Precision Load Support Coupling Chain for Enhanced Transmission 12022
Meters
Negotiable
Product information
High-quality Precision Load Support Coupling Chain for Enhanced Transmission 12022 supplied by Hangzhou Camel Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Chain Size:
1/2"*3/32"
Package Gross Weight:
10.000kg
Package Size:
10.00cm * 10.00cm * 10.00cm
Model NO.:
12022
Bore Diameter:
19mm
Speed:
4000r/M
Production Capacity:
5000000pieces
HS Code:
73151190
Specifications
Chain Size:
1/2"*3/32"
Package Gross Weight:
10.000kg
Package Size:
10.00cm * 10.00cm * 10.00cm
Model NO.:
12022
Bore Diameter:
19mm
Speed:
4000r/M
Production Capacity:
5000000pieces
HS Code:
73151190
Torque:
>80n.M
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Type:
Elastic Coupling
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Hangzhou
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Surface Treatment:
Polishing
Structur E:
Rigid
Transport Package:
Sea and Air Freight
Port Of Loading:
Shanghai port, Ningbo port
Specification:
Stainless steel material
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2014-02-11
Annual Revenue Amount:
Not specified
Numbers Of Employees:
10
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai port, Ningbo port
Certificates:
Our certificate, Our production line
Product descriptions from the supplier
Step into the dynamic realm of chain couplings, where one standard chain interacts with two sprockets having the same number of teeth at the same time. The range of chain coupling designs varies significantly based on the chain type used. Common examples are double-row roller chain joints, single-row roller chain joints, toothed chain assemblies, nylon-based chain connections, and additional variants.
SFR |
D Bore Dia |
Pin diameter |
Inertia |
Approx weight |
Casing |
|||||||||
| Chain coupling No. |
SFR Chain | Min | Max | I | S L | d1 | d2 | C | ×10-3 | Dimension |
Approx weight |
|||
| No. | mm | mm | mm | mm | mm | mm | mm | mm | kgf·m2 | kg | A mm |
B mm |
kg | |
| 3012 | 06B-2X12 | 12 | 16 | 64.8 | 29.8 | 5.2 | 25 | 45 | 10.2 | 0.233 | 0.4 | 69 | 63 | 0.3 |
| 4012 | 40-2X12 | 12 | 22 | 79.4 | 36.0 | 7.4 | 35 | 61 | 14.4 | 1.020 | 0.8 | 77 | 72 | 0.3 |
| 4014 | 40-2X14 | 12 | 28 | 79.4 | 36.0 | 7.4 | 43 | 69 | 14.4 | 1.924 | 1.1 | 84 | 75 | 0.4 |
| 4016 | 40-2X16 | 14 | 32 | 87.4 | 40.0 | 7.4 | 50 | 77 | 14.4 | 3.285 | 1.4 | 92 | 75 | 0.4 |
| 5014 | 50-2X14 | 16 | 35 | 99.7 | 45.0 | 9.7 | 53 | 86 | 18.1 | 6.010 | 2.2 | 101 | 85 | 0.5 |
| 5016 | 50-2X16 | 16 | 40 | 99.7 | 45.0 | 9.7 | 60 | 96 | 18.1 | 9.720 | 2.7 | 111 | 85 | 0.6 |
| 5018 | 50-2X18 | 16 | 45 | 99.7 | 45.0 | 9.7 | 70 | 106 | 18.1 | 15.420 | 3.8 | 122 | 85 | 0.8 |
| 6018 | 60-2X18 | 20 | 56 | 123.5 | 56.0 | 11.5 | 85 | 128 | 22.8 | 40.210 | 6.2 | 142 | 106 | 1.2 |
| 6020 | 60-2X20 | 20 | 60 | 123.5 | 56.0 | 11.5 | 98 | 140 | 22.8 | 62.870 | 7.8 | 158 | 105 | 1.6 |
| 6022 | 60-2X22 | 20 | 71 | 123.5 | 56.0 | 11.5 | 110 | 152 | 22.8 | 93.450 | 10.4 | 168 | 117 | 1.8 |
