Power Semiconductor Three Phases Rectifier Bridge Modules Mds150A
5 Piece
$1Product information
High-quality Power Semiconductor Three Phases Rectifier Bridge Modules Mds150A supplied by Sailing Commercial (Tianjin) Co., Ltd.. Bulk wholesale pricing is $1 per Piece with a minimum order of 5 Piece. Inquiry for latest prices.
Production Capacity:
100000 PCS/Year
Batch Number:
2019
Delivery Time:
3 Days
Specification:
400*300*200
HS Code:
8504409190
Signal Processing:
Analog Digital Composite and Function
Transport Package:
Carton Box
Origin:
China
Specifications
Production Capacity:
100000 PCS/Year
Batch Number:
2019
Delivery Time:
3 Days
Specification:
400*300*200
HS Code:
8504409190
Signal Processing:
Analog Digital Composite and Function
Transport Package:
Carton Box
Origin:
China
Material:
Compound Semiconductor
Manufacturing Technology:
Discrete Device
Trade Term:
FOB, CIF, CFR, EXW
Chip Type:
Fast Thyristor, Rectifier Modules
Price Term:
Fob/CPT/CIF
Type:
Intrinsic Semiconductor
Application Field:
Inverter, Induction Heating, Chopper, UPS Power
Payment Term:
LC, T/T
Model NO.:
MDS150A
MD Type:
Mdc/Mda/Mdk/MD
Others:
Mds/Mda/Mkc/Mhc/Mzc
Mf Type:
Mec/Mfa/Mfk
Application:
Motor Drives, Power Supply, Power Transmission
Mt Type:
Mtc/Mta/Mtk/Mtx/Mt
Model:
Mtc500A-1200V
Install:
Parallel, Series
Trademark:
SAILTON/STI
Package:
SMD
Brand:
Sailton/Sti
Delivery Way:
Sea/ Air/DHL/FedEx/UPS/TNT/Sf
Port Of Loading:
Tianjin Port
Payment Term:
Tt/Western Union /Paypal
Outline:
a-N Code, or Others Customs' Need
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-11-15
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Tianjin Port
Certificates:
CE for power module, CE for welding diode, ISO for factory, SGS Certificate
Product descriptions from the supplier
Power Semiconductor Three Phases Rectifier Bridge Modules MDS150A
We supply a wide range of thyristor module,diode module,scr module,power module,fast diode module,fast thyristor module.bridge rectifier,single phase bridge rectifier,3 phase bridge rectifier.
Power Module
Feature
Isolated mounting base
International standard package
Base plate insulation using AIN substrate
Industrial compatible packaging
Low forward voltage drop
High surge current Up to 5000V voltage available on reques
Press-pack structure, excellent temperature characteristics and power cycling capability
Below 350A modules are all forced air cooling, above 400A modules, air-cooled and water-cooled optional
Application
For motor drives, power supply, power transmission and distribution, railway transportation, metal smelting,
machinery manufacturing, welding machines, chemical industry,renewable energy.
CE certificate
Datasheet
| Type | IT(AV) | VDRM VRRM |
ITSM | IDRM IRRM |
di/dt | dv/dt | IGT | VGT | IH | VTO | rT | Rth(j-c) | Tj | Fig |
| A | V | Ax103 | mA | A/μs | V/μs | mA | v | mA | V | mΩ | ºC/ W | ºC | mm | |
| MTx25 | 25 | 600-1800 | 0.55 | 10 | >50 | >800 | <50 | <2 | <50 | 0.90 | 9.80 | 0.95 | 125 | A |
| MTx40 | 40 | 1.00 | 10 | >50 | <150 | <2 | <150 | 0.86 | 5.60 | 0.68 | A | |||
