Robust CNC Machine Tool with 10 4 Inch Display Technology

Presenting the GSK 980TDi-H, a cutting-edge controller meticulously built to enhance performance in your lathe operations. This CNC system embodies advanced engineering principles, engineered to connect smoothly with your equipment for superior speed and exactness.

GSK980TDi TURNING MACHINE CNC PRODUCT BRIEF
Presenting the GSK980TDi, the most advanced addition to the highly respected GSK980TD lineup! Designed by the same innovative team that developed the GSK980TD, GSK980TDa, GSK980TDb, and GSK980TDc, this next-generation solution builds on GSK's proven expertise in serving the mainstream CNC turning machine and turning center sectors with unmatched precision and refinement.
The GSK980TDi sets a new benchmark in advanced manufacturing through its built-on GSK-Link industry spot BUS architecture. It combines a BUS servo drive with a next-gen multi-core 23-bit absolute encoder motor, delivering exceptional 0.1μm positional precision. Featuring real-time servo tuning and a non-blocking mechanical homing function, it ensures top-tier accuracy. Crafted by celebrated design experts and backed by deep development in performance optimization, smart functionality, intuitive interface, and expandable programming, it represents the cutting edge of engineering advancement.
The unveiling of the GSK980TDi heralds a transformative era in the realm of CNC systems, setting new benchmarks in efficiency and performance!

High speed & high precision control
By leveraging the GSK-Link industrial fieldbus, our next-generation servo motors, fitted with GR-L series control units and 25-bit or higher precision absolute encoders, deliver sub-nanometer positioning. This integrated approach guarantees that the system’s performance matches the encoder’s real-time feedback, maximizing the potential of high-resolution servo systems to produce outcomes defined by both rapid response and extreme accuracy.

Oscillating chip break
While executing the intense roughing phase, controlled sine and cosine wave patterns are introduced to the feed direction, making the cutting tool move in a wavy motion along the path. This smart technique fragments long chip streams into smaller, controlled segments, stopping them from wrapping around the tool or the workpiece, thus avoiding tool fracture or displacement of the workpiece’s rotational axis during operation.

Support turning, milling and drilling complex machining
The machine features a powerful setup with five linear motion axes and two analog spindle drives. With a servo-driven spindle installed, capabilities like spindle angle control, precise tapping, cylindrical path programming, and polar coordinate motion are enabled, fully addressing the needs of integrated turning and milling operations.

Backstage editing
Unlock your system's full performance by editing programs in real time while processing. This feature enables smarter resource allocation, precise timing control, and greatly enhances your machine's overall productivity.

Graphical simulation
Discover a revolutionary approach to coding with our visual simulation tool. By creating a digital replica of the workpiece in real-time, operators obtain a realistic depiction of the cutting process, enabling them to spot and fix errors more efficiently via a clear, interactive display of the cutting trajectory.

Manual MST function
Enable efficient workflow through the Manual MST feature, letting operators run MST instructions straight from the position display in manual or MPG mode. This eliminates frequent screen navigation, delivering a more focused and intuitive control setup for faster machine handling.

Torque control
Enjoy precise rotational management through our intelligent feature that adjusts motor speed and stops movement at set thresholds. Once target torque is reached, the system locks in that force, establishing a responsive equilibrium between driving power and outside resistance. Perfectly suited for accurate workpiece alignment and tailstock positioning between spindle units.

Thread repair function
Equip your device with the thread restoration feature, designed to fix compromised threads—like those in big oil pipelines or bolts—regardless of whether it uses a servo or analog motor spindle.

Polygon turning

For traditional polygon processing, power milling tools are usually used for processing. For occasions where high precision is not required the polygon turning function can be used to accelerate the processing of various polygons by the offset angle before synchronizing the workpiece axis with the main control axis and changing the speed ratio of the workpiece axis and the tool axis.

Machine tool fault diagnosis
Our machine tool diagnostic tool offers a clear visual representation of input and output signals directly on the machine's structural layout. This easy-to-understand display enables quick identification of faults and faster fixes for any machine tool problems.

Application case
The GSK980TDi delivers outstanding features tailored for accurate and effective brake pad production. This state-of-the-art solution guarantees top-tier performance and consistency, essential for any modern manufacturing setup.

Special type: Brake pad processing machine

Application effect

Driving linear and rotary axes with a general servo drive;

The grinding wheel is machined with end faces instead of the side of the common grinding wheel;

Complete tasks with dedicated instructions

Technical Specification