| 8018 | 80-2X18 | 20 | 80 | 141.2 | 63.0 | 15.2 | 110 | 170 | 29.3 | 142.030 | 12.7 | 190 | 129 | 2.5 |
| 8020 | 80-2X20 | 20 | 90 | 145.2 | 65.0 | 15.2 | 120 | 186 | 29.3 | 204.900 | 16.0 | 210 | 137 | 2.9 |
| 8022 | 80-2X22 | 20 | 100 | 157.2 | 71.0 | 15.2 | 140 | 202 | 29.3 | 341.170 | 20.2 | 226 | 137 | 3.6 |
| 10020 | 100-2X20 | 25 | 110 | 178.8 | 80.0 | 18.8 | 160 | 233 | 35.8 | 646.290 | 33.0 | 281 | 153 | 4.6 |
| 12018 | 120-2X18 | 35 | 125 | 202.7 | 90.0 | 22.7 | 170 | 256 | 45.4 | 1075.710 | 47.0 | 307 | 181 | 6.2 |
| 12022 | 120-2X22 | 35 | 140 | 222.7 | 100.0 | 22.7 | 210 | 304 | 45.4 | 2454.500 | 72.0 | 357 | 181 | 8.0 |
SFR |
Pitch |
Roller diameter |
Width between inner plates |
Pin diameter |
Pin length |
Innerplate depth |
Plate thickness |
Transverse pitch |
Ultimate tensile strength |
Average tensile strength |
Weight per meter |
|
| SFR Chain No. | P | m(d)a(1)x | m(b)in(1) | m(d)a(2)x | L max | Lc max | m(h)a(2)x | T max | Pt | Q min | Q0 | q |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf | kN | kg/m | |
| 4012 | 12.700 | 7.95 | 7.85 | 3.96 | 31.0 | 32.2 | 12.00 | 1.50 | 14.38 | 28.2/6409 | 35.9 | 0.16 |
| 4014 | 12.700 | 7.95 | 7.85 | 3.96 | 31.0 | 32.2 | 12.00 | 1.50 | 14.38 | 28.2/6409 | 35.9 | 0.19 |
| 4016 | 12.700 | 7.95 | 7.85 | 3.96 | 31.0 | 32.2 | 12.00 | 1.50 | 14.38 | 28.2/6409 | 35.9 | 0.21 |
| 5014 | 15.875 | 10.16 | 9.40 | 5.08 | 38.9 | 40.4 | 15.09 | 2.03 | 18.11 | 44.4/10091 | 58.1 | 0.49 |
| 5016 | 15.875 | 10.16 | 9.40 | 5.08 | 38.9 | 40.4 | 15.09 | 2.03 | 18.11 | 44.4/10091 | 58.1 | 0.56 |
| 5018 | 15.875 | 10.16 | 9.40 | 5.08 | 38.9 | 40.4 | 15.09 | 2.03 | 18.11 | 44.4/10091 | 58.1 | 0.63 |
| 6018 | 19.050 | 11.91 | 12.57 | 5.94 | 48.8 | 50.5 | 18.00 | 2.42 | 22.78 | 63.6/14455 | 82.1 | 1.00 |
| 6020 | 19.050 | 11.91 | 12.57 | 5.94 | 48.8 | 50.5 | 18.00 | 2.42 | 22.78 | 63.6/14455 | 82.1 | 1.11 |
| 6022 | 19.050 | 11.91 | 12.57 | 5.94 | 48.8 | 50.5 | 18.00 | 2.42 | 22.78 | 63.6/14455 | 82.1 | 1.22 |
| 8018 | 25.400 | 15.88 | 15.75 | 7.92 | 62.7 | 64.3 | 24.00 | 3.25 | 29.29 | 113.4/25773 | 141.8 | 2.35 |
| 8020 | 25.400 | 15.88 | 15.75 | 7.92 | 62.7 | 64.3 | 24.00 | 3.25 | 29.29 | 113.4/25773 | 141.8 | 2.62 |
| 8022 | 25.400 | 15.88 | 15.75 | 7.92 | 62.7 | 64.3 | 24.00 | 3.25 | 29.29 | 113.4/25773 | 141.8 | 2.88 |
| 10018 | 31.750 | 19.05 | 18.90 | 9.53 | 76.4 | 80.5 | 30.00 | 4.00 | 35.76 | 177.0/40227 | 219.4 | 4.95 |
| 10022 | 31.750 | 19.05 | 18.90 | 9.53 | 76.4 | 80.5 | 30.00 | 4.00 | 35.76 | 177.0/40227 | 219.4 | 4.95 |
| 12018 | 38.100 | 22.23 | 25.22 | 11.10 | 95.8 | 99.7 | 35.70 | 4.80 | 45.44 | 254.0/57727 | 314.9 | 8.14 |
| 12022 | 38.100 | 22.23 | 25.22 | 11.10 | 95.8 | 99.7 | 35.70 | 4.80 | 45.44 | 254.0/57727 | 314.9 | 8.14 |