| MTx55 | 55 | 1.25 | 10 | >50 | <150 | <2 | <150 | 0.87 | 3.70 | 0.54 | A | |||
| MTx70 | 70 | 1.60 | 15 | >50 | <150 | <2 | <150 | 0.90 | 2.65 | 0.42 | A | |||
| MTx90 | 90 | 2.00 | 15 | >100 | <150 | <2 | <150 | 0.90 | 2.84 | 0.30 | A,B | |||
| MTx110 | 110 | 2.40 | 20 | >100 | <150 | <2 | <150 | 0.80 | 2.34 | 0.26 | A,B | |||
| MTx130 | 130 | 3.60 | 30 | >100 | <150 | <3 | <150 | 0.90 | 2.12 | 0.20 | C | |||
| MTx160 | 160 | 5.40 | 30 | >100 | <150 | <3 | <150 | 0.90 | 1.53 | 0.17 | C | |||
| MTx200 | 200 | 7.20 | 30 | >100 | <200 | <3 | <200 | 0.85 | 1.34 | 0.13 | D | |||
| MTx250 | 250 | 8.50 | 30 | >100 | <200 | <3 | <200 | 0.85 | 0.90 | 0.12 | D | |||
| MTx300 | 300 | 9.30 | 40 | >100 | <200 | <3 | <200 | 0.85 | 0.75 | 0.10 | D | |||
| MTx350 | 350 | 11.0 | 40 | >100 | <200 | <3 | <200 | 0.90 | 0.50 | 0.09 | F | |||
| MTx400 | 400 | 12.0 | 50 | >100 | <200 | <3 | <200 | 0.85 | 0.49 | 0.09 | F,N | |||
| MTx500 | 500 | 14.5 | 50 | >100 | <200 | <3 | <200 | 0.85 | 0.40 | 0.08 | F,N | |||
| MTx600 | 600 | 17.4 | 50 | >100 | <200 | <3 | <200 | 0.86 | 0.45 | 0.075 | H | |||
| MTx800 | 800 | 23.2 | 50 | >100 | <200 | <3 | <200 | 0.9 | 0.50 | 0.065 | J | |||
| MTx1000 * |
1000 | 28.0 | 50 | >100 | <200 | <3 | <200 | 0.87 | 0.45 | 0.06 | J | |||
| *MTx500 | 500 | 12.0 | 50 | >100 | <200 | <3 | <200 | 0.8 | 0.64 | 0.085 | G | |||
| *MTx600 * |
600 | 15.0 | 50 | >100 | <200 | <3 | <200 | 0.85 | 0.5 | 0.07 | I | |||
| *MTx800 | 800 | 18.0 | 50 | >100 | <200 | <3 | <200 | 0.9 | 0.4 | 0.05 | K | |||
| MTC MTA MTK MTX MT |
||||||||||||||
| Type | IF(AV) | VRRM | IFSM | IRRM | VFO | rF | Rth(j-c) | VISO | Tj | Fig |
| A | V | Ax103 | mA | V | mΩ | ºC/ W | V | ºC | mm | |
| MDx25 | 25 | 600-1800 | 0.65 | 10 | 0.80 | 10.9 | 1.25 | 2500 | 150 | A |
| MDx40 | 40 | 1.00 | 10 | 0.80 | 6.00 | 0.90 | A | |||
| MDx55 | 55 | 1.30 | 10 | 0.80 | 3.80 | 0.70 | A | |||
| MDx70 | 70 | 1.80 | 15 | 0.76 | 2.70 | 0.56 | A | |||
| MDx90 | 90 | 2.30 | 15 | 0.77 | 2.20 | 0.45 | A,B | |||
| MDx110 | 110 | 2.60 | 20 | 0.80 | 1.75 | 0.35 | A,B | |||
| MDx130 | 130 | 3.90 | 30 | 0.80 | 1.45 | 0.30 | C | |||
| MDx160 | 160 | 6.00 | 30 | 0.79 | 1.35 | 0.23 | C | |||
| MDx200 | 200 | 8.00 | 30 | 0.76 | 0.90 | 0.14 | D | |||
| MDx250 | 250 | 11.0 | 30 | 0.78 | 0.88 | 0.14 | D | |||
| MDx300 | 300 | 12.5 | 40 | 0.80 | 0.65 | 0.13 | D | |||
| MDx350 | 350 | 15.0 | 40 | 0.80 | 0.61 | 0.10 | F | |||
| MDx400 | 400 | 17.0 | 50 | 0.78 | 0.50 | 0.10 | F,N | |||
| MDx500 | 500 | 19.0 |
50 | 0.75 | 0.32 | 0.09 | F,N | |||
| MDx600 | 600 | 20.8 | 50 | 0.82 | 0.40 | 0.08 | H | |||
| MDx800 | 800 | 22.0 | 50 | 0.78 | 0.25 5 |
0.07 | J | |||
| MDx1000 | 1000 | 25.0 | 50 | 0.75 | 0.45 | 0.065 | J | |||
| *MDx500 | 500 | 13.0 | 50 | 0.78 | 0.50 5 |
0.10 | G | |||
| *MDx600 | 600 | 15.0 | 50 | 0.75 | 0.45 | 0.09 | I | |||
| *MDx800 | 800 | 19.0 | 50 | 0.75 | 0.34 | 0.08 | K | |||
| MDC MDA MDK MD |
||||||||||
| Type | IT(AV) | VDRM VRRM |
ITSM IFSM |
IDRM IRRM |
di/dt | dv/dt | IGT | VGT | IH | VTO | rT | Rth(j-c) | Tj | Fig |
