Pole Mounted Fan Ventilation Big Pole Standing Column Fan
1-9 Piece
$2,45910 Piece
$539Product information
High-quality Pole Mounted Fan Ventilation Big Pole Standing Column Fan supplied by Fujian Mindong IMP. & EXP. Co., Ltd.. Bulk wholesale pricing ranges from $539 to $2,459 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Power:
0.37kw 0.55kw 0.75kw 1.1kw
Specification:
2--7.3M
Voltage:
220/380V
Production Capacity:
3000PCS/Month
HS Code:
8414591000
Electric Current Type:
AC
Blades:
Aluminum 5/6PCS
Mounting:
Ceiling Fan
Specifications
Power:
0.37kw 0.55kw 0.75kw 1.1kw
Specification:
2--7.3M
Voltage:
220/380V
Production Capacity:
3000PCS/Month
HS Code:
8414591000
Electric Current Type:
AC
Blades:
Aluminum 5/6PCS
Mounting:
Ceiling Fan
Type:
Exhaust Fan
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Fuan Fujian China
Port Of Loading:
Fuzhou Port
Model NO.:
HDS-3, HDS-3.7, HDS-4.3, HDS-5, HDS-6.1, HDS-7.3
Trademark:
HUADA
Certification:
ISO, CE, CCC
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Motor:
Permanent Magnet
Transport Package:
Wooden Case
Coverage Area:
up to 1500 Square Meters
Effective Area:
up to 850 Square Meters
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2007
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Fuzhou Port
Certificates:
Ceiling fan blade structure, certificate, CSA, for ceiling fan, ISO 14001 certificate, ISO9001 certificate of fan, LOGO, Outdoor large vertical fan, Refrigeration equipment production license, The utility model relates to a dc outer rotor motor with adjustable speed
Product descriptions from the supplier
-----TECHNICAL DATA-----
| Model | HDS-3 | HDS-3.7 | HDS-4.3 | HDS-5 | HDS-5.5 | HDS-6.1 | HDS-6.7 | HDS-7.3 | HDS-6.7 | HDS-7.3 |
| diameter(m) | 3 | 3.7 | 4.3 | 5 | 5.5 | 6.1 | 6.7 | 7.3 | 6.7 | 7.3 |
| diameter(ft) | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | 22 | 24 |
| Power(KW) | 0.37 | 0.75 | 1.1 | 1.5 | ||||||
| Horsepower(HP) | 0.5 | 1 | 1.5 | 2 | ||||||
| voltage(V) | 220-240/380-460 | |||||||||
| Frequency(HZ) | 50/60 | |||||||||
| Air volume(m³/min) | 4000 | 5000 | 7000 | 10000 | 11000 | 11500 | 12000 | 13000 | 14000 | 15000 |
| Rotating speed(rpm) | 120 | 100 | 90 | 80 | 70 | 60 | 55 | 50 | 55 | 50 |
| Number of leaves(Pcs) | 5/6 | |||||||||
| Noise(dB) | 38 | |||||||||
| Motor weight(kg) | 18 | 18 | 25 | 25 | 48 | 48 | 48 | 48 | 58 | 58 |
| Ceiling fan weight(kg) | 35 | 38 | 46 | 49 | 99 | 103 | 107 | 111 | 118 | 122 |
| Effective area(m2) |
150 | 230 | 256 | 300 | 500 | 600 | 650 | 700 | 750 | 800 |
| Coverage area(m2) |
250 | 380 | 450 | 500 | 900 | 1000 | 1300 | 1500 | 1600 | 1700 |
-----PRODUCT DISPLAY-----
Product Description
HDS series intelligent ceiling fansare a series of products specially developed forenergy savingandconsumption reduction andimprovement of working environment comfort. The intelligent ceiling fan is driven by self-designed permanent magnet motor, featuring small volume, light weight,high efficiency,stepless speed regulation, compact structure and beautiful appearance. It is widely used in industrial workshop, logistics warehouse, waiting room, exhibition hall, gymnasium, commercial super and other tall space, as a common and intelligent machinefor space ventilation and personnel cooling. It can push a large amount of airflow to the ground, forming a certain height of airflow layer horizontal movement on the ground, thus contributing to the overall air circulation, which is both environmentally friendly and energy-saving, similar to the natural breeze system, enjoy the intimate experience of natural wind.
Functional configuration
Operation of ceiling fan:
adopt self-developed permanent magnet external motor
Fan blade safety ring:
the latest technology to connect the fan blade into a whole, to avoid fan blade accidental fall
Fan blade:
it is extruded by aluminum and magnesium alloy and has the advantages of high strength, good toughness, light weight, long life and safety
Anti-stripping device:
top safety, the fan blade, chassis and motor are connected as a whole, and anti-stripping plate plays a protective role to prevent any parts from falling off.
Tail fin:
high temperature resistant material is adopted to shape the product structure to be more beautiful. When the fan blade is running, air will generate vortex at the end of the airfoil fan blade.
