Power Monitoring Module Energy Metering Module
1 Piece
$2051 Piece
$247Product information
High-quality Power Monitoring Module Energy Metering Module supplied by Jiangsu Sfere Electric Co., Ltd.. Bulk wholesale pricing ranges from $205 to $247 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Accuracy Class:
0.5s
Voltage Range:
0.8un~1.2un
Energy Pulse:
1 Output, Pulse Width(80±20%) Ms
Production Capacity:
20000PCS/Per Month
Output Voltage:
230V
Frequency:
45-65Hz
Specification:
90*36mm
HS Code:
9030899090
Specifications
Accuracy Class:
0.5s
Voltage Range:
0.8un~1.2un
Energy Pulse:
1 Output, Pulse Width(80±20%) Ms
Production Capacity:
20000PCS/Per Month
Output Voltage:
230V
Frequency:
45-65Hz
Specification:
90*36mm
HS Code:
9030899090
Consumption:
<2va
Rated Current:
AC 5(100)a
Origin:
China
Customized:
Customized
Installation:
Direct Connected
Trademark:
ELECNOVA
Theory:
Electronic Meter
Type:
Energy Meter
Trade Term:
FOB, CIF, CFR, EXW
IP Degree:
Front IP51
Certification:
ISO, CE
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Usage:
Multi-Functional Energy Meter
Measured Signal:
Pulse Peak
Communication:
RS-485
Model NO.:
Sfere700-D1
Port Of Loading:
Shanghai Port
Electric Equipment:
Single-phase
Power Meter Connection:
Terminal
Rtc Error:
≤0.5s/Day
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
1998-01-15
Annual Revenue Amount:
Not specified
Numbers Of Employees:
598
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE
Product descriptions from the supplier
Product Name: Power monitoring module energy metering module
DDS1946-2P din rail mounted AC Digital single phase smart electricity meterare designed and produced according to user's real electricity consumption situation by adopting advanced energy measurement IC and using digital sampling processing and SMT technologies. They adopt modularity structure with the features such as small volume, convenient installation and reliable working.
|
|
DDS1946-1P
DDSF1946-1P
|
DDS1946-2P
DDSF1946-2P
|
DDS1946
DDSF1946
|
DSS1946
DSSF1946
|
DTS1946
DTSF1946
|
|
|
Normal Voltage
|
230V
|
230V
|
230V
|
3*400V
|
3*230/400V
|
|
|
Current |
Direct input
|
5(40)A
|
5(100)A
|
5(100)A
|
5(100)A
|
5(100)A
|
|
Via CT input
|
-
|
-
|
1.5(6)A
|
1.5(6)A
|
1.5(6)A
|
|
|
Accuracy
|
|
Class 1(Optional:Class 0.5S)
|
||||
|
Frequency
|
|
45Hz~65Hz
|
||||
|
Voltage Range
|
|
0.8Un~1.2Un
|
||||
|
Start Current |
Direct input
|
0.004Ib
|
||||
|
Via CT input
|
0.002In
|
|||||
|
Consumption
|
<2VA
|
|||||
|
Energy Pulse
|
1 output, pulse width (80±20%) ms
|
|||||
|
RTC Error
|
≤0.5s/day
|
|||||
|
Communication
|
RS485, Modbus-RTU, 2-wire, up to 9600bps
|
|||||
|
IP Degree
|
Front: IP51
|
|||||
|
Operating Temperature
|
-10ºC ~ 55ºC
|
|||||
|
Storage Temperature
|
-25ºC ~ 70ºC
|
|||||
|
Relative Humidity
|
≤93%
|
|||||
|
Certificate
|
CE ISO9001,MID
|
|||||
Energy management
Sub-item metering
Power monitoring
Remote monitoring of electrical equipment
Din rail mounted meter
Sub-item metering
Power monitoring
Remote monitoring of electrical equipment
Din rail mounted meter
Q: Are you trading company or manufacturer ?
A: We are factory located in Jiangyin Jiangsu Province.
Q: Does your company provide customized manufacturing?
A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples? Is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
