterprises, The business license
Product descriptions from the supplier
Forging is a processing method which uses forging machinery to exert pressure on metal billet to produce plastic deformation so as to obtain forging parts with certain mechanical properties, certain shape and size.Forging is a manufacturing process involving the shaping of metal using localized compressive forces.Through forging can eliminate the defects such as loose cast state produced in the smelting process of metal, optimize the microstructure structure, at the same time because of the preservation of a complete metal streamline, the mechanical properties of the forging is generally better than the same material castings. Forgings are mostly used for the important parts with high load and severe working conditions in the relevant machinery, except for the simple plate, profile or welding parts that can be rolled.
The blows are delivered with a hammer (often a power hammer) or a die. Forging is often classified according to the temperature at which it is performed: cold forging (a type of cold working), warm forging, or hot forging (a type of hot working). For the latter two, the metal is heated, usually in a forge. Forged parts can range in weight from less than a kilogram to hundreds of metric tons.Forging has been done by smiths for millennia; the traditional products were kitchenware, hardware, hand tools, edged weapons, cymbals, and jewellery. Since the Industrial Revolution, forged parts are widely used in mechanisms and machines wherever a component requires high strength; such forgings usually require further processing (such as machining) to achieve a finished part. Today, forging is a major worldwide industry.
Forging can produce a piece that is stronger than an equivalent castormachinedpart. As the metal is shaped during the forging process, its internalgrain texturedeforms to follow the general shape of the part. As a result, the texture variation is continuous throughout the part, giving rise to a piece with improved strength characteristics. Additionally, forgings can achieve a lower total cost than casting or fabrication. Considering all the costs that are incurred in a product's life cycle from procurement to lead time to rework, and factoring in the costs of scrap, and downtime and other quality considerations, the long-term benefits of forgings can outweigh the short-term cost savings that castings or fabrications might offer.
Different forging methods have different processes, among which the hot die forging process is the longest, the general order is: forging blank blanking; Forging billet heating; Roll forging billet preparation; Die forging; Trimming; Punching; Correction; Intermediate inspection, inspection forgings size and surface defects; Heat treatment of forgings to eliminate forging stress and improve metal cutting performance; Cleaning, mainly to remove the surface oxide skin; Correction; Inspection, general forgings to go through the appearance and hardness inspection, important forgings also through chemical composition analysis, mechanical properties, residual stress and other tests and non-destructive testing.
We have equipped with the latest testing instruments and testing technology, the use of computer control data processing of modern automatic ultrasonic testing system, the use of a variety of special automatic ultrasonic testing system, to complete the certification of various quality systems.We use computer simulation technology, computer aided process design and virtual technology to improve the process design level and product manufacturing capacity. DATAFOR, GEMARC/AUTOFORGE, DEFORM, LARSTRAN/SHAPE and THERMOCAL were introduced and applied to realize the process control of computer design and hot working.Most of the hydraulic presses of 40MN and above are equipped with 100-400t. M main forging manipulator and 20-40t. M auxiliary manipulator. A considerable number of manipulators are controlled by computer to realize the comprehensive control of forging process, so that the forging accuracy can be controlled within ±3mm.
