High-quality Purification Purifier for Impurity Removal, Water Removal Purifier supplied by GOLDSOL(WUHAN)HIPOT TEST EQUIPMENT FACTORY. Bulk wholesale pricing ranges from $7,000 to $19,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Package Size:
150.00cm * 170.00cm * 180.00cm
Capacity:
18000L/H
Production Capacity:
20sets/Month
Accuracy Grade:
3
Power Source:
380V
Weight:
500kg
Package Gross Weight:
700.000kg
HS Code:
9030332000
Specifications
Package Size:
150.00cm * 170.00cm * 180.00cm
Capacity:
18000L/H
Production Capacity:
20sets/Month
Accuracy Grade:
3
Power Source:
380V
Weight:
500kg
Package Gross Weight:
700.000kg
HS Code:
9030332000
Specification:
CE
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Display:
Digital
Trade Term:
FOB, CFR, CIF, DAT, FAS, DDP, DAP, CPT, FCA, EXW
Trademark:
GOLDSOL
Colour:
Grey
Model NO.:
HDTL-300
Type:
Insulation Oil Filtration System
Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Transport Package:
Plywood Case Outside
Payment Methods:
Support payments in USD
Port Of Loading:
Wuhan/Shanghai/Shenzhen/Guangzhou
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2006-05-10
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
FOB, CFR, CIF, DAT, FAS, DDP, DAP, CPT, FCA, EXW
Port Of Loading:
Wuhan/Shanghai/Shenzhen/Guangzhou
Certificates:
CE certificate of DC Hipot test set, VLF CE certificate
Product descriptions from the supplier
Application
1.HDTLseriesmulti-functional vacuum oil filteris mainly used to treat and purify unqualified lubricating oil, turbine oil, refrigeration oil, gear oil, anti-wear hydraulic oil and other high-precision oil.
2.It is used in power plant, power station, electric power company, power transformation industry, metallurgy, petrochemical, machinery, transportation, railway and other industries power system. It is used to purify lubricating oil such as machine oil, cooling oil, gasoline, engine oil, diesel engine oil, heat treatment oil, etc.
3.Filter harmful components such as moisture, impurities and volatile matter (such as ammonia) in the oil to ensure the normal operation of hydraulic system, power system and lubrication system.
Equipment standard:
Constraction and function of equipment
The equipmentincludes: frame, oil filtering system, heating system, vacuum system, separation system, condensate system, oil transportation system, pipeline valve system and electric control system.
Advantage
1)It adopted theseparation technology, high-efficiency vacuum dehydration, degassing and impurity remova. It hashigh oil purification efficiencyfor the industrial oil such as turbine oil, hydraulic oil and lubricating oil, so that the filtered oil can meet the use standard.
2)Compact structure: it adopts the structure of removing filter element without tools, so it is convenient and quick to replace filter element.
3)Equipped with infrared defoaming device: automatically eliminate the oil bubble in the vacuum tank, so as to avoid the damage of the vacuum pump caused by the oil bubble inhalation into the vacuum pump.
4)Equipped with filter element pollution alarm: when pollutionofthe filter element is fully absorbed, the whole machine will automatically stop running and give an alarm to stop and prompt to replace the filter element.
5)Built in heater: heating efficiency, heat preservation performance, heating speed, etc. are superior to the same industry level.
6)Low power density tubular heating element is adopted,built-inoil shortage protection and digital display constant temperature control device, which will not cause dry burning and oil cracking of oiler under any circumstances, and the whole machine can be operated online.
7)The oil transfer pump works stably with low noise.
8)When the equipment is started, the noise is stable and low. During normal operation, the oil pump does not empty and the motor does not operate under load. In case of any abnormal condition, the alarm can be automatically given, so as to achieve the automatic and reliable protection of the main equipment and ensure the safe and continuous operation of the oil filter for a long time.
9)The machine is equipped with automatic drainage system, automatic anti oil leakage device, automatic oil level control, automatic alarm and shutdown to prevent the oil leakage of vacuum oil filter.
10)The bottom of the whole machine is equipped with a bearing caster for convenient movement.
12)Quick connector is used for oil inlet and outlet pipe, which is convenient to use.
13)The machine has stable performance and avoids the trouble of adjusting each valve after starting the common oil filter.
Main technical parameters:
| 1 | Model no. | HDTL-20 | HDTL-30 | HDTL-50 | HDTL-100 | HDTL-150 | HDTL-200 | HDTL-300 |
| 2 | Flow | 1200L/h | 1800L/h | 3000L/h | 6000L/h | 9000 | 12000 | 18000 |
| 3 | Type | Coalescence vacuum separation | ||||||
| 4 | Working Vacuum (Mpa) | -0.06~0.098 | ||||||
| 5 | Pressure (Mpa) | ≤0.5 | ||||||
| 6 | Noise (dbA) | ≤ 78 | ||||||
| 7 | Residual Moisture content(PPm) | ≤100 | ||||||
| 8 | Acid Value (mgKoH/g) | ≤ 0.3(GB/T264) | ||||||
| 9 | Inlet and outlet pipe diameter(mm) | 25 | 25 | 32 | 40 | 50 | 50 | 65 |
| 10 | Heating range of Oil Temperature (ºC) | 20ºC-80ºC | ||||||
| 11 | Filter Precision(μm) | ≤5 | ||||||
| 12 | Mechanical impurities(%) | No (GB/T511) |
||||||
| 13 | Demulsification degree(min) | ≤15 (GB/T7305) | ||||||
| 14 | Total power(KW) | 23 | 25 | 45 | 65 | 86 | 108 | 160 |
| 15 | Power supply | 380V±10%, 50Hz or 60Hz(Can be customized) | ||||||
| 16 | Net weight(kg) | 280 | 320 | 580 | 800 | 900 | 1000 | 1200 |
| 17 | Demension(cm) (L*W*H) |
100*80*140 | 100*80*150 | 120*90*150 | 150*110*170 | 170*120*180 | 180*130*190 | 200*150*210 |
6.Accessoires
| Sr | Decription | Qty |
| 1 | Inlet/outletoiltube | 10m |
| 2 | Sealing element | 1 set |
| 3 | Hose clamp | 4 pcs |
| 4 | Circuit diagram | 1 pc |
| 5 | Opearting manual | 1 pc |
| 6 | Calibration report | 1 pc |
7.Optional items for buyers:
1. Water circulation vacuum pump;
2. Flow meter with accumulation function;
3. On line moisture detector and on-line particle detector;
4. PLC intelligent control, touch screen and dynamic display;
5. High quality imported power components, filter parts and electrical components to improve equipment performance;
6. BT or CT explosion-proof
8.Customized equipment as per buyer's requirements:
1. The whole machine mechanism can be made into mobile and fixed type;
2. Fully closed and open type can be made;
3. Select the equipment color according to the needs;
4. The whole machine can be made into oil filter with plate and frame, which has better filtering effect for oil with more impurities