Hangzhou Camel Machinery Co., Ltd. has grown significantly since 1984, driven by the strong guidance of SARL Camel Material Agricole-F.Z.C. The company's international reach is evident through its well-placed operations in Dubai, UAE, and Egypt. Spanning 33,000 square meters, the modern plant features over 100 advanced manufacturing and inspection tools, reflecting a deep dedication to quality excellence. A wide range of products—such as roller chains, sprockets, pulleys, and agricultural components—is ISO 9001 accredited and performs reliably in various global markets. With clients in more than 50 nations, these offerings are essential in fields including food processing equipment, engineering design, printing, wood processing, textiles, rubber manufacturing, and small-scale chemical processing.
machinery, plastic machinery, and many other sectors, ensuring seamless integration and superior performance.
SARL Camel Material Agricole-F.Z.C is a leading force in supplying agricultural machinery components and industrial drive systems. We deliver top-tier products, precisely designed to boost your productivity and support your long-term achievements.
Backed by the most expansive and tactically placed storage and maintenance centers in Oran, Algeria, plus broad operational bases in Egypt and Dubai, UAE, we deliver exceptional support and custom-designed responses, precisely aligned with your distinct agricultural and industrial power transfer needs.
At Camel, we trust that truly outstanding results come from thoughtful creation and precise delivery. Our skilled group serves as a steadfast ally, fully dedicated to treating you as part of the family and forming lasting relationships built to last.
Transmission chain: a vital engine of mechanical performance. This key element reliably transfers energy and movement, seamlessly converting rotational or straight-line motion via exact sprocket engagement, delivering fluid and effective functionality.
Our conveyor chains are meticulously designed featuring perfectly positioned bearings, firmly anchored by robust chain plates. Every bearing includes a pin shaft and housing, enabling the rollers to move smoothly, delivering optimal efficiency and steady dependability.
Stainless steel chain: Manufactured from high-quality stainless steel wire or solid round steel, these links come in short and long forms. Designed for diverse industrial uses, they deliver strong and consistent reliability.
Our full lineup features feed chains equipped with P2-style attachments, lift chains with Ld2-style plates, and corn harvest chains fitted with WK-type plates. Every model is precisely designed to deliver top-tier efficiency and outstanding results.
Traction chains are essential to efficient machine functions, serving a vital function in forklifts, port cranes, textile equipment, parking structures, drilling units, elevated work systems, pipe shaping machines, and many other uses, guaranteeing smooth and dependable operation.
2. Is OEM available?
-Ves, OEM is available
3. Are you a Manufacturer or Trade Company?
-We are a factory focused on producing and exporting chains for over 37 years and have a professional internationaltrade team.
4.What terms ofpayment you usually use?T/T 30% deposit and 70% against document, Western Union,L/C at sight
5. Do you have after-sale service?
Resposible After-sale service team ,solving your problem at any time.