| A | V | Ax103 | mA | A/μs | V/μs | mA | v | mA | V | mΩ | ºC/ W | ºC | mm | |
| MFx25 | 25 | 600-1800 | 0.55 | 10 | >50 | >800 | <50 | <2 | <50 | 0.90 | 9.80 | 0.95 | 125 | A |
| MFx40 | 40 | 1.00 | 10 | >50 | <150 | <2 | <150 | 0.86 | 5.60 | 0.68 | A | |||
| MFx55 | 55 | 1.25 | 10 | >50 | <150 | <2 | <150 | 0.87 | 3.70 | 0.54 | A | |||
| MFx70 | 70 | 1.60 | 15 | >50 | <150 | <2 | <150 | 0.90 | 2.65 | 0.42 | A | |||
| MFx90 | 90 | 2.00 | 15 | >100 | <150 | <2 | <150 | 0.90 | 2.84 | 0.30 | A,B | |||
| MFx110 | 110 | 2.40 | 20 | >100 | <150 | <2 | <150 | 0.80 | 2.34 | 0.26 | A,B | |||
| MFx130 | 130 | 3.60 | 30 | >100 | <150 | <3 | <150 | 0.90 | 2.12 | 0.20 | C | |||
| MFx160 | 160 | 5.40 | 30 | >100 | <150 | <3 | <150 | 0.90 | 1.53 | 0.17 | C | |||
| MFx200 | 200 | 7.20 | 30 | >100 | <200 | <3 | <200 | 0.85 | 1.34 | 0.13 | D | |||
| MFx250 | 250 | 8.50 | 30 | >100 | <200 | <3 | <200 | 0.85 | 0.90 | 0.12 | D | |||
| MFx300 | 300 | 9.30 | 40 | >100 | <200 | <3 | <200 | 0.85 | 0.75 | 0.10 | D | |||
| MFx350 | 350 | 11.0 | 40 | >100 | <200 | <3 | <200 | 0.90 | 0.50 | 0.09 | F | |||
| MFx400 | 400 | 12.0 | 50 | >100 | <200 | <3 | <200 | 0.85 | 0.49 | 0.09 | F,N | |||
| MFx500 | 500 | 14.5 | 50 | >100 | <200 | <3 | <200 | 0.85 | 0.40 | 0.08 | F,N | |||
| MFx600 | 600 | 17.4 | 50 | >100 | <200 | <3 | <200 | 0.86 | 0.45 | 0.075 | H | |||
| MFx800 | 800 | 23.2 | 50 | >100 | <200 | <3 | <200 | 0.9 | 0.50 | 0.065 | J | |||
| MFx1000 | 1000 | 28.0 | 50 | >100 | <200 | <3 | <200 | 0.87 | 0.45 | 0.06 | J | |||
| *MFx500 | 500 | 12.0 | 50 | >100 | <200 | <3 | <200 | 0.8 | 0.64 | 0.085 | G | |||
| *MFx600 | 600 | 15.0 | 50 | >100 | <200 | <3 | <200 | 0.85 | 0.5 | 0.07 | I | |||
| *MFx800 | 800 | 18.0 | 50 | >100 | <200 | <3 | <200 | 0.9 | 0.4 | 0.05 | K | |||
| MFC MFA MFK |
||||||||||||||
MDS
| Type | IO | VRRM | IFSM | IRRM | VFO | rF | Rth(j-c) | VISO | Tj | Fig |
| A | V | Ax103 | mA | V | mΩ | ºC/ W | V | ºC | mm | |
| MDS75 | 75 | 600-1800 | 1.00 | 10 | 0.80 | 4.70 | 0.36 | 2500 | 150 | L |
| MDS100 | 100 | 1.50 | 10 | 0.80 | 4.33 | 0.29 | L | |||
| MDS160 | 160 | 2.60 | 10 | 0.80 | 1.80 | 0.18 | M | |||
| MDS200 | 200 | 3.20 | 15 | 0.80 | 1.60 | 0.15 | M | |||
MDS |
||||||||||
MKC MHC
| IT(AV) | VDRM VRRM |
ITSM | IDRM IRRM |
di/dt | dv/dt | IGT | VGT | IH | VTO | rT | Rth(j-c) | Tq | Tj | Fig |
| A | V | Ax103 | mA | A/μs | V/μs | mA | v | mA | V | mΩ | ºC/ W | μs | ºC | mm |
| 160 | 600-1600 | 4.30 | 30 | >200 | >800 | <150 | <3 | <150 | 0.86 | 1.66 | 0.14 | 15-35 | 115 | D |
| 200 | 5.60 | 30 | >200 | <200 | <3 | <200 | 0.90 | 1.17 | 0.10 | 15-35 | F | |||
| 300 | 7.80 | 40 | >200 | <200 | <3 | <200 | 0.88 | 0.80 | 0.07 | 15-35 | H |
| IT(AV) | VRRM | IFSM | IRRM | VFO | RF | Rth(j-c) | Trr | Tj | Fig |
| A | V | Ax103 | mA | V | mΩ | ºC/ W | μs | ºC | mm |
| 160 | 600-1600 | 4.50 | 30 | 0.85 | 1.40 | 0.18 | 2.0 | 140 | D |
| 200 | 6.00 | 30 | 0.88 | 0.95 | 0.14 | 3.0 | F | ||
| 300 | 8.30 | 40 | 0.86 | 0.60 | 0.10 | 4.0 | H |
| MKC MHC MZC |
Note: MKC MHC @ Tc=85ºCMZC @Tc=100ºCVISO(AC)>2500V
Outline size:
