Professional Shaper Machine Manufacturer (Shaping Machine BC6050)
Set
Negotiable
Product information
High-quality Professional Shaper Machine Manufacturer (Shaping Machine BC6050) supplied by Wmt Cnc Industrial Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Overall Dimensions:
2160×1070×1194mm
Motor Power:
3kw
Production Capacity:
50 Sets/ Month
Table Size:
500X360mm
Max Planing Length:
500mm
HS Code:
82081000
Origin:
Anhui
Model NO.:
BC6050
Specifications
Overall Dimensions:
2160×1070×1194mm
Motor Power:
3kw
Production Capacity:
50 Sets/ Month
Table Size:
500X360mm
Max Planing Length:
500mm
HS Code:
82081000
Origin:
Anhui
Model NO.:
BC6050
Specification:
CE, ISO
Certification:
CE, ISO 9001
Trade Term:
FOB
Precision:
High Precision
Power Source:
Manual
Automatic Grade:
Manual
Shaping Machine Type:
Medium Type
Condition:
New
Transport Package:
Standard Plywood Package
Payment Term:
To be discussed
Trademark:
WMT
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
CE Certificate, High-tech Enterprise Certificate, ISO Certificate, Patent Certificate
Product descriptions from the supplier
Product main features:
1. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting; to planing inclined plane, thereby expanding the scope of use.
2 feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
3. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
4. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
5 Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
Main Specification:
Model |
BC6050 |
|
Maximum cutting length(mm) |
500 |
|
Maximum distance from ram bottom to table surface(mm) |
370 |
|
Maximum table horizontal travel(mm) |
525 |
|
Maximum table vertical travel(mm) |
270 |
|
Dimensions of table top surface(L×W)(mm) |
500×360 | |
Travel of tool head(mm) |
120 |
|
Number of ram strokes per minute |
14-80 |
|
Swivel of tool head(°) |
±60° |
|
Maximum size of tool shank(W×T)(mm) |
20×30 |
|
Range of table power feed |
0.2~0.25 |
|
0.08~1.00 |
||
Width of central T-slot of table(mm) |
18 |
|
Power of mortr(kw) |
3 |
|
Overall dimensions(L×W×H)(mm) |
2160×1070×1194 |
|
N.W/G.W(kg) |
1650/1760 |
|
WMT CNC Industrial Co., Ltd.is located in the southwest of the Yangtze River in Anhui Province with famous Buddhist shrine in the north of Jiuhua Mountain. The transportation facilities here are very convenient, directly linked with many metropolis like Shanghai, Beijing and Shenzhen via the highway, international airport, and high-speed railway.
WMTCNCcompanyfocuses on the research and development, manufacturing, sales and service ofvariousCNC machine tools.Our productsare widely used in the processing of molds and parts for products in the aerospace, automotive, steel, petrochemical, and electronics industries. The products are exported to more than 50 countries and regions around the worldwith good reputation always.
Ourmain products areVertical machining centers,Gantry machining centers, CNC milling machines, CNC lathes,Turning machining centers,commondrilling and milling machines, milling machines, lathes, andDIYmachine tools, etc.
Main functional componentsof machinesaresupplied byworld-renowned brands such as Japan, Taiwan and Germany. The concept of combining "craftsman spirit" and "intelligent manufacturing" runs through the research and development, production and sales of various products, relying on advanced processing And testing equipment, scientific management to ensureour products withthe high precision, high rigidity and high efficiency. Our machines are thetrustworthy product for mold and metal processing.
Q1: How is the warranty?
A1: Warranty time is13 monthsafter BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What's the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