Steel wire pulling and locking device -- high-altitude protection, the stress strength of each steel wire cable can reach 1000kg, and the fan can operate stably and reliably under the huge inertia generated by rotation.
adopt self-developed permanent magnet external motor
Fan blade safety ring:
the latest technology to connect the fan blade into a whole, to avoid fan blade accidental fall
Fan blade:
it is extruded by aluminum and magnesium alloy and has the advantages of high strength, good toughness, light weight, long life and safety
Anti-stripping device:
top safety, the fan blade, chassis and motor are connected as a whole, and anti-stripping plate plays a protective role to prevent any parts from falling off.
Tail fin:
high temperature resistant material is adopted to shape the product structure to be more beautiful. When the fan blade is running, air will generate vortex at the end of the airfoil fan blade.
Steel wire pulling and locking device -- high-altitude protection, the stress strength of each steel wire cable can reach 1000kg, and the fan can operate stably and reliably under the huge inertia generated by rotation.
Application field
Large logistics warehouse and distribution center:
improve air quality, dehumidify and cool down, prevent storage from rust and rot, and improve working environment.
Super large plant:
such as machinery processing, car repair, aircraft assembly, shipbuilding and other workshop, can improve ventilation efficiency..
Public buildings:
such as shopping malls, gymnasiums, railway stations, airports and other places with large human flow, can promote air circulation, dispel peculiar smell, and create a comfortable public place environment.
Large farms:
including milk farms, breeding farms, hatchery, etc. Good ventilation can improve air quality, remove moisture, remove odors, and reduce livestock morbidity. The suitable temperature can make the livestock feel comfortable and stimulate the rapid growth of the livestock, so as to improve the production rate of the stockholder livestock and increase the production of poultry eggs and milk meat.
Outdoor personnel density:
such as urban construction sites, outdoor workers can provide a cooler operating environment; For example, outdoor dining places can bring more comfortable dining experience to consumers.
improve air quality, dehumidify and cool down, prevent storage from rust and rot, and improve working environment.
Super large plant:
such as machinery processing, car repair, aircraft assembly, shipbuilding and other workshop, can improve ventilation efficiency..
Public buildings:
such as shopping malls, gymnasiums, railway stations, airports and other places with large human flow, can promote air circulation, dispel peculiar smell, and create a comfortable public place environment.
Large farms:
including milk farms, breeding farms, hatchery, etc. Good ventilation can improve air quality, remove moisture, remove odors, and reduce livestock morbidity. The suitable temperature can make the livestock feel comfortable and stimulate the rapid growth of the livestock, so as to improve the production rate of the stockholder livestock and increase the production of poultry eggs and milk meat.
Outdoor personnel density:
such as urban construction sites, outdoor workers can provide a cooler operating environment; For example, outdoor dining places can bring more comfortable dining experience to consumers.
-----WORKING PRINCIPLE -----
-----ENTERPRISE FEATURES -----
-----GLORY QUALIFICATIONS-----
-----PRODUCT PACKAGING-----
-----INSTALLATION PROCEDURE-----
-------FAQ-------
Q:Are you a foreign trade company or a manufacturer ?
A: Yes , we are a professional manufacturer, Our factory is specialized in Industrial Ceiling Fans, cooling fan, Exhaust Industrial Fan and so on.
Q:Do you have quality certification for your products?
A: Our ceiling fans have been certificated to CE, KC, CCC and so on , the fans quality can be guaranteed.
Q: Can you make my brand on products or provide OEM service?
A: Yes.We can provide OEM service.We are the OEM supplier for some famous companies.
Q: What's your minimum quantity for order (MOQ)?
A: 10PCS.
Q: what's the delivery time?
A: Delivery time will be within 20 days after receipt payment by 100%TT.
Q: How long is the warranty?
A: Our motor warranty is 3 years and the controller warranty is 18 months.
Fujian Mindong IMP.and EXP. Co. Ltd. is a professional manufacturer of industrial ceiling fan. We are participates in various exhibitions at home and abroad, because of its high quality and good after-sales service.
A: Yes , we are a professional manufacturer, Our factory is specialized in Industrial Ceiling Fans, cooling fan, Exhaust Industrial Fan and so on.
Q:Do you have quality certification for your products?
A: Our ceiling fans have been certificated to CE, KC, CCC and so on , the fans quality can be guaranteed.
Q: Can you make my brand on products or provide OEM service?
A: Yes.We can provide OEM service.We are the OEM supplier for some famous companies.
Q: What's your minimum quantity for order (MOQ)?
A: 10PCS.
Q: what's the delivery time?
A: Delivery time will be within 20 days after receipt payment by 100%TT.
Q: How long is the warranty?
A: Our motor warranty is 3 years and the controller warranty is 18 months.
Fujian Mindong IMP.and EXP. Co. Ltd. is a professional manufacturer of industrial ceiling fan. We are participates in various exhibitions at home and abroad, because of its high quality and good after-sales service.
Welcome to consultation!
